Chamfering Machine | Kouei Japan Trading | Get Quotation https://koueitrading.com/global Purchase tools and equipments made in Japan Mon, 16 Mar 2026 03:09:59 +0000 en-US hourly 1 https://wordpress.org/?v=7.0.2 https://koueitrading.com/global/wp-content/uploads/2018/01/cropped-KoueiVietnam-logo-32x32.png Chamfering Machine | Kouei Japan Trading | Get Quotation https://koueitrading.com/global 32 32 Miyakawa MArX-MB Pneumatic Chamfering Machine https://koueitrading.com/global/product/miyakawa-marx-mb-pneumatic-chamfering-machine/ Sun, 09 Mar 2025 01:10:50 +0000 https://koueitrading.com/global/?post_type=product&p=12896 Product made in Japan Manufacturer: Miyakawa Model: MArX: MArX-MB, MArX-MB-Z, MArX-MB-K Product Video Specification Model MArX-MB MArX-MB-Z MArX-MB-K Types of chamfers R3 Initial Chamfer amount setting equivalent to R 2.5 mm (Note 1) (Option: Ｃ1、Ｃ2) (Note 2） R4 Initial Chamfer amount setting equivalent to R 3.0 mm (Note 1) R4 Initial Chamfer amount setting equivalent […]

The post Miyakawa MArX-MB Pneumatic Chamfering Machine first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan

Manufacturer: Miyakawa

Model: MArX: MArX-MB, MArX-MB-Z, MArX-MB-K

Product Video

Specification

Model MArX-MB MArX-MB-Z MArX-MB-K
Types of chamfers R3
Initial Chamfer amount setting equivalent to R 2.5 mm (Note 1)
(Option: Ｃ1、Ｃ2) (Note 2）		 R4
Initial Chamfer amount setting equivalent to R 3.0 mm (Note 1)		 R4
Initial Chamfer amount setting equivalent to R 3.3 mm (Note 1)
Inserts Exclusive carbide insert (3R) Exclusive carbide insert (4R) Exclusive carbide insert (4R)
Min. chamfered thickness 9mm 9mm 9mm
Min. processing radius R17 (In the case of R3) R17 (In the case of R3) R17 (In the case of R3)
Cutter 3-Blades 3-Blades 3-Blades
No-load rotational speed 10,000 min-1 (Approx.)(Note 3) 10,000 min-1 (Approx.)(Note 3) 10,000 min-1 (Approx.)(Note 3)
Working pressure 0.49～0.68Mpa 0.49～0.68Mpa 0.49～0.68Mpa
Air consumption 0.86ｍ3/min 0.86ｍ3/min 0.86ｍ3/min
Weight 3.3kg (Approx.) 3.3kg (Approx.) 3.3kg (Approx.)

MArX-MB型

MArX-MB仕様



The post Miyakawa MArX-MB Pneumatic Chamfering Machine first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa MAG Chamfering Machine Air-type https://koueitrading.com/global/product/miyakawa-mag-chamfering-machine-air-type/ Tue, 12 Nov 2019 07:46:15 +0000 https://koueitrading.com/global/?post_type=product&p=12898 Product made in Japan Manufacturer: Miyakawa Model: MAG Product Video

The post Miyakawa MAG Chamfering Machine Air-type first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan

Manufacturer: Miyakawa

Model: MAG

MAG

Product Video



The post Miyakawa MAG Chamfering Machine Air-type first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa MArX-NEO, MArX-NEO-Mini Pneumatic Chamfering Machine https://koueitrading.com/global/product/miyakawa-marx-neo-marx-neo-mini-pneumatic-chamfering-machine/ Tue, 12 Nov 2019 06:53:12 +0000 https://koueitrading.com/global/?post_type=product&p=12894 Product made in Japan Manufacturer: Miyakawa Model: MArX-NEO, MArX-NEO-Mini Product Video Specification Types of chamfers R3 Initial Chamfer amount setting equivalent to R 2.5 mm (¹) (Option: Ｃ1) (²) Min. processing radius R17 Working pressure 0.49～0.68Mｐａ Air consumption 0.82m³/min Weight 2.2 kg (handle specification) / 2.0 kg (silencer specification) ¹: The initial chamfering amount is only […]

The post Miyakawa MArX-NEO, MArX-NEO-Mini Pneumatic Chamfering Machine first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan

Manufacturer: Miyakawa

Model: MArX-NEO, MArX-NEO-Mini

Product Video

Specification

Types of chamfers R3
Initial Chamfer amount setting equivalent to R 2.5 mm (¹) (Option: Ｃ1) (²)
Min. processing radius R17
Working pressure 0.49～0.68Mｐａ
Air consumption 0.82m³/min
Weight 2.2 kg (handle specification) / 2.0 kg (silencer specification)

¹: The initial chamfering amount is only for when the element surface angle is 90 °.
²: Please contact us about the optional chamfer amount of C1 and insert requirements.

