The post Miyakawa MArX-MB Pneumatic Chamfering Machine first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan

Manufacturer: Miyakawa

Model: MArX: MArX-MB, MArX-MB-Z, MArX-MB-K

Product Video

Specification

Model MArX-MB MArX-MB-Z MArX-MB-K
Types of chamfers R3
Initial Chamfer amount setting equivalent to R 2.5 mm (Note 1)
(Option: Ｃ1、Ｃ2) (Note 2）		 R4
Initial Chamfer amount setting equivalent to R 3.0 mm (Note 1)		 R4
Initial Chamfer amount setting equivalent to R 3.3 mm (Note 1)
Inserts Exclusive carbide insert (3R) Exclusive carbide insert (4R) Exclusive carbide insert (4R)
Min. chamfered thickness 9mm 9mm 9mm
Min. processing radius R17 (In the case of R3) R17 (In the case of R3) R17 (In the case of R3)
Cutter 3-Blades 3-Blades 3-Blades
No-load rotational speed 10,000 min-1 (Approx.)(Note 3) 10,000 min-1 (Approx.)(Note 3) 10,000 min-1 (Approx.)(Note 3)
Working pressure 0.49～0.68Mpa 0.49～0.68Mpa 0.49～0.68Mpa
Air consumption 0.86ｍ3/min 0.86ｍ3/min 0.86ｍ3/min
Weight 3.3kg (Approx.) 3.3kg (Approx.) 3.3kg (Approx.)

MArX-MB型

MArX-MB仕様



The post Miyakawa MArX-MB Pneumatic Chamfering Machine first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa MGR-100 Chamfer Machine https://koueitrading.com/global/product/miyakawa-mgr-100-chamfer-machine/ Thu, 11 Mar 2021 01:10:07 +0000 https://koueitrading.com/global/?post_type=product&p=423 Product Made in Japan Manufacturer: MIYAKAWA Model: MGR-100 Features Enhanced Rigidity: The machine’s design accommodates large surfaces, such as R5 and C5, ensuring stable and precise chamfering operations. Versatile Chamfering Capabilities: While the standard setup is for R3 chamfering, the MGR-100 allows for other chamfering tasks by replacing optional components like chips, center rollers, liners, […]

The post Miyakawa MGR-100 Chamfer Machine first appeared on Kouei Japan Trading | Get Quotation.]]> Product Made in Japan
Manufacturer: MIYAKAWA
Model: MGR-100

Features

  • Enhanced Rigidity: The machine’s design accommodates large surfaces, such as R5 and C5, ensuring stable and precise chamfering operations.

  • Versatile Chamfering Capabilities: While the standard setup is for R3 chamfering, the MGR-100 allows for other chamfering tasks by replacing optional components like chips, center rollers, liners, and the body.

  • High Power Output: Equipped with a 720W motor, the machine delivers stable chamfering performance, requiring it suitable for demanding tasks such as R chamfering of steel sheets used in shipbuilding and bridge construction.

  • Chamfering Range: The MGR-100 can handle chamfer abilities ranging from R2 to R5 and C1 to C5, providing flexibility for various project requirements.

  • User-Friendly Operation: The machine’s design emphasizes ease of use, allowing for efficient operation without the need for extensive setup or clamping mechanisms.

For Shipbuilding, Bridge
[Model: MGR-100]

Performance Specification

Feature Specification
Bevelling Amount R (R2,R3,R4,R5) (C1,C2,C3,C4,C5)
Min. Plate Thickness 9mm
Min. Processing Radius R17
Power Supply 100V, 50/60Hz
Electric Motor Single-phase series commutator motor
No-Load Spindle Speed 9,300 min^-1
Full-load Current 7.3 A
Electric Power 720W
Cutter 3-inserts cutter (Clockwise rotation)
Inserts Carbide inserts (3 pcs)
Weight 3.3 kg (Without cord)(Approx.)

Features:
Rigidity up to support the large bevelling [i.e., R5 ● C5].

This unit is a product only for R3 bevelling but, by exchanging form the options like inserts, center roller, liner and body orther hamfering is also possible. Please contact us for the option requirements.

Beveller Type Standard Bevelling Amount
R3 2.2 ~ 2.5 mm
R2 1.2 ~ 1.5 mm
R4 3.2 ~ 3.5 mm
R5 4.2 ~ 4.5 mm
C1 1.0 ~ 1.2 mm
C2 2.0 ~ 2.2 mm
C3 3.0 ~ 3.2 mm
C4 3.8 ~ 4.1 mm
C5 4.8 ~ 5.0 mm



*Note 1 This bevelling amount is only for when the element surface angle is 90°.

  • Please be sure to read the operation manuals for your secure use of this model.
  • The contents of this catalog are subject to change without notice.



The post Miyakawa MGR-100 Chamfer Machine first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa Roll splitter https://koueitrading.com/global/product/miyakawa-roll-splitter/ Sat, 26 Sep 2020 10:11:52 +0000 https://koueitrading.com/global/?post_type=product&p=37946 Product made in Japan Manufacturer: Miyakawa Specification: Dimension:

The post Miyakawa Roll splitter first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa

Specification:

Dimension:



The post Miyakawa Roll splitter first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa InDie360 Press tap device https://koueitrading.com/global/product/miyakawa-indie360-press-tap-device-indie360/ Sat, 26 Sep 2020 10:07:30 +0000 https://koueitrading.com/global/?post_type=product&p=37943 Product made in Japan Manufacturer: Miyakawa Overview: Tapping device in progressive press. Specification: Structure: Dimension:

The post Miyakawa InDie360 Press tap device first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa

Overview:

Tapping device in progressive press.

Specification:

Structure:

Dimension:

The post Miyakawa InDie360 Press tap device first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa Oxide film remover https://koueitrading.com/global/product/miyakawa-oxide-film-remover/ Sat, 26 Sep 2020 10:04:48 +0000 https://koueitrading.com/global/?post_type=product&p=37941 Product made in Japan Manufacturer: Miyakawa Overview: Simultaneous removal of aluminum oxide film on top and bottom surfaces.

The post Miyakawa Oxide film remover first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa

Overview:

Simultaneous removal of aluminum oxide film on top and bottom surfaces.

