Features

• It is widely directional, so there is no need to adjust it during installation.
• It works reliably even if the floodlight shakes.
• It has a long battery life and the battery is commercially available.
• High response.
• It can be easily connected to a utility power supply with a small transformer.
• The structure is robust.

Features

• Reliably responds to the touch time of the moment and self-retaining.
• Minimum contact time 0.1msec
• It can be easily connected to a utility power supply with a small transformer.
• It is compact and rail-mounted.

Features

• It distributes 5 pulses from proximity switches and rotary encoders.
• Up to 5 electronic counters can be driven by a single pulse generator.
• It is compact and rail-mounted.

Features

• It has an indicator light that allows you to check the presence or absence of input and output pulses at a glance.
• The division ratio can be easily set.
• It is compact and rail-mounted.

Features

• The DC output voltage value can be set from 0~maximum when the input signal voltage is 0V.
• When using multiple PA-1 power amplifiers with a common input signal voltage, the mechalos of each load can be adjusted.
• The maximum DC output voltage can be set to match the maximum input signal voltage.
• compact

Features

• No equipment control power supply required.
• The power loss is small, and the output can be arbitrarily set from 0 to maximum.
• The ratio of the set output voltage to the input voltage is constant.
• Set the output voltage with a digital switch. The set value will not be deviated by vibration.
• It has a check plug that allows you to easily check the output voltage value with the tester.
• The load can be switched in and out with the ON/OFF switch.
• The structure is robust and designed to withstand centrifugal force, so it can be equipped in a rotating body.
• It can be mounted both stationary and embedded.
• Small size and light weight.

Features

• When two points of empty tension and groove tension are set, the voltage is output proportional to the measured value of the counter between the two points, making tension setting easy and tension control continuous.
• With output contacts that output at the full roll value or “0” of the winding thickness.
• It is equipped with both power and voltage outputs. The power output can directly control the powder clutch and the like, and the voltage output can control the power regulator and so on.
• You can switch to an external tension setter or connect an external calculator to compensate for inertia when starting or stopping.
• It is equipped with an auxiliary input terminal that inputs the displacement of the dansa roller or other voltage plasma or minus and increases or decreases the output of the wind thickness value.
• The output meter is a digital display and can be switched between a voltmeter and an ammeter.
• After the ban is lifted, it is equipped with a prohibited input terminal that starts calculating the wind thickness after receiving the first gate input, so the display of the wind thickness will not be disturbed when starting or stopping.
• It has an indicator light that allows you to check the presence or absence of counting and gate input pulses at a glance.
• The tension setter is a multi-dial with lock. The setpoint can be locked and the tension can be fine-tuned.
• It has a built-in 15 V, 50 mA DC sensor power supply and ±a 15 V, 10 mA DC auxiliary power supply.
• With memory by built-in battery.
• The display of unnecessary upper digits is eliminated, and the numerical values can be read directly using the zero-suppress method.

Features

• When two points of empty tension and groove tension are set, the voltage is output proportional to the measured value of the counter between the two points, making tension setting easy and tension control continuous.
• The tension for any winding thickness can be checked before operation, and the winding thickness and tension values can be constantly monitored during operation.
• With output contacts that output at the full roll value or “0” of the winding thickness. It can be used as a preset counter.
• You can switch to an external tension setter or connect an external calculator to compensate for inertia when starting or stopping.
• It is equipped with an auxiliary input terminal that inputs the displacement of the dansa roller or other voltage plasma or minus and increases or decreases the output of the wind thickness value.
• The output meter is a digital display and can be switched between a voltmeter and an ammeter.
• The tension setter is a multi-dial with lock. The setpoint can be locked and the tension can be fine-tuned.
• It has a built-in 15 V, 50 mA DC sensor power supply and ±a 15 V, 10 mA DC auxiliary power supply.
• With memory by built-in battery.
• The display of unnecessary upper digits is eliminated, and the numerical values can be read directly using the zero-suppress method.
• Small, lightweight and compact.

