Manufacturer: KURIMOTO

Model: KEX-65, KEX-80, KEX-100, KEX-125,KEX-160

The Kurimoto’s KEX series extruders are a unique two-shaft kneading and extruding machine developed by Kurimoto enabling you to process new materials.
Kurimoto has a long list of successful accomplishments of conventional KRC Kneader (continuous two-shaft kneading machine) for the applications of continuous kneading and reaction of resins and others, and is highly regarded for its technical expertise. Kurimoto has developed and commercialized the KEX series extruders on these experience and technology in the field.
The KEX series extruders are designed with thorough attention to high-temperature heating, high-torque drive, corrosion and wear resistance, precise controllability, and usability in addition to superb kneading capability, enabling you to process new materials such as plastic compounds and polymer alloy.

Features

Screw

Two-start and three-start types of screws are available. You can choose appropriate one for your applications.
By combining the screw elements such as screws of different pitches, reverse screws, and special kneading discs on the screw shaft, you can choose a best-suited screw profile for your kneading requirements. The screws and kneading discs have superb self-cleaning capability. Furthermore, the screw shaft and screw elements are fixed with a spline.

Barrel

The barrel is separated into segments having the order of 4D in length respectively. Therefore, various types of barrels are combined to use according to your applications. You can choose a barrel from feed barrel, standard barrel, vent barrel, dehydration barrel, liquid injection plate, and others. Normally, common steel is used for the barrels and screws, while heat-resisting, corrosion-resisting, or wear-resisting steel is used according to the applications.

Structure

Specifications

Manufacturer: KURIMOTO

Indirect heating type rotary dryer
This is an indirect heating type of rotary dryer that brings materials into indirect contact with heating medium to provide heat exchanging.
The indirect heating type of rotary dryer is classified into external heating rotary dryer and steam tube dryer, which are applied for the following conditions.

If you use materials that are easily affected by contact with combustion gas.

If you need to minimize the amount of exhaust gas from the dryer.

If you use materials that are apt to produce dust.

If you use materials that are easily affected by oxidation.

If you need to recover volatile component.

Construction

The main unit of the rotary dryer is an inclined shell supported by four rollers. Materials, which are fed through one end of the shell, move inside the shell along the inclination of the shell and through the rotary movement and are discharged from the other end. Materials, while moving inside the shell, are lifted up by a lifter incorporated in the shell. Then, the materials fall evenly in the shell space and exchange heat with the hot air flowing through the space to dry. Depending on the method of providing hot air for the materials, this dryer is classified into two types, that is, concurrent flow drying type by which the hot air and materials flow in the same direction and countercurrent flow drying type by which they flow in the opposite direction.
Lifter
The lifter is the most critical part having an influence on the performance of the dryer, which provides uniform dispersion of materials in the shell space. Any of the constructions shown below is used according to the physical properties of materials. Furthermore, spiral lifters designed with consideration of forced feeding of materials are used for the material feeding end.

Adjustment of residence time
By providing dams according to the applications, the materials residence time can be adjusted.

Prevention of adhesion and accumulation
In order to handle materials of high adhesive property, chains are provided in the shell or a hammering unit is provided externally on the shell, thus preventing material adhesion and accumulation.

Concurrent flow and countercurrent flow
Concurrent flow drying type
With the concurrent flow drying type, the materials move and the hot air flows in the same direction. Therefore, the hot air of the highest applicable temperature comes in contact with materials of the lowest applicable temperature at the end of the material inlet of the rotary shell. Normally, the concurrent flow drying type is used for the following conditions.

Countercurrent flow drying type
With the countercurrent flow drying type, the relation of flow direction and temperature between the hot air and the materials becomes reverse equivalent of the concurrent flow drying type. Therefore, this type is used especially in the case that low-moisture products are required, taking advantage of its characteristic that the hot air of the highest applicable temperature comes in contact with materials of the lowest moisture at the end of the material outlet.

Application

Indirect heating type rotary dryer

Manufacturer: KURIMOTO

Model: KSF-01

The SF Sharp Cut Separator is a centrifugal, pneumatic classifier making it possible to classify particles of up to 0.3 mm. On the SF Sharp Cut Separator, the cylindrical squirrel-cage rotor with multiple blades arranged in a radical pattern in order to classify, seal, and discharge fine particles rotates at a high speed to generate the centrifugal force due to rotary airflow and the centripetal force due to suction air, fixing up the cut size in balance between the centrifugal and centripetal forces.

Features

Enable to classify submicron particles.
Reduce the secondary air consumption due to the introduction of the closed seal chamber.

Provide isolation-free particle size distribution.

Provide a sharp particle size distribution.

Minimize wear contamination.

Diminish the power consumption due to self-suction seal air

Construction

Typical Flow Sheet

Specifications

Applications

Silicon nitride

Talc

Special glass

Aluminum oxide

Toner

Calcium carbonate

Silicon

New materials and others

Manufacturer: KURIMOTO

Features

Hammer Crusher with high-performance grate bar

Easily ensures the desired crushed particle size.
Suitable for fine crushing

More suited for fine crushing than top feed type.

Uniform particle size

The grate bar minimizes the effects of raw stone size and shape on the crushed particle size.