The post Miyakawa Oxide film remover first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa MPAR-1 Deburring/Film Removal Equipment https://koueitrading.com/global/product/miyakawa-mpar-1-deburring-film-removal-equipment/ Sat, 26 Sep 2020 10:00:07 +0000 https://koueitrading.com/global/?post_type=product&p=37938 Product made in Japan Manufacturer: Miyakawa Model: MPAR-1 Specification Item Specification Rotation Speed 6000 min⁻¹ ~ 10000 min⁻¹ Power Consumption 350 W Power Supply 100 V 50/60 Hz Rating 30 minutes Cord Length 2.4 m Weight 1.13 kg (including cord) Usage examples (6 of shaft diameter):

The post Miyakawa MPAR-1 Deburring/Film Removal Equipment first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: MPAR-1

Specification

Item Specification
Rotation Speed 6000 min⁻¹ ~ 10000 min⁻¹
Power Consumption 350 W
Power Supply 100 V 50/60 Hz
Rating 30 minutes
Cord Length 2.4 m
Weight 1.13 kg (including cord)

Usage examples (6 of shaft diameter):

MPAR-1

The post Miyakawa MPAR-1 Deburring/Film Removal Equipment first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa MYK-1 Deburring/film removal equipment https://koueitrading.com/global/product/miyakawa-myk-1-deburring-film-removal-equipment/ Sat, 26 Sep 2020 09:43:49 +0000 https://koueitrading.com/global/?post_type=product&p=37935 Product made in Japan Manufacturer: Miyakawa Model: MYK-1 Features: Heavy cutting work, black scale removal ・Polishing of difficult-to-cut materials such as titanium and aluminum ・Grinding of transportation vehicles (hairline, etc.) ・Peeling of plating and paint ・Rust removal and other general polishing Structure Body: MYK-1×1 unit Abrasive belt x 2 types CBN belt x1 L-shaped guide […]

The post Miyakawa MYK-1 Deburring/film removal equipment first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: MYK-1

Features:

Heavy cutting work, black scale removal
・Polishing of difficult-to-cut materials such as titanium and aluminum
・Grinding of transportation vehicles (hairline, etc.)
・Peeling of plating and paint
・Rust removal and other general polishing

Structure

Body: MYK-1×1 unit

  • Abrasive belt x 2 types
  • CBN belt x1
  • L-shaped guide x1
  • Coupler x1
  • Oil x1

Specification:

Optional abrasives (various types will be available as other options)

CBN scale belt

◆ Aggregate abrasive grains of CBN abrasive grains (high hardness abrasive grains) open (sparsely) coated
It is a product.
◆ Hard scale removal of iron plate and steel frame
◆ Heavy grinding of difficult-to-cut materials

Cute belt

Heavy Duty Abrasive Belt
Maintains high polishing power.
◆ Metal Grinding Polishing
◆ Strong rust removal and paint removal
◆ Stainless steel grinding and polishing
The post Miyakawa MYK-1 Deburring/film removal equipment first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa Mist coolant device https://koueitrading.com/global/product/miyakawa-mist-coolant-device/ Sat, 26 Sep 2020 08:40:34 +0000 https://koueitrading.com/global/?post_type=product&p=37924 Product made in Japan Manufacturer: Miyakawa Overview: A device that atomizes cutting fluid and feeds it to the cutting edge, improving cutting performance and removing chips. Feature Equipped with a liquid level sensor and a pressure sensor to detect running out of cutting fluid and air. Since mist is supplied directly to the cutting edge, […]

The post Miyakawa Mist coolant device first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa

Overview:

A device that atomizes cutting fluid and feeds it to the cutting edge, improving cutting performance and removing chips.

Feature

  • Equipped with a liquid level sensor and a pressure sensor to detect running out of cutting fluid and air.
  • Since mist is supplied directly to the cutting edge, cutting conditions are improved and the life of the cutting tool is extended.
  • Only 47ml of cutting fluid is used per minute, which not only leads to cost reduction, but also improves the work environment by reducing dirt in the work area.

Difference from conventional mist device

  • Since the cutting fluid is atomized inside the device and supplied to the cutting edge, it can also be used for oil hole drills.
  • Cutting fluid hose can be lengthened (up to 20m)
  • Conventional cutting fluid can be used
The post Miyakawa Mist coolant device first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa M1D Gantry type splicing machine https://koueitrading.com/global/product/miyakawa-m1d-gantry-type-splicing-machine/ Sat, 26 Sep 2020 08:40:31 +0000 https://koueitrading.com/global/?post_type=product&p=37923 Product made in Japan Manufacturer: Miyakawa Model: M1D Overview: Install the components and switch on.

The post Miyakawa M1D Gantry type splicing machine first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: M1D

Overview:

Install the components and switch on.

The post Miyakawa M1D Gantry type splicing machine first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa M1DA Drilling machine https://koueitrading.com/global/product/miyakawa-m1da-drilling-machine/ Sat, 26 Sep 2020 08:40:27 +0000 https://koueitrading.com/global/?post_type=product&p=37922 Product made in Japan Manufacturer: Miyakawa Model: M1DA Overview: Stack the parts and switch on. Automatically transported and automatic drilling.

The post Miyakawa M1DA Drilling machine first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: M1DA

Overview:

Stack the parts and switch on. Automatically transported and automatic drilling.

The post Miyakawa M1DA Drilling machine first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa M1G Drilling machine https://koueitrading.com/global/product/miyakawa-m1g-drilling-machine/ Sat, 26 Sep 2020 08:39:32 +0000 https://koueitrading.com/global/?post_type=product&p=37921 Product made in Japan Manufacturer: Miyakawa Model: M1G Overview: Automatic drilling of steel plates for bridges/aircraft.

The post Miyakawa M1G Drilling machine first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: M1G

Overview:

Automatic drilling of steel plates for bridges/aircraft.

The post Miyakawa M1G Drilling machine first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa MRAS-600 R chamfering system https://koueitrading.com/global/product/miyakawa-mras-600-r-chamfering-system/ Sat, 26 Sep 2020 08:24:46 +0000 https://koueitrading.com/global/?post_type=product&p=37916 Product made in Japan Manufacturer: Miyakawa Model: MRAS-600 Overview: This is a fully automatic system that performs R surface processing on the edges of steel plates and splint plates up to 400mm x 400mm.

The post Miyakawa MRAS-600 R chamfering system first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: MRAS-600

Overview:

This is a fully automatic system that performs R surface processing on the edges of steel plates and splint plates up to 400mm x 400mm.