Features

• When two points of empty tension and groove tension are set, the voltage is output proportional to the measured value of the counter between the two points, making tension setting easy and tension control continuous.
• It has an output contact that outputs at a preset value of the counter or “0”. It can be used as a preset counter.
• It is equipped with both power and voltage outputs. The power output can directly control the powder clutch and the like, and the voltage output can control the power regulator and so on.
• You can switch to an external tension setter or connect an external calculator to compensate for inertia when starting or stopping.
• It is equipped with an auxiliary input terminal that inputs the displacement of the Dansa roller or other voltage plasma or minus, and positively or negatively displays the output of the numerical value.
• The output meter is a digital display and can be switched between a voltmeter and an ammeter.
• The tension setter is a multi-dial with lock. The setpoint can be locked and the tension can be fine-tuned.
• The number of digits on the counter display can be changed with one touch.
• It has a built-in 15 V, 50 mA DC sensor power supply and ±a 15 V, 10 mA DC auxiliary power supply.
• With memory by built-in battery.
• The display of unnecessary upper digits is eliminated, and the numerical values can be read directly using the zero-suppress method.
• Small, lightweight and compact.

Features

• When two points of empty tension and groove tension are set, the voltage is output proportional to the measured value of the counter between the two points, making tension setting easy and tension control continuous.
• The tension of the counter against any measured value can be checked before operation, and the measured and tension values can be constantly monitored during operation.
• It has an output contact that outputs at a preset value of the counter or “0”. It can be used as a preset counter.
• It is equipped with both power and voltage outputs. The power output can directly control the powder clutch and the like, and the voltage output can control the power regulator and so on.
• You can switch to an external tension setter or connect an external calculator to compensate for inertia when starting or stopping.
• It is equipped with an auxiliary input terminal that inputs the displacement of the Dansa roller or other voltage plasma or minus, and positively or negatively displays the output of the numerical value.
• You can change the number of digits in the counter display.
• It has a built-in 15 V, 50 mA DC sensor power supply and ±a 15 V, 10 mA DC auxiliary power supply.
• With memory by built-in battery.
• The display of unnecessary upper digits is eliminated, and the numerical values can be read directly using the zero-suppress method.
• Small, lightweight and compact.

Features

• No license requiredNo
  radio station license is required, saving the cost and hassle of applying for a license.
• Since
  it is a ranging type that measures the distance between the microguard and the reflector, it can reliably detect intrusion alarms.
• OK
  in adverse environments Microwaves penetrate dirt and layers of deposits on the detection surface and are almost unaffected by fog, rain, wind, snow, dust, and water vapor.
• The beam axis does not
  shift The transmitting and receiving beams are conical in shape, making it easy to adjust the beam axis and there is no operation defect due to axis misalignment.
• Several microguards that do not
  interfere with the set can be installed in close proximity.
• Outdoor
• Affordable price

Specification

Features

Features

• The signal input by RS422 is converted into a microwave signal and transmitted to another data transmission device, and the microwave signal received by the receiver is output via RS422. The signal is used to control the brakes of each vehicle and to unpin the hitch.
• Microwaves are less susceptible to flames, water vapor, suspended dust, dirt, and high-voltage wires, and can communicate more reliably than light and coil methods.

Features

• High accuracy and reliability There is a good linear relationship between
  the phase delay and density of microwaves, so high-precision density measurements can be made from low to high densities. The flow velocity can be accurately measured by taking the mutual correlation of the phase change pattern between the upstream and downstream sides to determine the flow velocity. The sensor part through which the pulverized coal passes is a ceramic pipe with excellent wear resistance and no protrusion into the tube.
• Continuous in-line measurement is possible.
  It can be attached to a pipe and continuously measure the density and flow velocity of pulverized coal flowing through the pipe.
• Equipped with
  convenient functions It can be set up on your own computer to monitor the operating status and set parameters. Density, flow rate, and flow rate can be monitored, and each output at 4~20mA. The calibration curve coefficient can be set externally and the zero point can be calibrated.