Extremely high reduction ratio

Application

Cement plants

(Used to crush limestone, clay, clinker, plaster, etc.)

Civil engineering and construction

(Used to manufacture concrete aggregate and road gravel)

Glass and ceramics

(Used to crush raw stone, cullet, old bricks, etc.)

Thermal power plants and gas plants

(Used to crush coal)

Specifications

Note)Capacity and required electric power vary according to material,feed size and crushing size.The above mention capacity indicates approximate capacity indicates approximate standard capacity in case of crushing medium-hard limestone.

Manufacturer: KURIMOTO

By combining the MRCP Roll Compactor with two-shaft self-cleaning type kneading machine to have raw materials intruded between the rolls, you can gain a variety of features, which could not be provided with previous dry-type compression granulating machines

Features

The MRCR Roll Compactor has a two-shaft self-cleaning type screw, which maintains stability of processing capability even with adherent materials.

Screws are segmented for ease of replacement when worn and torn.

By installing kneading paddles, you can achieve adding binder and granulation in one system.

The MRCR Roll Compactor is available for mixing, compression, and de-gassing as the pretreatment equipment for kneading machines, enabling you to increase the kneading capacity.

Applications

Chemical Industry : Plastics (e.g. phenol, urea, and melamine)

Electronics : Ferrite, toner, and paints

Pharmaceuticals : Chinese medicine, antibiotics, and others

Food products : Seasonings, condiments, and food additives

Fertilizers : Lime, chloride of potash, ammonium chloride, and compound fertilizers

Agricultural chemicals : Herbicides and insecticides

Inorganic substance : Purified talc, lime, and clay

Specifications

Typical Flow Sheet

Manufacturer: KURIMOTO

Low noise, Low vibrations, Less clogging!

Unlike conventional vibrating screens, this roller screen is particularly useful for processing materials of “high moisture content” and “high adhesiveness.”

Features

Quiet operation

Free from operating noise and secondary pollution

Low vibrations

Vibrational load do not need to be taken into account. Compared to vibrating screens, the support frame can be designed lighter in weight and lower in vibrations.

Less likely to get clogged

Reduced concerns about clogging

Low powdering rate

Low vibration reduces the powdering rate.

Specifications

Note
1) Capacity shows the case when treating raw material with apparent specific gravity 1.6t/m³.
2) Motor output (kW) includes the efficiency of reducer, chage gear and transmission part.
3) As a rule, this machine employs variable speed operation.
4) Inclination angle is standardised as 15 downward.
5) Grizzly opening shall be set to the thickness of feed material.

Applications

Suitable to screen materials that were hard to be screened with conventional vibrating screens (such as high-moisture, -adhesion, and -temperature objects).

Manufacturer: KURIMOTO

Model:TES-60

Features

By using 5-axis AC servomotors, it can fit to various motion and speed for transferring.

Without back-rush phenomenon, ball screw structure can make higher accuracy and speed transferring

It controlled by servomotors and synchronized with die-lube system, it can provide an appropriate motion for different kinds of forging works.

Manufacturer: KURIMOTO

The Kurimoto Solvent Recovery System is a fixed bed type of flue gas treatment equipment using granulated active carbon, which has been developed for the purpose of recovering organic solvent contained in the flue gas. By passing the solvent-containing gas through the granulated active carbon layer, the solvent is adsorbed to the active carbon to exhaust clean air. By blowing vapor into the active carbon layer after the solvent is adsorbed, the solvent is isolated from the active carbon, and recovered after condensation and separation.

Features

Providing a high degree of elimination efficiency.

Supporting for large changes in inlet concentration.

Trouble-free operation.

A large amount of know-how and extensive experience.

Enabling treatment in the range from small capacity to large capacity.

Less running costs, compared to other solvent recovery systems.

Application

Chlorine base organic solvent

• Solvent and monomer generated from solution polymerization lines.
• Industrial cleaning agent such as methylene chloride, trichloroethylene, and tetrachloroethylene

Chlorofluorocarbon base solvent

• Heat insulation chlorofluorocarbon (CFC-11and HCFC-141b)
• CFC-113

Hydrocarbon base organic solvent

• Non water base
  Benzene, toluene, xylene, styrene, naphtha, kerosene, heptane, and others
• Water base
  Methanol, ethanol, acetone, methyl ethyl ketone, propanol, methyl acetate, ethyl acetate, butyl acetate, and others

Operating Process

The Kurimoto Solvent Recovery System enables the elimination and recovery of solvent contained in flue gas by performing the following processes in order of “Adsorption”, “Isolation”, and “Drying”. By using two active carbon adsorption towers, the continuous treatment of flue gas is enabled.

The solvent-containing gas is sucked by the blower. When the gas passes through the granulated active carbon layer, the solvent is adsorbed to the active carbon, where it turns into clean air to be exhausted.

Steam is blown into the adsorption tower from its bottom to purge the solvent adsorbed to the active carbon. The isolated solvent vapor passes through the condenser where it is liquefied, and it is recovered by gravity separation through the separator.

The active carbon, which has got wet in the isolation process, is dried by hot air generated through the steam air heater and, then, cooled by air of ambient temperature.