The post Miyakawa MRAS-600 R chamfering system first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa MCSIC R chamfering system https://koueitrading.com/global/product/miyakawa-mcsic-r-chamfering-system/ Sat, 26 Sep 2020 08:24:44 +0000 https://koueitrading.com/global/?post_type=product&p=37915 Product made in Japan Manufacturer: Miyakawa Model: MCSIC Overview: This is a fully automatic system that performs R surface processing on the edges of steel plates and splint plates.

The post Miyakawa MCSIC R chamfering system first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: MCSIC

Overview:

This is a fully automatic system that performs R surface processing on the edges of steel plates and splint plates.

The post Miyakawa MCSIC R chamfering system first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa RB-5S R chamfering system https://koueitrading.com/global/product/miyakawa-rb-5s-r-chamfering-system/ Sat, 26 Sep 2020 08:24:42 +0000 https://koueitrading.com/global/?post_type=product&p=37914 Product made in Japan Manufacturer: Miyakawa Model: RB-5S Overview R-face processing is performed on the edges of steel plates used as aggregates for bridges, steel frames, shipbuilding, etc. Feature Easy setup changeover for R-face machining and C-face machining Feed speed can be adjusted according to the material. Specification Chamfer type R3 (optional R2, C2, C1) […]

The post Miyakawa RB-5S R chamfering system first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: RB-5S

Overview

R-face processing is performed on the edges of steel plates used as aggregates for bridges, steel frames, shipbuilding, etc.

Feature

  • Easy setup changeover for R-face machining and C-face machining
    Feed speed can be adjusted according to the material.

Specification

Chamfer type R3 (optional R2, C2, C1)
Worked plate thickness 8mm to 36mm
Worked plate width 80mm to 500mm
Worked plate length 300mm to 4000mm
Power supply 3-phase 200V 3kVA
Cutter used 3 blades (1 each for right rotation and left rotation)
Chip used 3 Carbide R Chips x2
Number of rotations 2500/3000RPM 50/60Hz
Material feed speed 1500mm/min
Machine dimensions 1100mm×1450mm×1400mm
Machine weight about 750kg
The post Miyakawa RB-5S R chamfering system first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa ESA-3R electric handheld single-sided type https://koueitrading.com/global/product/miyakawa-esa-3r-electric-handheld-single-sided-type/ Sat, 26 Sep 2020 07:32:40 +0000 https://koueitrading.com/global/?post_type=product&p=37907 Product made in Japan Manufacturer: Miyakawa Model: ESA-3R Overview R chamfering can be done twice as fast as conventional products! Feature Equipped with a motor suitable for high-speed machining With one set-up, it automatically travels to the rear end of the material or the stopper to perform R chamfering. A special carbide tip is used […]

The post Miyakawa ESA-3R electric handheld single-sided type first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: ESA-3R

Overview

R chamfering can be done twice as fast as conventional products!

Feature

  • Equipped with a motor suitable for high-speed machining
  • With one set-up, it automatically travels to the rear end of the material or the stopper to perform R chamfering.
  • A special carbide tip is used to obtain an extremely smooth finished surface.
  • Easy tip replacement
  • It can be easily attached to the straight part of the steel plate.
Type of chamfers R3 (Option: R1, R2, C1, C2)
Processing plate thickness 9mm to 100mm
Working plate width 150mm or more (Rib height 100mm or more)
Cutter 3 blades (clockwise rotation)
Inserts Carbide R Tip
No-load rotational speed 4000RPM
Self-propelled speed 4500mm/min
Power Supply/ Output 3-phase 200V brushless DC motor 750W
Machine dimensions 250mm×320mm×505mm (605mm)
Weight 17.5kg Control panel (7kg) separately placed

Notes

In the case of R chamfering, please replace a special cutter (sold separately) and R1 or R2 special tip (sold separately)

In the case of C chamfering, please replace a special cutter (sold separately) and C1 or C2 special tip (sold separately).



The post Miyakawa ESA-3R electric handheld single-sided type first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa MWA-3R Electric self-propelled double-sided type https://koueitrading.com/global/product/miyakawa-mwa-3r-electric-self-propelled-double-sided-type/ Sat, 26 Sep 2020 07:32:38 +0000 https://koueitrading.com/global/?post_type=product&p=37906 Product made in Japan Manufacturer: Miyakawa Model: MWA-3R Overview For R-chamfering of long way! Self-propelled, any possible to make smooth R-chamfering on both upper and lower surfaces at the same time. Feature In a single installation, the machine automatically runs to the back end of the material or to the stopper, and performs R-chamfering on […]

The post Miyakawa MWA-3R Electric self-propelled double-sided type first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: MWA-3R

Overview

For R-chamfering of long way! Self-propelled, any possible to make smooth R-chamfering on both upper and lower surfaces at the same time.

Feature

  • In a single installation, the machine automatically runs to the back end of the material or to the stopper, and performs R-chamfering on both top and bottom surfaces at the same time.
  • Possible to make smooth finished surfaces by special carbide up.
  • Easy to change the tip.
  • Easily setting on the straight section of steel plate.
Type of chamfers R3 (Option: R1, R2, C1, C2)
Processing plate thickness 9mm to 50mm
Working plate width 200mm or more (Rib height 80mm or more)
Cutter 3 carbide R-tip (1 each for right-rotating and left-rotating)
Inserts Carbide R Tip
No-load rotational speed 2000/2400RPM 50/60Hz
Self-propelled speed 1275/1300mm/min 50/60Hz
Power Supply/ Output 3-phase 200V 1.6kVA
Machine dimensions 490mm×240mm×490mm
Weight 39.5kg

Notes

In the case of R chamfering, please replace a special cutter (sold separately) and R1 or R2 special tip (sold separately)

In the case of C chamfering, please replace a special cutter (sold separately) and C1 or C2 special tip (sold separately).



The post Miyakawa MWA-3R Electric self-propelled double-sided type first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa MSA-3R Electric self-propelled single-sided type https://koueitrading.com/global/product/miyakawa-msa-3r-electric-self-propelled-single-sided-type/ Sat, 26 Sep 2020 07:32:36 +0000 https://koueitrading.com/global/?post_type=product&p=37905 Product made in Japan Manufacturer: Miyakawa Model: MSA-3R Overview For R-chamfering of long way! Self-propelled, any possible to make smooth R-chamfering. Feature In a single installation, the machine automatically runs to the back end of the material or to the stopper, and performs R-chamfering. Possible to make smooth finished surfaces by special carbide tip. Easy […]

The post Miyakawa MSA-3R Electric self-propelled single-sided type first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: MSA-3R

Overview

For R-chamfering of long way! Self-propelled, any possible to make smooth R-chamfering.