Specification

Features

Features

• No license requiredNo
  radio station license is required, saving the cost and hassle of applying for a license.
• It is a ranging type that measures the distance between the two-output
  micro robot and the reflector, so it is easy to adjust the distance, and the crane can be slowed down with the deceleration output and stopped with the stop output.
• Analog output of measuring distance with
  analog output.
• OK
  in adverse environments Microwaves can penetrate dirt and layers of deposits on the detection surface, and are almost unaffected by rain, wind, snow, fog, dust, and water vapor.
• No
  beam axis misalignment The transmitting and receiving beams are conical in shape, making it easy to adjust the beam axis and there is no operation defect due to axis misalignment.
• You can install a micro robot in close proximity that does not
  interfere with the set.
• Outdoor
• Affordable price

Features

• No license requiredNo
  radio station license required, saving the cost and hassle of applying for a license.
• The structure is simple
  , and it is small and economical because it can transmit and receive both with one antenna.
• OK
  in adverse environments Microwaves can penetrate dirt and layers of deposits on the detection surface, and are almost unaffected by rain, wind, snow, fog, dust, and water vapor.
• By sharpening the directivity of microwaves transmitted from highly directional
  sensors, they are less susceptible to structural influences.
• Three-dimensional detection area
  The transmitting and receiving area is in the shape of a cone, and the detection area is the area where the transmitting and receiving area wraps.
  It is easy to adjust the angle during installation, and there is no need to worry about malfunction due to angle misalignment, and proximity detection can be reliably detected.
• You can select a channel number that does not
  interfere with the set and place up to four pairs of micro robots in close proximity.
• With
  reception level and sensitivity setpoint display One of the 15 LEDs is lit to display the reception level in 15 levels. On the other hand, one of the 15 LEDs is illuminated dim to display the sensitivity setpoint. The setpoint and reception level margin are visible at a glance, making it easy to adjust and maintain.
• Outdoor type
  It has a splash-proof structure equivalent to IP65.

Features

• No license requiredNo
  radio station license required, saving the cost and hassle of applying for a license.
• The structure is simple
  , and it is small and economical because it can transmit and receive both with one antenna.
• OK
  in adverse environments Microwaves can penetrate dirt and layers of deposits on the detection surface, and are almost unaffected by rain, wind, snow, fog, dust, and water vapor.
• Three-dimensional detection area
  The transmitting and receiving area is in the shape of a cone, and the detection area is the area where the transmitting and receiving area wraps.
  It is easy to adjust the angle during installation, and there is no need to worry about malfunction due to angle misalignment, and proximity detection can be reliably detected.
• You can select a channel number that does not
  interfere with the set and place up to four pairs of micro robots in close proximity.
• With
  reception level and sensitivity setpoint display One of the 15 LEDs is lit to display the reception level in 15 levels. On the other hand, one of the 15 LEDs is illuminated dim to display the sensitivity setpoint. The setpoint and reception level margin are visible at a glance, making it easy to adjust and maintain.
• Outdoor type
  It has a splash-proof structure equivalent to IP65.

Face-To-Face Type Microwave Sensor for Crane Proximity Detection MICRO-ROBO®
ANIMATION

Features

• No license requiredNo
  radio station license required, saving the cost and hassle of applying for a license.
• OK
  in adverse environments mmWave is not affected by high temperatures, water vapor, flames, water flowing over the slabs, showers.
  Use the option if you need heat protection.
• High reliability detects the presence or absence of slabs with or without reflections from the
  rolls. Since it is detected digitally, the presence or absence of slabs is reliably detected.
• Fast response
  approx. 5msec. Realize the update time.
• By using a millimeter-wave beam with high precision
  and sharp directionality, the presence or absence of slabs is accurately detected.
• There is no misalignment of the beam axis The transmitting and receiving beams are conical in shape, making it easy to adjust the beam axis and there is no malfunction due to axis misalignment.
• Multiple millimeter trackers that do not
  interfere with the set can be installed close together.