Specification

1. The Kurimoto Solvent Recovery System is of unit type. Therefore, the system can support for applications requiring high concentration and large air quantity in accordance with the combination.
2. Each type has the following models.
1) Model SA (single tower, automatic control)
2) Model DA (twin towers, automatic control)
3) Model 2BDA (twin blowers, twin towers, automatic control): Supporting for solvent of low boiling point
3. Increased safety explosion-proof type is available on request, which can support for the treatment of flammable solvent.

4. Choice of type

Typical Flow Sheet

Manufacturer: KURIMOTO

Offering the best wear-resistance among high-chromium-based cast iron consumables

These are major consumable parts used at coal pulverizing mills for boilers and firing kilns. However, in recent years, longer-life parts have been required in order to reduce maintenance costs of these wear parts.

Features

Life twice as long as Ni-Hard IV that has been conventionally used

18Cr-based cast-iron material provides the top level of hardness through the effect produced by the proper mixing of C and Cr, special heat treatment, and addition of special elements.

Maintained at stable hardness

Thin-wall parts and thick-wall parts such as rollers do not lose hardness loss from surfaces to their core.

High hardness, but less toughness loss

Higher hardness but the same toughness as conventional high-chromium materials.

Application

Pulverizing of coal

Pulverizing of blast furnace slag

Pulverizing of calcium carbonate

Preliminary crushing of clinker

Manufacturer: KURIMOTO

A winding core made of reinforced plastic, used in the manufacturing and processing of products such as metallic foil and high-performance films such as optical films etc.

Kurimoto Ltd also offers general-purpose grade cores that are perfect for the winding of general-purpose plastic film, paper products, etc

Features

High-Precision		Having excellent cylindricity and circularity, and minimizing winding wrinkles.
High-Rigidity		Very rigid and stable winding.
Dust-Free		Adaptable for use in clean rooms.
Heat Resistance		No deformation even under high temperature, because thermosetting plastic is used.
Reusable		Can be reused by repairing of the surface, cutting of both ends, and so on, if the core is damaged.

Application

Winding of films such as PET, PE, PI
Winding of high-performance film.
e.g. optical film
Winding of processed film such as deposition.
Winding of paper products
Winding of seals, labels, etc.
Winding of metallic foil

Manufacturer: KURIMOTO

Features

Rigid materials can be sized.

With the Kurimoto granulator, you can adjust product sizes by changing the roll width and increasing the number of granulating stages

Structure

Specifications

Manufacturer: KURIMOTO

This machine is an indirect heating type of rotary kiln using ceramics for the retort material. Introducing the ceramic retort enables continuous heat treatment at a high temperature (approximately 1500ºC) for nonmetallic materials to produce stable and high quality products

Features

High-temperature, continuous treatment enabled

Easy replacement of ceramic retort according to objects

Scraper mountable

Severe atmosphere and temperature control (sealing performance to a maximum of±500Pa)

Easy maintenance

Compact installation area required

Specifications

Manufacturer: KURIMOTO

This dryer has double rotary shells consisting of a horizontal external shell and an inclined internal shell. The internal shell is comprised of numbers of vanes as shown in the figure. The annular section between the external and internal shells serves as a passage of the hot air and is divided into numbers of segments. The hot air is fed from this annular section through the gaps between the vanes and exhausted through the material layer, which continuously moves. The material is fed into the internal shell from the same direction as that at the hot air inlet and dried along with the shell rotation while continuously moving to the outlet.

Features

Large heat capacity coefficient and high heat efficiency
The hot air passes directly through the material layer to provide a maximum of touch area between the hot air and the material, allowing a large calorific value, Ua = 2,100 to 7,500 KJ/m3hr℃, which transfers from the hot air to the material.

Large hold-up available
It is possible to provide 15 to 20% of hold-up compared to 10% with other types of rotary dryers, making it possible to reduce the volume of the dryer.

Minimized material destruction
This dryer has no process to lift the materials up and down with a lifting wing, suppressing the destruction of the material particles.

Less wear of vanes
This dryer has no process to lift the materials up and down with a lifting wing, minimizing the wear of the vanes.

Minimized uneven drying
Superb mixing of materials is provided through the rotation and aeration, enabling you to get homogeneous products with uneven drying minimized.

Drying possible to low moisture content
Possible extended residence time (some for 3 hours) enables the materials to be dried up to extremely low moisture content.

A constant rate of hot air can be fed in the material layer.

Drying and cooling can be performed in a single unit.

Continuous, Rotary Type Through-flow Dryer

Summary

This dryer has double rotary shells consisting of a horizontal external shell and an inclined internal shell. The internal shell is comprised of numbers of vanes as shown in the figure. The annular section between the external and internal shells serves as a passage of the hot air and is divided into numbers of segments. The hot air is fed from this annular section through the gaps between the vanes and exhausted through the material layer, which continuously moves. The material is fed into the internal shell from the same direction as that at the hot air inlet and dried along with the shell rotation while continuously moving to the outlet.