Feature

  • In a single installation, the machine automatically runs to the back end of the material or to the stopper, and performs R-chamfering.
  • Possible to make smooth finished surfaces by special carbide tip.
  • Easy to change the tip.
  • Easily setting on the straight section of steel plate.
Type of Chamfers R3 (Option: R2, C1, C2)
Processing Plate Thickness 9mm to 50mm
Worked plate width 200mm or more (Rib height 80mm or more)
Cutter 3 blades (clockwise rotation)
Inserts Carbide R Tip
No-load rotational speed 2000/2400RPM 50/60Hz
Self-propelled speed 1275/1300mm/min 50/60Hz
Power supply/ output 3-phase 200V 0.8kVA
Machine dimensions 210mm×370mm×400mm
Weight 16kg

Notes

In the case of R chamfering, please replace a special cutter (sold separately) and R1 or R2 special tip (sold separately)

In the case of C chamfering, please replace a special cutter (sold separately) and C1 or C2 special tip (sold separately).



The post Miyakawa MSA-3R Electric self-propelled single-sided type first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa MAG-3R Air Self-propelled Type – Single-sided Type https://koueitrading.com/global/product/miyakwa-mag-3r-air-self-propelled-type-single-sided-type/ Sat, 26 Sep 2020 07:32:34 +0000 https://koueitrading.com/global/?post_type=product&p=37904 Product made in Japan Manufacturer: Miyakawa Model: MAG-3R Feature Lightweight and compact for easy handling and easy chamfering Employs a magnet method, setting is easy, and processing is possible even for members placed flat. Equipped with an air blower for removing facets specification Chamfer amount R3 Overlap processing minimum plate thickness 9mm Worked plate width […]

The post Miyakawa MAG-3R Air Self-propelled Type – Single-sided Type first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: MAG-3R

Feature

  • Lightweight and compact for easy handling and easy chamfering
  • Employs a magnet method, setting is easy, and processing is possible even for members placed flat.
  • Equipped with an air blower for removing facets

specification

Chamfer amount R3
Overlap processing minimum plate thickness 9mm
Worked plate width 150mm or more
Minimum machining radius R50
No-load speed 8,500 RPM*1
working pressure 0.49～0.68Mpa
air consumption 1.42m³/min
Cutter used 3 blades (clockwise rotation)
Chip used Carbide R Tip
weight 13.5kg

Notes

*1 Rotational speed varies depending on the usage environment.

The post Miyakawa MAG-3R Air Self-propelled Type – Single-sided Type first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakwa OPT-MII electric hand-held type with rotating backing plate https://koueitrading.com/global/product/miyakwa-opt-mii-electric-hand-held-type-with-rotating-backing-plate/ Sat, 26 Sep 2020 07:32:32 +0000 https://koueitrading.com/global/?post_type=product&p=37903 Product made in Japan Manufacturer: Miyakawa Model: OPT-MII Overview Smooth chamfering by rotating the backing plate! feature When replacing the tip, it can be replaced without removing the cutter (tip holder) The cutter can be easily replaced with a special tool. 4 types of chamfering available By installing a slag prevention roller (option), it is […]

The post Miyakwa OPT-MII electric hand-held type with rotating backing plate first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: OPT-MII

Overview

Smooth chamfering by rotating the backing plate!

feature

  • When replacing the tip, it can be replaced without removing the cutter (tip holder)
  • The cutter can be easily replaced with a special tool.
  • 4 types of chamfering available
  • By installing a slag prevention roller (option), it is possible to process while avoiding the weld slag part.
Chamfer type R3 (Option: R2, C1, C2)*1
Minimum plate thickness 6mm (9mm when flattened)*2
Minimum machining radius R13.5 (when processing R3)
R15 (when processing R2, C1, C2)
Cutter used 2 blades (clockwise rotation)
Chip used Carbide R Tip
number of revolutions 9000RPM
power supply 7.4A single-phase AC100V 50/60Hz
power consumption 720W (rated 30 minutes)
machine weight 2.6kg (excluding cord)

Notes

*1 C chamfering requires a C center roller and a C tip. R2 chamfering requires a dedicated liner, center roller for R2 and tip for R2.

*2 Flat processing means processing when there is no space below the processed surface of the member, or when the members are stacked on top of each other.

The post Miyakwa OPT-MII electric hand-held type with rotating backing plate first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa MGR-100-S Electric Handheld – High Power https://koueitrading.com/global/product/miyakawa-mgr-100-s-electric-handheld-high-power/ Sat, 26 Sep 2020 07:12:03 +0000 https://koueitrading.com/global/?post_type=product&p=37897 Product made in Japan Manufacturer: Miyakawa Model: MGR-100-S Feature Rigidity has been increased to support large chamfers such as R5 and C5 *1 The double lock system makes tip replacement easy. specification Chamfer amount R3 (Option: R2, R4, R5, C1, C2, C3, C4, C5)*1 Overlapping minimum plate thickness 9mm Minimum machining radius R17 No-load speed […]

The post Miyakawa MGR-100-S Electric Handheld – High Power first appeared on Kouei Japan Trading | Get Quotation.]]>

Product made in Japan
Manufacturer: Miyakawa
Model: MGR-100-S

Feature

  • Rigidity has been increased to support large chamfers such as R5 and C5 *1
  • The double lock system makes tip replacement easy.

specification

Chamfer amount R3 (Option: R2, R4, R5, C1, C2, C3, C4, C5)*1
Overlapping minimum plate thickness 9mm
Minimum machining radius R17
No-load speed 9,300 RPM*2
Working pressure 0.49～0.68Mpa
Air consumption 0.86m³/min
Power supply used Single-phase AC 50/50Hz 100V
Full load current 7.3A
Power consumption 720W
Cutter used 3 blades (clockwise rotation)
Chip used Carbide R Tip
Weight 3.3kg (without cord)

Notes

*1 This product supports R3 chamfering as standard, but by replacing the tip, center roller, liner and body, other chamfering processes can be supported. Please contact us for more information.

*2 The number of revolutions varies depending on the usage environment.