Specification

Features

• No license requiredNo
  radio station license required, saving the cost and hassle of applying for a license.
• The detection distance is three
  times longer than that of our company. Therefore, the waveguide length can be lengthened.
• The antenna that is OK
  in adverse environments can be used at high temperatures. Microwaves are largely unaffected by high temperatures, water vapor, flames, and dust.
• Detection mode switch with
  UNREFLECTED detection or REFLECTED detection can be selected.
• You can select a channel number that does not
  interfere with the set and install up to 4 pairs of microguns in close proximity.
• With
  reception level and sensitivity setpoint display One of the 15 LEDs is lit to display the reception level in 15 levels. On the other hand, one of the 15 LEDs is illuminated dim to display the sensitivity setpoint. The setpoint and reception level margin are visible at a glance, making it easy to adjust and maintain.
• With a viewing window (optional)
  With a viewing window that shows the reception level and sensitivity setting value at a glance.
• Adopts an IC semiconductor relay that is resistant to contactless output
  vibration.
• IP65 equivalent degree of protection
• Compact and lightweight, easy to install

Features

• No license requiredNo
  radio station license required, saving the cost and hassle of applying for a license.
• The detection distance is three
  times longer than that of our company. The waveguide length can be lengthened.
• The use of the rotating microwave system, which does not cause malfunctions due to reflected waves, improves detection accuracy with almost no malfunctions caused by reflections from detected objects or surrounding objects, and chatter due to phase interference between direct waves and reflected waves.
• The antenna that is OK
  in adverse environments can be used at high temperatures. Microwaves are largely unaffected by high temperatures, water vapor, flames, and dust.
• The transmitting and receiving areas without
  beam axis deviation are conical in shape, so there is no need to adjust the beam axis during installation, and it can be reliably detected without worrying about malfunctions due to beam axis misalignment.
• With detection mode switch,
  you can choose between shatter detection or transmission detection.
• You can select a channel number that does not
  interfere with the set and install up to 4 pairs of microguns in close proximity.
• With
  reception level and sensitivity setpoint display One of the 15 LEDs is lit to display the reception level in 15 levels. On the other hand, one of the 15 LEDs is illuminated dim to display the sensitivity setpoint. The setpoint and reception level margin are visible at a glance, making it easy to adjust and maintain.
• With analog output (optional)
  Analog output (4mA~20mA) receives the received power. It can detect objects by catching even the slightest change in received power without missing it. In addition, the received power can be monitored, so failures can be detected before they occur.
• With a viewing window (optional)
  With a viewing window that shows the reception level and sensitivity setting value at a glance.
• Adopts an IC semiconductor relay that is resistant to contactless output
  vibration.
• IP65 equivalent degree of protection

Features

• No license requiredNo
  radio station license required, saving the cost and hassle of applying for a license.
• Strong penetration detection
  It is virtually unaffected by dirt and deposits on the surface, and the sensor is mounted outside the non-metal pipe, such as plastic or ceramic, to detect the flow in the pipe from the outside.
• It does not interfere with the flow.
  It can be installed without any unevenness in the pipe, so it will not obstruct the flow or damage the flowing object.
• Removal of unnecessary Doppler signals with filter function It
  improves the signal-to-noise ratio by removing unnecessary Doppler signals other than detected objects, such as vibration, so it can be used in places where detection was previously difficult.
• Sensitivity setting margin indicator
  lighted and non-flow reception level and sensitivity setting value can be seen at a glance between the reception level and the sensitivity setting, making it easy to set and maintain the sensitivity, and the effect of using the filter function to remove unwanted Doppler signals can be seen at a glance.
• With
  alarm output Microwave system abnormalities and temperature rises are alarmed.
• You can choose between flow-time detection or non-flow detection with
  detection mode switch.
• Test Button When
  the test button is pressed, the LED displays the oscillation stop, reception status, and temperature inside the sensor.
• LED illuminates when a Doppler signal is received.You can determine whether there is flow in the pipe.
• Doppler with analog output (optional)
  Analog output (4mA~20mA) Doppler receive power.