Features

• Large heat capacity coefficient and high heat efficiency
  The hot air passes directly through the material layer to provide a maximum of touch area between the hot air and the material, allowing a large calorific value, Ua = 2,100 to 7,500 KJ/m3hr℃, which transfers from the hot air to the material.
• Large hold-up available
  It is possible to provide 15 to 20% of hold-up compared to 10% with other types of rotary dryers, making it possible to reduce the volume of the dryer.
• Minimized material destruction
  This dryer has no process to lift the materials up and down with a lifting wing, suppressing the destruction of the material particles.
• Less wear of vanes
  This dryer has no process to lift the materials up and down with a lifting wing, minimizing the wear of the vanes.
• Minimized uneven drying
  Superb mixing of materials is provided through the rotation and aeration, enabling you to get homogeneous products with uneven drying minimized.
• Drying possible to low moisture content
  Possible extended residence time (some for 3 hours) enables the materials to be dried up to extremely low moisture content.
• A constant rate of hot air can be fed in the material layer.
• Drying and cooling can be performed in a single unit.

Construction



Application

Sugar, coke, and flat soybeans

Synthetic resin pellets

Wood chip and pulp waste

Coal and blast furnace slag

Manufacturer: KURIMOTO

This dryer serves to layer materials up to 30 to 100 mm in thickness on the band comprised of wire mesh or perforated sheet and perform drying by feeding hot air from the top or the bottom at right angles to the materials layered.

Features

Evenly dried products are discharged.
This dryer is used to dry formed materials, enabling you to get homogeneous products with uneven drying diminished.

Products of low moisture content are discharged.
Extended contact time makes it possible to dry materials of high internal moisture up to considerably low moisture content.

Minimized material destruction
Materials are dried in a state of packed layer, enabling you to get products with minimized particle destruction.

Short drying time
Compared to concurrent-flow compartment dryers, you are able to finish drying step in far shorter period of time.

Reduced floor space for drying
Materials can be layered thick in a state of packed bed for shorter drying time, reducing the floor space required for drying as well as the volume of the equipment.

Diminished flying of materials
Materials are dried as they are left at rest to diminish their flying, enabling you to cut the costs of flue gas treatment.

Construction

The above figure shows an example of sludgy materials forming and drying system. Materials formed through the pelletizer are stacked in layers on the conveyor screen to enter the drying chamber, where the materials, while passing to the outlet, are dried with hot air forcibly ventilated from the top through the bottom of the material layers.

Application

Fibrous materials

Solids forming of sludgy materials

Calcium carbonate and magnesium carbonate

Titanium oxide, white carbon, and carbon black

Synthetic resin pellets

Manufacturer: KURIMOTO

Mainly used to crush objects above coal sieves.

Features

Ring hammer

The ring hammer forcedly discharges wet crushed product using the extrusion force generated by the hammer’s rotation during crushing.

Applications

Cement plants (Used to crush limestone, clay, clinker, plaster, etc.)

Civil engineering and construction (Used to manufacture concrete aggregate and road gravel)

Ceramics (Used to crush glass, cullet, old bricks, etc.)

Thermal power plants (Used to crush coal)

Structral Diagram

Specifications

Manufacturer: KURIMOTO

Model: KSF-02, KSF-03, KSF-04

The SF Sharp Cut Separator is a centrifugal, pneumatic classifier making it possible to classify particles of up to 0.3 mm. On the SF Sharp Cut Separator, the cylindrical squirrel-cage rotor with multiple blades arranged in a radical pattern in order to classify, seal, and discharge fine particles rotates at a high speed to generate the centrifugal force due to rotary airflow and the centripetal force due to suction air, fixing up the cut size in balance between the centrifugal and centripetal forces.

Features

Enable to classify submicron particles.
Reduce the secondary air consumption due to the introduction of the closed seal chamber.

Provide isolation-free particle size distribution.

Provide a sharp particle size distribution.

Minimize wear contamination.

Diminish the power consumption due to self-suction seal air

Construction

Typical Flow Sheet

Specifications

Applications

Silicon nitride

Talc

Special glass

Aluminum oxide

Toner

Calcium carbonate

Silicon

New materials and others

Manufacturer: KURIMOTO

Model: C2F-25W

Accommodate the Specifications in accordance with Customers’ needs for Optimum Operation

C2F Series perform stable operation and a varieties of Options can be added to suit for your needs and requirement.
High rigid frame structure achieves very precise and constant forging operation.

Features

High-Rigidity and High-Precision Structure

Upper Frame, Upright, and Lower Frame are tightened by Four Tie Rods to be very Rigid Frame Structure.

Wide Range of Allowable Eccentric Load

Adoption of 2 Point Connecting Rods allows very wide Allowable Eccentric Load which contributes Forged Parts Accuracy Improvement.

KURIMOTO’s Patented Slide Adjustment / Stick Release Device

Simple and Reliable Structure with Simple Operation

Automatic Slide Adjustment Device – Achieve High Precision

Combination of Hydraulic Cylinder and Eccentric Wrist Pin enable adequate die height adjustment during high speed operation to resolve the Forged Parts Accuracy Issue.

Easy Maintenance

Press Main keeps clean with Oil Lubrication.  It is circulated type which allows collection / re-use.  Hard Plate is being used on Slide Gib for KURIMOTO Press to maintain long preciseness.  For Clutch and Brake, Block type Friction Material is being use for ease use and longevity.