The post Miyakawa MGR-100-S Electric Handheld – High Power first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa MArX-NEO air handheld-compact https://koueitrading.com/global/product/miyakawa-marx-neo-air-handheld-compact/ Sat, 26 Sep 2020 07:11:57 +0000 https://koueitrading.com/global/?post_type=product&p=37895 Product made in Japan Manufacturer: Miyakawa Model: MArX-NEO Feature Robust construction around the motor The strength of the center roller is higher than conventional products It is lighter than conventional products and uses a rotary switch specification, making it suitable for long-time processing. Suitable for work that requires small turning radius There is also a […]

The post Miyakawa MArX-NEO air handheld-compact first appeared on Kouei Japan Trading | Get Quotation.]]>

Product made in Japan
Manufacturer: Miyakawa
Model: MArX-NEO

Feature

  • Robust construction around the motor
  • The strength of the center roller is higher than conventional products
  • It is lighter than conventional products and uses a rotary switch specification, making it suitable for long-time processing.
  • Suitable for work that requires small turning radius
  • There is also a silencer specification without a handle.

specification

Model MArX-NEO MArX-NEO-mini
Chamfer type R3 (initial chamfering amount R2.5, option C1)*1,2
Minimum machining radius R17 R11
Overlap processing minimum plate thickness 9mm
Cutter used 3 blades (clockwise rotation) 2 blades (clockwise rotation)
Chip used Carbide R Tip
When changing tip Remove the center roller and replace *3 Replace without removing the center roller
working pressure 0.49～0.68Mpa
air consumption 0.82m³/min
weight 2.2kg (handle type), 2.0kg (silencer type)

Notes

*1 The initial chamfering amount is the processing amount when the member end face angle is 90 degrees.

*2 Please contact us for the amount of chamfering and inserts used for C1.

*3 Some models can replace the tip without removing the center roller. Please contact us for more information.

The post Miyakawa MArX-NEO air handheld-compact first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa MArX-MB Air Handheld – High Power https://koueitrading.com/global/product/miyakawa-marx-mb-air-handheld-high-power/ Sat, 26 Sep 2020 07:11:55 +0000 https://koueitrading.com/global/?post_type=product&p=37894 Product made in Japan Manufacturer: Miyakawa Model: MArX-MB Feature With the 4R tip, a smooth R surface of R2 or more can be secured even at acute and obtuse angles. Uses 8-sided tip for long-lasting tip Specification Chamfer type R3 (standard product, initial chamfer amount R2.5, option C1, C2)*1,2 R4 (shipbuilding specifications, initial chamfer amount […]

The post Miyakawa MArX-MB Air Handheld – High Power first appeared on Kouei Japan Trading | Get Quotation.]]>

Product made in Japan
Manufacturer: Miyakawa
Model: MArX-MB

Feature

  • With the 4R tip, a smooth R surface of R2 or more can be secured even at acute and obtuse angles.
  • Uses 8-sided tip for long-lasting tip

Specification

Chamfer type R3 (standard product, initial chamfer amount R2.5, option C1, C2)*1,2
R4 (shipbuilding specifications, initial chamfer amount R3.0)*1
R4 (bridge specification, initial chamfer amount R3.3)*2
Overlap processing minimum plate thickness 9mm
Minimum machining radius R17
Cutter used 3 blades (clockwise rotation)
Chip used Carbide R Tip
No-load speed 10,000 RPM*3
Working pressure 0.49～0.68Mpa
Air consumption 0.86m³/min
Weight 3.3kg

Notes

*1 The initial chamfering amount is the processing amount when the member end face angle is 90 degrees.

*2 Please contact us for the amount of chamfering for C1 and C2 and the inserts used.

*3 Rotational speed varies depending on the usage environment.

The post Miyakawa MArX-MB Air Handheld – High Power first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa BakROS-NEO Pneumatic back chamfering machine https://koueitrading.com/global/product/miyakawa-bakros-neo-pneumatic-back-chamfering-machine/ Sat, 26 Sep 2020 07:11:54 +0000 https://koueitrading.com/global/?post_type=product&p=37893 Product made in Japan Manufacturer: Miyakawa Model: BakROS-NEO Specification: Chamfer type R3 Worked plate thickness 9mm to 100mm Minimum machining radius R17 (φ45 or more) Cutter used 3 blades Chip used Carbide R Tip No-load speed 10000RPM air consumption 0.53m³/min machine weight 3.2kg

The post Miyakawa BakROS-NEO Pneumatic back chamfering machine first appeared on Kouei Japan Trading | Get Quotation.]]>

Product made in Japan
Manufacturer: Miyakawa
Model: BakROS-NEO

Specification:

Chamfer type R3
Worked plate thickness 9mm to 100mm
Minimum machining radius R17 (φ45 or more)
Cutter used 3 blades
Chip used Carbide R Tip
No-load speed 10000RPM
air consumption 0.53m³/min
machine weight 3.2kg
The post Miyakawa BakROS-NEO Pneumatic back chamfering machine first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa MGR-18EV Cordless Denmaru-kun Smooth R chamfering machine https://koueitrading.com/global/product/miyakawa-mgr-18ev-cordless-denmaru-kun-smooth-r-chamfering-machine/ Sat, 26 Sep 2020 06:25:19 +0000 https://koueitrading.com/global/?post_type=product&p=37889 Product made in Japan Manufacturer: Miyakawa Model: MGR-18EV Specification:

The post Miyakawa MGR-18EV Cordless Denmaru-kun Smooth R chamfering machine first appeared on Kouei Japan Trading | Get Quotation.]]>

Product made in Japan
Manufacturer: Miyakawa
Model: MGR-18EV

Specification:

The post Miyakawa MGR-18EV Cordless Denmaru-kun Smooth R chamfering machine first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa Multi-axis Attachment Special Type https://koueitrading.com/global/product/miyakawa-multi-axis-attachment-special-type/ Sat, 26 Sep 2020 06:19:36 +0000 https://koueitrading.com/global/?post_type=product&p=37884 Product made in Japan Manufacturer: Miyakawa In addition to standardized multi-axis attachments, we also manufacture various multi-axis heads. Specification:

The post Miyakawa Multi-axis Attachment Special Type first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa

In addition to standardized multi-axis attachments, we also manufacture various multi-axis heads.