Features

• No license required
  If you obtain a certificate of compliance with the technical standards for specified small power, you can save the cost and hassle of applying for a license without the need for a license.
• It has a strong penetrating force
  and can easily penetrate adherents.
• OK
  in adverse environments Microwaves penetrate layers of dirt and deposits on the detection surface and are virtually unaffected by flames, water vapor, and dust.
• The transmitting and receiving areas without
  beam axis deviation are conical in shape, and there is no need to adjust the beam axis during installation, and there is no malfunction due to axis misalignment.
• With sensitivity setting margin indicator light,
  the margin of non-swing and squeezing can be seen from the outside at a glance, making it easy to adjust the sensitivity and maintain.
• You can switch
  the delay on to the delay off.
• Hysteresis switching
  The output relay can be turned on and off to reduce the hysteresis.
• Easy
  to set The distance can be set from the minimum to the maximum distance with a single sensitivity setting knob.
• Improved
  vibration resistance and vibration resistance.

Features

• No license requiredNo
  radio station license required, saving the cost and hassle of applying for a license.
• Strong penetration detection
  It is virtually unaffected by dirt and deposits on the surface, and the sensor is mounted outside the non-metal pipe, such as plastic or ceramic, to detect the flow in the pipe from the outside.
• It does not interfere with the flow.
  It can be installed without any unevenness in the pipe, so it will not obstruct the flow or damage the flowing object.
• Removal of unnecessary Doppler signals with filter function It
  improves the signal-to-noise ratio by removing unnecessary Doppler signals other than detected objects, such as vibration, so it can be used in places where detection was previously difficult.
• Sensitivity setting margin indicator
  lighted and non-flow reception level and sensitivity setting value can be seen at a glance between the reception level and the sensitivity setting, making it easy to set and maintain the sensitivity, and the effect of using the filter function to remove unwanted Doppler signals can be seen at a glance.
• You can choose between flow-time detection or non-flow detection with
  detection mode switch.
• Test Button When
  the test button is pressed, the LED displays the oscillation stop, reception status, and temperature inside the sensor.
• LED illuminates when a Doppler signal is received.
  You can determine whether there is flow in the pipe.

Features

• Strong permeability It also penetrates the adhesion easily.
• OK in adverse environments Microwaves penetrate layers of dirt and deposits on the detection surface and are virtually unaffected by flames, water vapor, and dust.
• No beam axis misalignment The transmitting and receiving areas are conical, and there is no need to adjust the beam axis during mounting, and there is no malfunction due to axis misalignment.
• Sensitivity settingwith margin indicator The margin between non-cut-off and stiff-off time can be seen from the outside at a glance, making it easy to adjust the sensitivity and maintain.
• Switching Delay You can turn on-delay to off-delay.
• Switching hysteresis The hysteresis of the output relay on and off can be reduced.
• Easy to set up You can set the distance from the minimum to the maximum distance with a single sensitivity setting knob.
• Vibration resistance Improved vibration resistance.

Specification

*1: A 24V DC power supply (MWS-CTX/CRX-1-24V type) is also available. *2: The detection distance varies depending on the sensor and installation environment.

Features

• No license requiredNo
  radio station license is required, saving the cost and hassle of applying for a license.
• Strong penetration power
  Achieves 3 times the detection distance compared to our company. It can easily penetrate thick adhesions such as molten ash.
• The transmitting and receiving areas without
  beam axis deviation are conical in shape, and there is no need to adjust the beam axis during installation, and there is no malfunction due to axis misalignment.
• With sensitivity setting margin indicator light,
  the margin of non-swing and squeezing can be seen from the outside at a glance, making it easy to adjust the sensitivity and maintain.
• Compact and easy to install
• Improved earthquake
  resistance.
• Achieve a reach of 200 m
• IP65 equivalent degree of protection

Features

*The detection distance varies depending on the sensor and installation environment.