Applications

Hot / Warm Forged Parts

Non-ferrous (Aluminum) Forged Parts

Options

Optional accessories to Press

Load meter with over load sensor

Thermometer for journals & con-rods with alarm

Adaptor plate

Bolster plate

Peripheral Devices

Other options and various kind of peripheral devices are available.

Automatic Transfer System

The simplified structure contributes to better maintainability.

The ball screw ensures high-accuracy and high-speed transfer with back-lash less.

The servo control provides the optimum transfer motion for particular product and simplify setting and selection of the die lubrication pattern.

Left/Right and Front/Rear boxes are independently positioned.

Layout flexibility around loading and unloading is greatly improved.

Material Supply System

Can be customed to accommodate specific product, transfer speed and applications.

Can be designed to incorporate an optional servo system.

Accommodates optional design variations such as vertical-horizontal combination transfer.

Die Lubrication System

The timing of servo-driven movable nozzle is synchronized with the automatic transfer system.

This ensure the most efficient due lubrication, thus extending die service life.

Quick Die Changer (QDC) System

We offer a variety of systems including T-type,V-type, I-type and F-type to accommodate diverse facility layouts.

Specification

Capacity: 30MN (3000 ton)

Sample Forging Parts: Bearings

Manufacturer: KURIMOTO

Features

Cable protection pipe, which is superior in strength, corrosion resistance and workability, is widely used by the electric power companies all over Japan.

Manufacturer: KURIMOTO

Features

External pressure pipes (compliant with ‘JSWAS K-2’ of the Japan Sewage Works Association) are superior acid resistance, earthquake resistance, water-tightness and resistance against external pressure, These characteristics make it suitable for use as sewerage pipe, For sewer construction in a heavily-trafficked urban center where open excavation cannot be applied, jacking pipes are used.

Manufacturer: KURIMOTO

Model: RE-30

Features

Valve size 100 – 300mm (4″ – 12″)

As soon as the hydraulic pressure in the water main connected to a tank abnormally lowers due to the damage by disaster such as an earthquake and other trouble, the valve detects the pressure difference and shuts off water supply to the tank to change water flow and keep clean water in the tank.

Manufacturer: KURIMOTO

Flow control valve to reduce cavitation and noise at high differential pressure

Features

Orifice butterfly valve controls flow at high differential pressure
1. Anti-cavitation structure
Achieves flow control at high differential pressure by multiple distributed
nozzles which divide the flow at all opening degrees.
2. Low noise
Possible to modulate the flows at high flow rate without making noise.
3. Light and compact
More compact than sluice and globe valves by adopting the butterfly valve
structure.
4. Water sealing by rubber seat
Has excellent water sealing, same as the JWWA B 138 butterfly valve.

Merit

1. Standard Butterfly valve

As the valve opens, a crescent shape opening gets bigger.
2. Multi-hole variable orifice valve
The breakdown of flow in to multiple small jets reduces noise and makes throttling more effective with less cavitation, even as the valve opens up.
3. Orifice butterfly valve
Cavitation is suppressed by multiple distributed nozzles which divide flow and the valve opens . This can achieve higher performance than multi-hole
variable orifice valves.

Specification

Manufacturer: KURIMOTO

Features

Vibrations

Kurimoto manufactures vibrating screens suitable for a wide variety of applications from large blocks of raw stone to fine particles.
Available in the KI (Inclined) and KH (Horizontal) Series. The best suited model and size can be selected according to operating conditions.

Application

Specification

Note
1）Irregular sized screens other than this table are also available.
2）The Electric motor power output indicates general values and they are subject to change by the use conditions.

Manufacturer: KURIMOTO

Model: 50NXC-5S, 50NXC-4S, 50NXC-3S, 50NXC-2S, 50NXC-S

Best and most reliable secondary crusher
Secondary crusher with a high reduction ratio

Features

High reduction ratio and crushing to product of excellent particle shape

(Unique shape of crushing chamber and large eccentric stroke)

Spiderless structure reduces the risk of bridges.
Setting and adjustment using hydraulic power

Visualization of worn depth of liner

Numerous deliveries

Application

Manufacturer: KURIMOTO

Model: 4830ST, 4842ST, 6048ST, 7254ST, 8460ST

Robust, highly reliable crusher for primary crushing!

Commonly used for primary crushing of large blocks of raw stone.

Features

Wear resistance

Jaw plate made of robust materials of high wear resistance in a rational profile

Crushing

Deep crushing chamber facilitates biting of large blocks and deliver a large crushing capacity.

Frame structure

Robust frame structure made of thick steel plate

Outlet clearance adjustment with hydraulic jack

Easy-to-handle outlet clearance adjustment system using a hydraulic jack

Roller bearing and grease lubrication system

Bearing structure with combined use of roller bearings of sufficient capacity and a highly reliable grease lubrication system

Application

Double-toggle crusher designed particularly to crush a large amount of robust raw stone. Offers outstanding durability.

Specifications

Manufacturer: KURIMOTO

By combining the MRCP Roll Compactor with two-shaft self-cleaning type kneading machine to have raw materials intruded between the rolls, you can gain a variety of features, which could not be provided with previous dry-type compression granulating machines

Features

The MRCR Roll Compactor has a two-shaft self-cleaning type screw, which maintains stability of processing capability even with adherent materials.

Screws are segmented for ease of replacement when worn and torn.