Specification:

The post Miyakawa Multi-axis Attachment Special Type first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa CTL-13 Multi-axis Attachment Collet for Left-hand Screw Tap CTL type https://koueitrading.com/global/product/miyakawa-ctl-13-multi-axis-attachment-collet-for-left-hand-screw-tap-ctl-type/ Sat, 26 Sep 2020 03:57:50 +0000 https://koueitrading.com/global/?post_type=product&p=37879 Product made in Japan Manufacturer: Miyakawa Model: CTL-13 Feature When the collet is screwed onto the spindle, the tapered section tightens the tap The straight hole is internally ground according to JIS for taps. Appearance is black-plated Dimension:

The post Miyakawa CTL-13 Multi-axis Attachment Collet for Left-hand Screw Tap CTL type first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: CTL-13

Feature

  • When the collet is screwed onto the spindle, the tapered section tightens the tap
  • The straight hole is internally ground according to JIS for taps.
  • Appearance is black-plated

Dimension:



The post Miyakawa CTL-13 Multi-axis Attachment Collet for Left-hand Screw Tap CTL type first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa CTQS Series Multi-axis attachment Quick Change Collet https://koueitrading.com/global/product/miyakawa-ctqs-series-multi-axis-attachment-quick-change-collet/ Sat, 26 Sep 2020 03:57:48 +0000 https://koueitrading.com/global/?post_type=product&p=37878 Product made in Japan Manufacturer: Miyakawa Model: CTQS Series Feature Taps can be installed with one hand without using tools. Dimension Model Supported Tap Diameter Key Dimensions (mm) CTQS-4 ~M3 Ø9.5 (10), L = 41 CTQS-6 ~M6 Ø13.5 (14.0), L = 44 CTQS-10 ~M10 Ø19.6, L = 48 CTQS-13 ~M12 Ø23, L = 53

The post Miyakawa CTQS Series Multi-axis attachment Quick Change Collet first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: CTQS Series

Feature

  • Taps can be installed with one hand without using tools.

Dimension

Model Supported Tap Diameter Key Dimensions (mm)
CTQS-4 ~M3 Ø9.5 (10), L = 41
CTQS-6 ~M6 Ø13.5 (14.0), L = 44
CTQS-10 ~M10 Ø19.6, L = 48
CTQS-13 ~M12 Ø23, L = 53
The post Miyakawa CTQS Series Multi-axis attachment Quick Change Collet first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa CS-6/10/13 Multi-axis attachment Collet for stub drill CS type https://koueitrading.com/global/product/miyakawa-cs-6-10-13-multi-axis-attachment-collet-for-stub-drill-cs-type/ Sat, 26 Sep 2020 03:35:04 +0000 https://koueitrading.com/global/?post_type=product&p=37866 Product made in Japan Manufacturer: Miyakawa Model: CS-6/10/13 Feature Comes with a screw that adjusts the amount of drilling Comes with a tongue for reaming, chamfering, and spot boring Internally ground straight hole diameters are in 0.1mm increments Dimension:

The post Miyakawa CS-6/10/13 Multi-axis attachment Collet for stub drill CS type first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: CS-6/10/13

Feature

  • Comes with a screw that adjusts the amount of drilling
  • Comes with a tongue for reaming, chamfering, and spot boring
  • Internally ground straight hole diameters are in 0.1mm increments

Dimension:

The post Miyakawa CS-6/10/13 Multi-axis attachment Collet for stub drill CS type first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa CR-3/4/6/10/13 Multi-axis attachment Collet CR Type for Reamers https://koueitrading.com/global/product/miyakawa-cr-3-4-6-10-13-multi-axis-attachment-collet-cr-type-for-reamers/ Sat, 26 Sep 2020 03:35:02 +0000 https://koueitrading.com/global/?post_type=product&p=37865 Product made in Japan Manufacturer: Miyakawa Model: CR-3/4/6/10/13 Feature When the collet is screwed onto the spindle, the taper tightens the drill The straight hole is internally ground according to reamer JIS. The size varies according to the diameter of the reamer grip Dimension:

The post Miyakawa CR-3/4/6/10/13 Multi-axis attachment Collet CR Type for Reamers first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: CR-3/4/6/10/13

Feature

  • When the collet is screwed onto the spindle, the taper tightens the drill
  • The straight hole is internally ground according to reamer JIS.
  • The size varies according to the diameter of the reamer grip

Dimension:

The post Miyakawa CR-3/4/6/10/13 Multi-axis attachment Collet CR Type for Reamers first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa CD-3/4/6/10/13 and CDS-6/10/13 Multi-axis attachment Drill collet CD type https://koueitrading.com/global/product/miyakawa-cd-3-4-6-10-13-and-cds-6-10-13-multi-axis-attachment-drill-collet-cd-type/ Sat, 26 Sep 2020 03:27:57 +0000 https://koueitrading.com/global/?post_type=product&p=37859 Product made in Japan Manufacturer: Miyakawa Model: CD-3/4/6/10/13 and CDS-6/10/13 Feature When the collet is screwed onto the spindle, the taper tightens the drill The inner diameter of the collet is ground slightly thinner than the tip of the drill to match the shank diameter of the drill. The inner diameter of the collet is […]

The post Miyakawa CD-3/4/6/10/13 and CDS-6/10/13 Multi-axis attachment Drill collet CD type first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: CD-3/4/6/10/13 and CDS-6/10/13

Feature

  • When the collet is screwed onto the spindle, the taper tightens the drill
  • The inner diameter of the collet is ground slightly thinner than the tip of the drill to match the shank diameter of the drill.
  • The inner diameter of the collet is at 0.1mm intervals.
  • There is also a type with a screw that adjusts the amount of drilling (CDS type)
  • Please contact us for inch collets and ANSI (American standard) and DIN (German industrial standard) collets.

Dimension:

The post Miyakawa CD-3/4/6/10/13 and CDS-6/10/13 Multi-axis attachment Drill collet CD type first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa G-1320/1326/1332/1620/1626/1632/1640/2030/2040/2050/2530/2540/2550/2020/2525/2828/3232/3636 Multi-axis attachment G type (square type) https://koueitrading.com/global/product/miyakawa-g-1320-1326-1332-1620-1626-1632-1640-2030-2040-2050-2530-2540-2550-2020-2525-2828-3232-3636-multi-axis-attachment-g-type-square-type/ Sat, 26 Sep 2020 03:17:48 +0000 https://koueitrading.com/global/?post_type=product&p=37848 Product made in Japan Manufacturer: Miyakawa Model: G-1320/1326/1332/1620/1626/1632/1640/2030/2040/2050/2530/2540/2550/2020/2525/2828/3232/3636 It has high accuracy and rigidity and is compact and easy to incorporate into a unit or special machine. Feature It has a smaller volume than the K type and does not easily interfere with jigs and accessories when incorporated into a dedicated machine. Optimal when hole […]

The post Miyakawa G-1320/1326/1332/1620/1626/1632/1640/2030/2040/2050/2530/2540/2550/2020/2525/2828/3232/3636 Multi-axis attachment G type (square type) first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: G-1320/1326/1332/1620/1626/1632/1640/2030/2040/2050/2530/2540/2550/2020/2525/2828/3232/3636

It has high accuracy and rigidity and is compact and easy to incorporate into a unit or special machine.