Features

• No license requiredNo
  radio station license is required, saving the cost and hassle of applying for a license.
• Strong penetration power
  Achieves 3 times the detection distance compared to our company. It can easily penetrate thick adhesions such as molten ash.
• The transmitting and receiving areas without beam axis deviation are conical in shape, and there is no need to adjust the beam axis during installation, and there is no malfunction due to axis misalignment.
• Detection mode: Shut-off detection with switch switch or transmission detection can be selected.
• You can select a channel number that does not interfere with the set and install up to four pairs of sensors in close proximity.
• With reception level and sensitivity setpoint display One of the 15 LEDs is lit to display the reception level in 15 levels.
• On the other hand, one of the 15 LEDs is illuminated dim to display the sensitivity setpoint. The setpoint and reception level margin are visible at a glance, making it easy to adjust and maintain.
• With a viewing window (optional)
  With a viewing window that shows the reception level and sensitivity setting value at a glance.
• Achieves a reach of about 100m with a small detection surface of φ27mm
• IP65 equivalent degree of protection

Features

• No license requiredNo
  radio station license is required, saving the cost and hassle of applying for a license.
• OK
  in adverse environments Microwaves penetrate layers of dirt and deposits on the detection surface and are virtually unaffected by flames, water vapor, and dust.
• Reach:
  100m Reach: Easily penetrates thick deposits such as molten ash.
• Easy
  to set up With one sensitivity setting knob, you can set the distance to the maximum reach.
• Detection mode: Shut-off
  detection with switch switch or transmission detection can be selected.
• There is no deviation of the beam axis The transmitting and receiving areas are conical in shape, and there is no need to adjust the beam axis during mounting, and there is no malfunction due to axis misalignment.
• Detection mode: Shut-off
  detection with switch switch or transmission detection can be selected.
• IP65 equivalent degree of protection

Features

• Excellent environmental resistance:
  It enables stable measurements even in high-temperature environments and dust-filled environments.
• It is ideal as a sensor for mold powder level control because it measures with a measurement
  accuracy of less than ± 2 mm and a response of 5 msec. The
  measured data is stored on the hard disk of the data processing PC.
• Small size and light weight
  Small and light weight for easy installation.
• Measurement in
  narrow spaces The use of millimeter waves enables measurement even in narrow spaces that cannot be measured with eddy current sensors.
• Thickness Measurement
  of Mold Powder In combination with eddy current sensors, the thickness of mold powder can be measured.
• If there is no mold powder, the molten steel level is measured.

Features

• License not required
  • No radio station license is required, saving the cost and hassle of applying for a license.
• OK in adverse environments
  • The reflector corresponding to the detection head is attached to the high-temperature part and can be used at high temperatures without a cooling device.
  • Millimeter waves are almost unaffected by temperature, flame, water vapor, airborne dust, and dirt.
• High accuracy, high reliability
  • The 79GHz antenna is compact and has a sharp beam angle, allowing it to be used in narrow spaces.
  • It is ideal for detecting granules on steep slopes.
  • ± 5mm accuracy.
  • Since the measurement distance is automatically calibrated at regular intervals, the measurement accuracy is not affected even if the temperature changes or long-term use are not affected.
  • With a filter function to remove fault waves.
• Monitoring of driving status and abnormal conditions with a computer
  • It continuously displays the received signal waveform, FFT spectral waveform, and measurement trajectory, and can also record, playback, and fast forward as needed.
  • You can easily determine the optimal parameter value while simulating using the recording and playback function.
  • It displays and outputs the temperature and alarms (reception level drop, temperature increase in the main unit, version mismatch, communication error).
• Equipped with useful functions
  • You can set any reference point or measurement range.
  • You can set it up on your computer.
  • It is a free power supply with AC90~240V and 50/60Hz.
  • You can communicate with your computer via RS-232C or RS-422.
  • The distance output is 4-20mA output.
• Reduced weight and compactness
  • You can hold it with one hand. The antenna has become even lighter and smaller.
  • The burden of installation work has been reduced.
• Flexible Adaptability
  • Both hardware and software can be changed and improved according to your requirements.