By installing kneading paddles, you can achieve adding binder and granulation in one system.

The MRCR Roll Compactor is available for mixing, compression, and de-gassing as the pretreatment equipment for kneading machines, enabling you to increase the kneading capacity.

Applications

Chemical Industry : Plastics (e.g. phenol, urea, and melamine)

Electronics : Ferrite, toner, and paints

Pharmaceuticals : Chinese medicine, antibiotics, and others

Food products : Seasonings, condiments, and food additives

Fertilizers : Lime, chloride of potash, ammonium chloride, and compound fertilizers

Agricultural chemicals : Herbicides and insecticides

Inorganic substance : Purified talc, lime, and clay

Specifications

Typical Flow Sheet

Manufacturer: KURIMOTO

This machine is an indirect heating type of rotary kiln using electricity, heavy oil, or gas as the heat source. The shell, due to its equilateral hexagonal cross section, minimizes the “shear” of the material layer to provide a sharp distribution of residence time, enabling you to get stable and high quality products of uneven firing.

Features

Equilateral hexagonal shell employed (Refer to Figure-1.)
Compared to cylindrical shell, this shall provides less “shear” of the material layer, a sharp distribution of residence time, and less uneven calcining, increasing the material holding ratio to make the equipment compact in size.

(Figure-1 Comparison of kiln action)

Introduction of superb air sealing performance and special sealing construction enables sealing up to a maximum of pressure of kiln internal pressure±500Pa.

Besides oxidized (i.e., in the air) or neutral (i.e., nitrogen gas or carbon dioxide gas) gas, reducing gas can be used.
Carrier gas or reaction gas can be charged thanks to the improved sealing performance.

Severe calcining temperature control enabled
The calcining temperature is directly measured with sheathed thermocouples inserted in the material layer.
Introducing the multi-chamber type of electric furnace enables independent temperature control of each chamber.
The material temperature is selectable up to a maximum of 1000ºC. Furthermore, if you use gas or heavy oil as the heat source, please introduce the hot air circulation system for energy savings.

Easy settings of residence time
The shell speed varies with the use of the variable speed motor (10:1). Furthermore, variable inclination system is also available for the shell.

Easy installation
The retort, heating oven, and feeder are set up on the common platform, facilitating the installation work. Small-sized kilns come with casters (wheels) for relocation use.

Application

Operation
Drying, pre-calcining, high temperature reaction, and heat treatment
Superb air-tightness enables application to the high temperature reaction process of various kinds of powders in an acid, neutral, or reducing atmosphere.

Heating temperature and material of shell (retort)
300ºC to 1200ºC
Various kinds of stainless steel, Inconel, hastelloy, or heat resisting cast iron (Kurimoto Thermalloy) is used for the shell with consideration given to resistance to heat and corrosion.

Heat source
Electricity (standard), gas, or heavy oil

Objects
The rotary kiln is available for the processing of fine chemical materials up to micron order in size including pigments, ferrite, active carbon, carbon black, various kinds of ceramic materials, powder and particles such as industrial chemicals, and pellets.

Specifications

Typical Flow Sheet

Manufacturer: KURIMOTO

Model: RCP-110K, RCP-150K

Offers higher bulk specific gravity. (Materials can be processed without being bulky.)

Maintains stability of bulk specific gravity.

Improves liquidity. (It facilitates constant feeding, weighing, and others.)

Eases the system handling.

Prevents materials from scattering (i.e., improves the working environment).

Facilitate mixing of materials.

Provides smooth melting of materials (in other words, hardly forms lumps of materials)

Features

Simplified manufacturing process
By dry-process granulation, you require no humidification and drying stages.

Minimal transformation
This system is the best-suited to granulate materials which are unstable to water or solvent and subject to thermal transformation.

High-density products
By compaction with pressure rollers, you can produce high-density particles and granulated powder.

High compression force
The Kurimoto High-pressure Type Roll Compactor offers larger compression force, enabling you to produce high-density and high-intensity products.

Soft granulation
Even though the hydraulic cylinder is used to apply compression force, since the operative pressure of the hydraulic cylinder can be easily adjusted, you are able to reduce the compression force for soft granulation.

Incorporation of high-performance screw
The screw performance exerts a significant influence upon the granulating capability of the Roll Compactor.
The Roll Compactor has a high-performance screw, which have materials intruded between the rolls to facilitate de-gassing.

Efficient crushing and granulation
By freely varying combination of breakers, several types of granulators for fine particle and sizing use, and granulators with screen, you can efficiently get a target particle size.

Construction

Specifications

Manufacturer: KURIMOTO

Model: BX284E-H/BX384E/BX1144E

The Kurimoto High G consists of a main unit which revolves and mill pots which rotate in the same and opposite directions. You should put grinding medium (usually small-diameter balls) and material in the rotating mill pot to move the balls applying centrifugal force generated during revolution and rotation for processing (i.e., grinding).
The name, “Planetary Mill”, is derived from the mill pot’s revolution and rotation like the sun-and-planet motion.

Features

Only one reversible mill available in the world (Source: Our survey)

Powders are processed with large energy from small-diameter balls.

Significantly shortened processing time (up to 1/10 of that with conventional mills).