Feature

  • It has a smaller volume than the K type and does not easily interfere with jigs and accessories when incorporated into a dedicated machine.
  • Optimal when hole positions are distributed in a straight line or staggered arrangement, suitable for heavy-duty cutting.
  • Optional brackets and guide bars can be installed to improve lateral advancement accuracy

Specification:

Dimension:

The post Miyakawa G-1320/1326/1332/1620/1626/1632/1640/2030/2040/2050/2530/2540/2550/2020/2525/2828/3232/3636 Multi-axis attachment G type (square type) first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa Without G type bracket Multi-axis attachment G type (square type) https://koueitrading.com/global/product/miyakawa-without-g-type-bracket-multi-axis-attachment-g-type-square-type/ Sat, 26 Sep 2020 03:15:39 +0000 https://koueitrading.com/global/?post_type=product&p=37847 Product made in Japan Manufacturer: Miyakawa Model: Without G type bracket It has high accuracy and rigidity, and is compact and easy to incorporate into a unit or special machine. Feature It has a smaller volume than the K type and does not easily interfere with jigs and accessories when incorporated into a dedicated machine. […]

The post Miyakawa Without G type bracket Multi-axis attachment G type (square type) first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: Without G type bracket

It has high accuracy and rigidity, and is compact and easy to incorporate into a unit or special machine.

Feature

  • It has a smaller volume than the K type and does not easily interfere with jigs and accessories when incorporated into a dedicated machine.
  • Optimal when hole positions are distributed in a straight line or staggered arrangement, suitable for heavy-duty cutting.
  • Optional brackets and guide bars can be installed to improve lateral advancement accuracy

Specification:

Dimension:

The post Miyakawa Without G type bracket Multi-axis attachment G type (square type) first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa With K type bracket Multi-axis attachment K type (round type) https://koueitrading.com/global/product/miyakawa-with-k-type-bracket-multi-axis-attachment-k-type-round-type/ Sat, 26 Sep 2020 03:04:22 +0000 https://koueitrading.com/global/?post_type=product&p=37843 Product made in Japan Manufacturer: Miyakawa Model: With K type bracket Overview It has high precision and rigidity, and has a long system life, and is widely used for heavy cutting. feature The lower body and intermediate body are machined with a jig borer for high precision and excellent rigidity. It is a safe type […]

The post Miyakawa With K type bracket Multi-axis attachment K type (round type) first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: With K type bracket

Overview

It has high precision and rigidity, and has a long system life, and is widely used for heavy cutting.

feature

  • The lower body and intermediate body are machined with a jig borer for high precision and excellent rigidity.
  • It is a safe type with a dustproof mechanism.
  • Suitable for drilling machines, drilling units, tapping units, special purpose machines, flange mounting type is also available
  • Optional brackets and guide bars can be installed to improve lateral advancement accuracy
  • If you prepare a head for each workpiece, there is no need for centering, and if you attach a quick change mechanism, you can easily replace the head.
  • Grease is used as a lubrication mechanism, but it can be changed to an oil bath method as an option.
  • Even workpieces with steps can be processed by using the extension axis.

Specification:

Dimension:

The post Miyakawa With K type bracket Multi-axis attachment K type (round type) first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa Without K type bracket Multi-axis attachment K type (round type) https://koueitrading.com/global/product/miyakawa-without-k-type-bracket-multi-axis-attachment-k-type-round-type/ Sat, 26 Sep 2020 03:01:30 +0000 https://koueitrading.com/global/?post_type=product&p=37839 Product made in Japan Manufacturer: Miyakawa Model: Without K type bracket It has high precision and rigidity, and has a long system life, and is widely used for heavy cutting. Feature The lower body and intermediate body are machined with a jig borer for high precision and excellent rigidity. It is a safe type with […]

The post Miyakawa Without K type bracket Multi-axis attachment K type (round type) first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: Without K type bracket

It has high precision and rigidity, and has a long system life, and is widely used for heavy cutting.

Feature

  • The lower body and intermediate body are machined with a jig borer for high precision and excellent rigidity.
  • It is a safe type with a dustproof mechanism.
  • Suitable for drilling machines, drilling units, tapping units, special purpose machines, flange mounting type is also available
  • Optional brackets and guide bars can be installed to improve lateral advancement accuracy
  • If you prepare a head for each workpiece, there is no need for centering, and if you attach a quick change mechanism, you can easily replace the head.
  • Grease is used as a lubrication mechanism, but it can be changed to an oil bath method as an option.
  • Even workpieces with steps can be processed by using the extension axis.

Specification:

Dimension:

The post Miyakawa Without K type bracket Multi-axis attachment K type (round type) first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa E-117 Multi-axis attachment E type https://koueitrading.com/global/product/miyakawa-e-117-multi-axis-attachment-e-type-2/ Sat, 26 Sep 2020 02:47:13 +0000 https://koueitrading.com/global/?post_type=product&p=37833 Product made in Japan Manufacturer: Miyakawa Model: E-117 Light weight, low cost, short delivery shaft fixed type Feature The mounting drilling machine supports 13 mm, but the E-117 type can also support 19 mm as an option. Specification:     Dimension:

The post Miyakawa E-117 Multi-axis attachment E type first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: E-117

Light weight, low cost, short delivery shaft fixed type

Feature

  • The mounting drilling machine supports 13 mm, but the E-117 type can also support 19 mm as an option.

Specification:





Dimension:

The post Miyakawa E-117 Multi-axis attachment E type first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa E-077 Multi-axis attachment E type https://koueitrading.com/global/product/miyakawa-e-077-multi-axis-attachment-e-type/ Sat, 26 Sep 2020 02:43:05 +0000 https://koueitrading.com/global/?post_type=product&p=37828 Product made in Japan Manufacturer: Miyakawa Model: E-077 Light weight, low cost, short delivery shaft fixed type Feature The mounting drilling machine supports 13 mm, but the E-117 type can also support 19 mm as an option. Specification: Dimension:

The post Miyakawa E-077 Multi-axis attachment E type first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: E-077

Light weight, low cost, short delivery shaft fixed type

Feature

  • The mounting drilling machine supports 13 mm, but the E-117 type can also support 19 mm as an option.