MArX-Neo

MArX-NeoMArX-Neo

The post Miyakawa MArX-NEO, MArX-NEO-Mini Pneumatic Chamfering Machine first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa ESA-3R Self-Propelled High Speed Chamfering Machine https://koueitrading.com/global/product/miyakawa-esa-3r-self-propelled-high-speed-chamfering-machine/ Tue, 31 Jul 2018 04:21:07 +0000 https://koueitrading.com/global/?post_type=product&p=1452 Product Made in Japan Manufacturer: MIYAKAWA Model: ESA – 3R Product Video Features It uses a dedicated carbide cutting tool with carbide R tip than the conventional machining method, so a uniform, extremely smooth finished surface can be obtained. By adopting exclusive carbide R chips, chip exchange can be done easily. It can be attached […]

The post Miyakawa ESA-3R Self-Propelled High Speed Chamfering Machine first appeared on Kouei Japan Trading | Get Quotation.]]> Product Made in Japan

Manufacturer: MIYAKAWA

Model: ESA – 3R

Product Video

Features

  • It uses a dedicated carbide cutting tool with carbide R tip than the conventional machining method, so a uniform, extremely smooth finished surface can be obtained.
  • By adopting exclusive carbide R chips, chip exchange can be done easily.
  • It can be attached easily to the straight part of the steel plate. Automatic traveling processing is performed to the material rear end or stopper with one setup.
  • Self-propelled type is particularly effective for R-chamfering of long workpieces.

Specifications

Specification specification
Types of chamfering R face – R 2, R 3
C-plane – C1, C2
Processed plate thickness min 9 mm – max 100 mm
Working plate width 150 mm or more (rib height 100 mm or more)
Used cutter 3 blades (clockwise rotation)
Used chip Exclusive carbide R tip (stock stock)
Rotation speed 4000 min – 1
Cutting speed 4500 mm / min
Power capacity 3 phase, 200 V brushless DC motor 750 W
Machine size 250 × 320 × 505 (605) mm
Machine weight 17.5 kg Control panel (7 kg) separate

The post Miyakawa ESA-3R Self-Propelled High Speed Chamfering Machine first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa MSA-3R Self-Propelled One Side Surface Chamfering Machine https://koueitrading.com/global/product/miyakawa-msa-3r-self-propelled-one-side-surface-chamfering-machine/ Tue, 31 Jul 2018 04:09:03 +0000 https://koueitrading.com/global/?post_type=product&p=1443 Product Made in Japan Manufacturer: MIYAKAWA Model: MSA-3R Product Video Features It uses a dedicated carbide cutting tool with carbide R tip than the conventional machining method, so a uniform, extremely smooth finished surface can be obtained. By adopting exclusive carbide R chips, chip exchange can be done easily. It can be attached easily to […]

The post Miyakawa MSA-3R Self-Propelled One Side Surface Chamfering Machine first appeared on Kouei Japan Trading | Get Quotation.]]> Product Made in Japan

Manufacturer: MIYAKAWA

Model: MSA-3R

Product Video

Features

  • It uses a dedicated carbide cutting tool with carbide R tip than the conventional machining method, so a uniform, extremely smooth finished surface can be obtained.
  • By adopting exclusive carbide R chips, chip exchange can be done easily.
  • It can be attached easily to the straight part of the steel plate. Automatic traveling processing is performed to the material rear end or stopper with one setup.
  • Self-propelled type is particularly effective for R-chamfering of long workpieces.

Specifications

Specification specification
Types of chamfering R face – R1, R2
C-plane – C1, C2
Processed plate thickness min 9 mm – max 50 mm
Working plate width 200 mm or more (rib height 80 mm or more)
Used cutter 3 blades (clockwise rotation)
Used chip Exclusive carbide R tip (stock stock)
Rotation speed 2000/2400 min-1 50/60 Hz
Cutting speed 1275/1300 mm / min 50/60 Hz
Power capacity 200 V (3 phases). 0.8 kvA
Machine size 210 x 370 x 400 mm
Machine weight 16 kg

MSA - 3R



The post Miyakawa MSA-3R Self-Propelled One Side Surface Chamfering Machine first appeared on Kouei Japan Trading | Get Quotation.]]>