Low vibration and low noise

Can be upsized. (We can see large-sized mills becoming operational.)

Motion of balls determined through the analysis of computer simulation

Construction

Typical Flow Sheet

Specifications

Applications

Mechano-chemical reaction

Mechanical alloying (MA)
This is a production method of new materials only with which several kinds of mixed element powders are alloyed only by milling them.

Dry- and wet-process grinding

Dispersion

Particle compounding, and others

Manufacturer: KURIMOTO

Model:TES-30M

Features

By using 10-axis AC servomotors, the beams at both sides are mounted in individual box.

It can offer wide, free spaces for both start and end of the forging process.

Manufacturer: KURIMOTO

Features

Polycon FRP pipes for a pressure pipeline (compliant with ‘JIS A5350’ of the Japan Standards Association) are used as agricultural water pipe, penstock, and so on.

Manufacturer: KURIMOTO

Model: C2F-63

Accommodate the Specifications in accordance with Customers’ needs for Optimum Operation

C2F Series perform stable operation and a varieties of Options can be added to suit for your needs and requirement.
High rigid frame structure achieves very precise and constant forging operation.

Features

High-Rigidity and High-Precision Structure

Upper Frame, Upright, and Lower Frame are tightened by Four Tie Rods to be very Rigid Frame Structure.

Wide Range of Allowable Eccentric Load

Adoption of 2 Point Connecting Rods allows very wide Allowable Eccentric Load which contributes Forged Parts Accuracy Improvement.

KURIMOTO’s Patented Slide Adjustment / Stick Release Device

Simple and Reliable Structure with Simple Operation

Automatic Slide Adjustment Device – Achieve High Precision

Combination of Hydraulic Cylinder and Eccentric Wrist Pin enable adequate die height adjustment during high speed operation to resolve the Forged Parts Accuracy Issue.

Easy Maintenance

Press Main keeps clean with Oil Lubrication.  It is circulated type which allows collection / re-use.  Hard Plate is being used on Slide Gib for KURIMOTO Press to maintain long preciseness.  For Clutch and Brake, Block type Friction Material is being use for ease use and longevity.

Manufacturer: KURIMOTO

Model: C2F-50

Accommodate the Specifications in accordance with Customers’ needs for Optimum Operation

C2F Series perform stable operation and a varieties of Options can be added to suit for your needs and requirement.
High rigid frame structure achieves very precise and constant forging operation.

Features

High-Rigidity and High-Precision Structure

Upper Frame, Upright, and Lower Frame are tightened by Four Tie Rods to be very Rigid Frame Structure.

Wide Range of Allowable Eccentric Load

Adoption of 2 Point Connecting Rods allows very wide Allowable Eccentric Load which contributes Forged Parts Accuracy Improvement.

KURIMOTO’s Patented Slide Adjustment / Stick Release Device

Simple and Reliable Structure with Simple Operation

Automatic Slide Adjustment Device – Achieve High Precision

Combination of Hydraulic Cylinder and Eccentric Wrist Pin enable adequate die height adjustment during high speed operation to resolve the Forged Parts Accuracy Issue.

Easy Maintenance

Press Main keeps clean with Oil Lubrication.  It is circulated type which allows collection / re-use.  Hard Plate is being used on Slide Gib for KURIMOTO Press to maintain long preciseness.  For Clutch and Brake, Block type Friction Material is being use for ease use and longevity.

Manufacturer: KURIMOTO

Kurimoto’s Apron Feeders offer a wealth of variations that meet diverse applications.

Features

Special heavy-duty model (Robust design)

Allows for stable continuous operation with some leeway even under harsh conditions.

Powerful (lightweight, compact, and yet high-performance) model

Lightweight, compact, and yet high-performance feeder suitable for feeding medium and small blocks of raw materials

Standard model

Constant-volume feeder suitable for feeding small blocks of raw materials

Application

Crushed stone

Limestone

Coal

Iron ore

Specification

Note
1）The performance shown above is related to the case where raw materials of apparent apecific gravity 1.6t/m³ are continuously supplied.The conveying capacity and the output of motor increase according to the length of machine and the apron speed.
2）As a rule, this machine employs variable speed operation.
3）Motor output（kW）includes efficiently of reducer,variable speed gear and transmission.
4）Inclination angle is standardized at 8^° overhead.
5）Grizzly opening shall be set to the thickness of feed size.

Manufacturer: KURIMOTO

Model: 6004, 6008, 6010, 6012, 7205, 7209, 7212

Offers extraordinary crushing capacity and ease of maintenance!

Features

Large crushing capacity

A large eccentric stroke (throw) and the unique shape of the crushing chamber deliver large crushing capacity and end-products of excellent particle shape.

Stable operation

Because there is no spider arm, operation precedes continuously and stably without concerns over bridging caused by a large block of raw stone.

Substantial reduction in running costs

The unique shape of the crushing chamber enables the mantle bowl liner to be used effectively. Moreover, no consumable parts such as an upper arm protector, upper bearing or seal are used. This achieves a substantial reduction in running costs.

Simple operation

Simple switch operation facilitates setting and adjustment. The worn depth of the bowl liner can be checked from the control panel.