Features

• OK in adverse environments
  • The reflector corresponding to the detection head is attached to the high-temperature part and can be used at high temperatures without a cooling device.
  • Millimeter waves are almost unaffected by temperature, flame, water vapor, airborne dust, and dirt.
• High accuracy, high reliability
  • The 79GHz system detects even objects with low radio wave reflectivity. Moreover, the antenna is compact and the beam angle is sharp, so it can be used in narrow spaces.
  • It is ideal for detecting powders and granules with large angles of repose.
  • ± 5mm accuracy.
  • The rotating millimeter wave method is used to eliminate false measurements caused by reflected waves twice.
  • Since the measurement distance is automatically calibrated at regular intervals, the measurement accuracy is not affected even if the temperature changes or long-term use are not affected.
  • With a filter function to remove fault waves.
• Monitoring of driving status and abnormal conditions with a computer
  • It continuously displays the received signal waveform, FFT spectral waveform, and measurement trajectory, and can also record, playback, and fast forward as needed.
  • You can easily determine the optimal parameter value while simulating using the recording and playback function.
  • It displays and outputs the temperature and alarms (reception level drop, temperature increase in the main unit, version mismatch, communication error).
• Equipped with useful functions
  • The reference point and measurement range can be set arbitrarily, and the waveguide or coaxial cable length can be easily reduced from the measured value.
  • You can set it up on your computer.
  • It is a free power supply with AC90~240V and 50/60Hz.
  • It can communicate with a computer via RS-232C.
  • The distance output is 4-20mA output.
  • RS-422 digital output terminal included.
• Reduced weight and compactness
  • You can hold it with one hand. The antenna has become even lighter and smaller.
  • The burden of installation work has been reduced.
• Flexible Adaptability
  • Both hardware and software can be changed and improved according to your requirements.

Features

• OK in adverse environments
  • The reflector corresponding to the detection head is attached to the high-temperature part and can be used at high temperatures without a cooling device.
  • The antenna and controller can be connected by a circular waveguide or coaxial cable, and the guide pipe and reflector can further move the controller away from the hot part.
  • Microwaves are almost unaffected by temperature, flame, water vapor, airborne dust, and dirt.
  • High accuracy, high reliability
  • The 24GHz antenna is compact and has a sharp beam angle, allowing it to be used in narrow spaces.
  • It reliably captures targets even in environments with large disturbance waves.
  • ± 5mm accuracy.
  • The rotating microwave method is used to eliminate false measurements due to reflected waves twice.
  • Since the measurement distance is automatically calibrated at regular intervals, the measurement accuracy is not affected even if the temperature changes or long-term use are not affected.
  • With a filter function to remove fault waves.
• Monitoring of driving status and abnormal conditions with a computer
  • It continuously displays the received signal waveform, FFT spectral waveform, and measurement trajectory, and can also record, playback, and fast forward as needed.
  • You can easily determine the optimal parameter value while simulating using the recording and playback function.
  • It displays and outputs the temperature and alarms (reception level drop, temperature increase in the main unit, version mismatch, communication error).
• Equipped with useful functions
  • The reference point and measurement range can be set arbitrarily, and the waveguide or coaxial cable length can be easily reduced from the measured value.
  • You can set it up on your computer.
  • It is a free power supply with AC90~240V and 50/60Hz.
  • It can communicate with a computer via RS-232C.
  • The distance output is 4-20mA output.
  • With RS-422 digital input/output terminals.
• Reduced weight and compactness
  • You can hold it with one hand. The antenna has become even lighter and smaller.
  • The burden of installation work has been reduced.
• Flexible Adaptability
  • Both hardware and software can be changed and improved according to your requirements.
• With degree regulator (optional)
  • The mounting angle can be adjusted according to the powder surface situation.