Specification:

Dimension:

The post Miyakawa E-077 Multi-axis attachment E type first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa A-260 Multi-axis attachment type A https://koueitrading.com/global/product/miyakawa-a-260-multi-axis-attachment-type-a-2/ Sat, 26 Sep 2020 02:35:54 +0000 https://koueitrading.com/global/?post_type=product&p=37825 Product made in Japan Manufacturer: Miyakawa Model: A-260 It is a type that can be easily set on a colinear line positioning of 2 axes. Feature Has a wide adjustment range It is lighter than conventional products (60% compared to our company) and is suitable for mounting small units other than drilling machines. Specification: Dimension:

The post Miyakawa A-260 Multi-axis attachment type A first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: A-260

It is a type that can be easily set on a colinear line positioning of 2 axes.

Feature

  • Has a wide adjustment range
  • It is lighter than conventional products (60% compared to our company) and is suitable for mounting small units other than drilling machines.

Specification:

Dimension:

The post Miyakawa A-260 Multi-axis attachment type A first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa C-155 Multi-axis attachment type C https://koueitrading.com/global/product/miyakawa-c-155-multi-axis-attachment-type-c/ Sat, 26 Sep 2020 02:17:22 +0000 https://koueitrading.com/global/?post_type=product&p=37820 Product made in Japan Manufacturer: Miyakawa Model: C-155 Equally positioning is possible on the circumference of two axes, and it is a compact short-delivery type Feature Has dust-proof function, small size and light weight The speed ratio of drilling machine to spindle is 1:1 As an application, in addition to holes, it can be widely […]

The post Miyakawa C-155 Multi-axis attachment type C first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: C-155

Equally positioning is possible on the circumference of two axes, and it is a compact short-delivery type

Feature

  • Has dust-proof function, small size and light weight
  • The speed ratio of drilling machine to spindle is 1:1
  • As an application, in addition to holes, it can be widely used such as tapping, reaming, and zagri processing.
  • Only the 86 type has a turning correction function for hole group position after setting the interaxis pitch.

Specification:

Dimension:

The post Miyakawa C-155 Multi-axis attachment type C first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa CT-3/4/6/10/13 and CTF-6/10/13 Multi-axis Attachment Collet CT type for Tap https://koueitrading.com/global/product/miyakawa-ct-3-4-6-10-13-ctf-6-10-13-multi-axis-attachment-collet-ct-type-for-tap/ Sat, 26 Sep 2020 01:50:07 +0000 https://koueitrading.com/global/?post_type=product&p=37867 Product made in Japan Manufacturer: Miyakawa Model: CT-3/4/6/10/13 and CTF-6/10/13 Feature When the collet is screwed onto the spindle, the tapered section tightens the tap It has a screw that adjusts the amount of tapping and a tongue that prevents rotation. The straight hole is internally ground according to JIS for taps. Has a floating […]

The post Miyakawa CT-3/4/6/10/13 and CTF-6/10/13 Multi-axis Attachment Collet CT type for Tap first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: CT-3/4/6/10/13 and CTF-6/10/13

Feature

  • When the collet is screwed onto the spindle, the tapered section tightens the tap
  • It has a screw that adjusts the amount of tapping and a tongue that prevents rotation.
  • The straight hole is internally ground according to JIS for taps.
  • Has a floating function (CTF type)

Dimension:



The post Miyakawa CT-3/4/6/10/13 and CTF-6/10/13 Multi-axis Attachment Collet CT type for Tap first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa A-180 Multi-axis attachment type A https://koueitrading.com/global/product/miyakawa-a-180-multi-axis-attachment-type-a/ Thu, 24 Sep 2020 04:36:40 +0000 https://koueitrading.com/global/?post_type=product&p=37808 Product made in Japan Manufacturer: Miyakawa Model: A-180 It is a type that can be easily set on a colinear line positioning of 2 axes. Feature Has a wide adjustment range It is lighter than conventional products (60% compared to our company) and is suitable for mounting small units other than drilling machines. Specification: Dimension:

The post Miyakawa A-180 Multi-axis attachment type A first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: A-180

It is a type that can be easily set on a colinear line positioning of 2 axes.

Feature

  • Has a wide adjustment range
  • It is lighter than conventional products (60% compared to our company) and is suitable for mounting small units other than drilling machines.

Specification:

Dimension:

The post Miyakawa A-180 Multi-axis attachment type A first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa A-140 Multi-Axis Attachment Type A https://koueitrading.com/global/product/miyakawa-a-140-multi-axis-attachment-type-a/ Thu, 24 Sep 2020 04:25:42 +0000 https://koueitrading.com/global/?post_type=product&p=37803 Product made in Japan Manufacturer: Miyakawa Model: A-140 It is a type that can be easily set on a colinear line positioning of 2 axes. Feature Has a wide adjustment range It is lighter than conventional products (60% compared to our company) and is suitable for mounting small units other than drilling machines. Specification: Dimension:

The post Miyakawa A-140 Multi-Axis Attachment Type A first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: A-140

It is a type that can be easily set on a colinear line positioning of 2 axes.

Feature

  • Has a wide adjustment range
  • It is lighter than conventional products (60% compared to our company) and is suitable for mounting small units other than drilling machines.

Specification:

Dimension:

The post Miyakawa A-140 Multi-Axis Attachment Type A first appeared on Kouei Japan Trading | Get Quotation.]]> Miyakawa A-100 Multi-axis attachment type A https://koueitrading.com/global/product/miyakawa-a-100-multi-axis-attachment-type-a/ Thu, 24 Sep 2020 04:06:09 +0000 https://koueitrading.com/global/?post_type=product&p=37792 Product made in Japan Manufacturer: Miyakawa Model: A-100 It is a type that can be easily set on a colinear line positioning of 2 axes. Feature Has a wide adjustment range It is lighter than conventional products (60% compared to our company) and is suitable for mounting small units other than drilling machines. Specification: Dimension:

The post Miyakawa A-100 Multi-axis attachment type A first appeared on Kouei Japan Trading | Get Quotation.]]> Product made in Japan
Manufacturer: Miyakawa
Model: A-100

It is a type that can be easily set on a colinear line positioning of 2 axes.

Feature

  • Has a wide adjustment range
  • It is lighter than conventional products (60% compared to our company) and is suitable for mounting small units other than drilling machines.

Specification:

Dimension:

The post Miyakawa A-100 Multi-axis attachment type A first appeared on Kouei Japan Trading | Get Quotation.]]>