Application

Crushing for stone or ore

Specifications

Model: 40NXC-5S, 40NXC-4S, 40NXC-3S, 40NXC-2S, 40NXC-S

Best and most reliable secondary crusher
Secondary crusher with a high reduction ratio

Features

High reduction ratio and crushing to product of excellent particle shape

(Unique shape of crushing chamber and large eccentric stroke)

Spiderless structure reduces the risk of bridges.
Setting and adjustment using hydraulic power

Visualization of worn depth of liner

Numerous deliveries

Application

Manufacturer: KURIMOTO

Direct heating type rotary dryer
This is a direct heating type of dryer that brings materials into direct contact with hot air to dry them by lifting them up inside the rotary shell

If you use materials that are easily affected by contact with combustion gas.

If you need to minimize the amount of exhaust gas from the dryer.

If you use materials that are apt to produce dust.

If you use materials that are easily affected by oxidation.

If you need to recover volatile component.

Construction

The main unit of the rotary dryer is an inclined shell supported by four rollers. Materials, which are fed through one end of the shell, move inside the shell along the inclination of the shell and through the rotary movement and are discharged from the other end. Materials, while moving inside the shell, are lifted up by a lifter incorporated in the shell. Then, the materials fall evenly in the shell space and exchange heat with the hot air flowing through the space to dry. Depending on the method of providing hot air for the materials, this dryer is classified into two types, that is, concurrent flow drying type by which the hot air and materials flow in the same direction and countercurrent flow drying type by which they flow in the opposite direction.
Lifter
The lifter is the most critical part having an influence on the performance of the dryer, which provides uniform dispersion of materials in the shell space. Any of the constructions shown below is used according to the physical properties of materials. Furthermore, spiral lifters designed with consideration of forced feeding of materials are used for the material feeding end.

Adjustment of residence time
By providing dams according to the applications, the materials residence time can be adjusted.

Prevention of adhesion and accumulation
In order to handle materials of high adhesive property, chains are provided in the shell or a hammering unit is provided externally on the shell, thus preventing material adhesion and accumulation.

Concurrent flow and countercurrent flow
Concurrent flow drying type
With the concurrent flow drying type, the materials move and the hot air flows in the same direction. Therefore, the hot air of the highest applicable temperature comes in contact with materials of the lowest applicable temperature at the end of the material inlet of the rotary shell. Normally, the concurrent flow drying type is used for the following conditions.

Countercurrent flow drying type
With the countercurrent flow drying type, the relation of flow direction and temperature between the hot air and the materials becomes reverse equivalent of the concurrent flow drying type. Therefore, this type is used especially in the case that low-moisture products are required, taking advantage of its characteristic that the hot air of the highest applicable temperature comes in contact with materials of the lowest moisture at the end of the material outlet.

Application

Concurrent flow drying type

Countercurrent flow drying type

Manufacturer: KURIMOTO

Model:TES-25

Features

It can achieve the simple and compact body by adapting rack & pinion

Manufacturer: KURIMOTO

Model: BT-SH

Features

Valve size 300 – 2000mm (12″ – 80″)

It has a spherical disc and is used as turbine inlet valve of Hydro power station.
It is used for high head.

Manufacturer: KURIMOTO

Features

Valve size 400 – 1500mm (16″ – 60″)

When such an emergency should arise as an earthquake or earth-avalanche damaging pipelines or their deterioration in use, Kurimoto’s emergency shut-off valve would not only automatically, safely and quickly shut off the affected pipeline, thereby securing the valuable water supply, but preclude the secondary disaster from effluent.
The emergency shut-off valve comprises a valve body, locking device, self-closing device(weight), hydraulic shock absorber, actuator etc., and the valve body is fabricated in conformity with JIS-B-2064 Butterfly valve for water service. It has a valve closing system including a line abnomality detector, also provided with a control panel incorporating the system operation check function for normal operation.

Manufacturer: KURIMOTO

Model: KHB-5, KHB-6, KHB-9

Demonstrates good performance in crushing coal!

The Hammer Crusher is an impact crusher designed to repeatedly crush raw material between a beater head rotating at high speeds and breaker plates.

Features

Excellent crushing performance

A number of hammers deliver an outstanding crushing effect.

Longer-lasting consumable parts

The consumable parts are made of high chromium cast iron from Kurimoto, a manufacturer of wear-resistant special steel, to extend their service life.

Reversible system

This system doubles the continuous operation time of consumable parts compared to conventional systems.

Support for raw materials of comparatively high moisture content

The unique structure enables crushing of raw materials of comparatively high moisture content.

Compact design

Compact design saves space.

Applications

Manufacturer: KURIMOTO

Features

Easily ensures the desired crushed particle size.
Suitable for fine crushing

More suited for fine crushing than top feed type.

Uniform particle size

The grate bar minimizes the effects of raw stone size and shape on the crushed particle size.

Extremely high reduction ratio

Applications

Cement plants

(Used to crush limestone, clay, clinker, plaster, etc.)

Civil engineering and construction

(Used to manufacture concrete aggregate and road gravel)

Glass and ceramics

(Used to crush raw stone, cullet, old bricks, etc.)

Thermal power plants and gas plants

(Used to crush coal)

Structral Diagram

Specifications

Manufacturer: KURIMOTO

Features

This device can shear the billet by sharp blades with less distortion.