Features

• OK in adverse environments
  • The reflector corresponding to the detection head is attached to the high-temperature part and can be used at high temperatures without a cooling device.
  • The antenna and controller can be connected by a circular waveguide, which can be bent to 90°.
  • Microwaves are almost unaffected by dirt, flames, water vapor, and airborne dust.
• High precision and reliability
  • ± Compatible with 10mm accuracy.
  • The rotating microwave method is used to eliminate false measurements due to reflected waves twice.
  • With a filter function to remove fault waves.
• Monitor the operating status with a computer
  • The measured distance, distance trend can be displayed at all times, and the FFT spectrum, received signal waveform, and various set values can also be displayed.
  • Displays and outputs abnormal conditions (reception level drop, controller temperature rise, communication abnormality).
• Equipped with useful functions
  • The reference point and measurement range can be set arbitrarily, and the waveguide length can be easily reduced from the measured value.
  • You can set it up on your computer.
  • It is a free power supply with AC90~240V and 50/60Hz.
  • RS-422 can communicate with a computer or sequencer.
  • The distance output is 4-20mA output.
• Achieve weight reduction and compactness
  • You can hold it with one hand.
  • The burden of installation work has been reduced.
• Flexible Adaptability
  • Both hardware and software can be changed and improved according to requirements.

Features

• OK
  in adverse environments mmWave is not affected by high temperatures, water vapor, flames, water flowing over the slabs, showers.
  Use the option if you need heat protection.
• 3D surface map and cross-sectional profile display
  The 3D surface map and cross-sectional profile of the measured object are measured in a continuous manner and displayed on a computer.
  The measured data is stored on the hard disk of the data processing PC.
• Integrating the technology and experience cultivated through 3D measurement of high-reliability
  blast furnace interior surfaces. It
  can be measured stably over a long period of time even in a bad environment.
• Compact and simple structureCompact
  and simple, yet easy to maintain.

Features

• Measure and display 3D surface maps and their cross-sectional profiles at any angle.
• It’s compact, simple, and easy to maintain.
• A shutter can be attached to separate the profile meter from inside the furnace.
• Maximum measurement distance 15m

Features

• Measures and displays the profile for each rotation of the feeder.
• Measures and displays the descent speed.
• It’s compact, simple, and easy to maintain.
• Since the profile meter is not inserted or taken out of the blast furnace, the structure is simple and space-saving.
• With a partition valve, the profile meter can be separated from inside the blast furnace.
• No deck required.
• Maximum measurement distance 15m
• With removal of irregular height measurements (hunting, structures in the furnace) (optional)

Lanceless Blast Furnace 2D Profile Meter
ANIMATION

Features

• The 3D surface map and its arbitrary angle profile are measured in approximately 20 seconds per batch.
• The profile of the load immediately after the fall is captured by following the chute, displaying a 3D surface map that shows the fall trajectory with each chute rotation.
• In addition to 3D surface maps, various display functions are provided, including cross-sectional profiles at any angle, descent speed, and received power.
• The product features a compact and simple mechanical scanning mechanism that is easy to maintain, with no dust adhesion on the antenna surface.
• Gas leakage is not a concern.
• The sliding plate, which opens and closes in approximately 7 seconds, protects the profile meter from ultra-hot gases during the atrium.
• The self-diagnostic function detects the amount of deposited dust in the profile meter and indicates when maintenance is required. Water cooling is not included.

Lanceless Blast Furnace 3D Profile Meter
ANIMATION

Features

• The 3D surface map is measured along with its arbitrary angle profile in approximately 20 seconds per batch.
• The profile of the load immediately after the fall is captured by following the chute, displaying a 3D surface map that shows the fall trajectory with each chute rotation.
• In addition to 3D surface maps, various display functions are available, including cross-sectional profiles at any angle, descent speed, and received power.
• The product features a mechanical scanning mechanism that is compact, simple, and easy to maintain, with no dust adhesion on the antenna surface.
• There is no concern about gas leakage.
• The sliding plate, which opens and closes within 7 seconds, protects the profile meter from ultra-hot gases during the atrium.
• The self-diagnostic function detects the amount of deposited dust in the profile meter and signals when maintenance is required.
• Water cooling is not included.

Vertical 3D Profile Meter For Blast Furnace
ANIMATION
