SUNCO | Kouei Japan Trading | Get Quotation

63-4853 Slim Knurled Screw (Boxed)

kvt part2 — Sat, 26 Dec 2020 07:41:45 +0000

Model: 63-4853

Iron (or standard).
Zinc yellow cr6+.

■ Chromate

Standard	Size (mm)		Product Code
Standard	Head Diameter	Thread Dia. × Overall Length	Product Code
25	7.0	3.3×25	9100
28	7.0	3.3×28	9101
32	7.0	3.3×32	9102
38	7.0	3.3×38	9103
41	7.0	3.3×41	9104
45	7.0	3.3×45	9105
51	7.0	3.3×51	9106
57	7.0	3.6×57	9107
65	7.0	3.6×65	9108
75	7.0	3.9×75	9109
90	7.0	4.0×90	9110

The post 63-4853 Slim Knurled Screw (Boxed) first appeared on Kouei Japan Trading | Get Quotation.

63-8470 LIVE Slim Fine Thread Screw

kvt part2 — Sat, 26 Dec 2020 07:41:43 +0000

Model: 63-8470

Dia range:M3.3～M3.9
Length range:25～90

Iron (or standard).
Zinc yellow cr6+.

Unit: mm

Diameter × Length (d × L1)	Thread Pitch	Thread Length L2	Head Diameter D	Phillips Drive	Thread / Tip Shape
3.3 × 25	1.95	17	6.0	No.2	Coarse / Sharp Tip (with Cut)
3.3 × 30	1.95	20	6.0	No.2
3.3 × 35	1.95	22	6.0	No.2
3.3 × 40	1.95	26	6.0	No.2
3.3 × 45	1.95	30	6.0	No.2
3.3 × 50	1.95	35	6.0	No.2
3.8 × 55	2.31	38	7.0	No.2
3.8 × 60	2.31	40	7.0	No.2
3.8 × 65	2.31	45	7.0	No.2
3.8 × 70	2.31	50	7.0	No.2
3.8 × 75	2.31	55	7.0	No.2
3.9 × 90	2.54	60	7.0	No.2

The post 63-8470 LIVE Slim Fine Thread Screw first appeared on Kouei Japan Trading | Get Quotation.

63-87NS No-Break Screw Slim Type

kvt part2 — Sat, 26 Dec 2020 07:41:42 +0000

Model: 63-87NS

Dia range:M3.3～M3.9
Length range:30～90

Iron (or standard).
Trivalent zinc cr+3 color white.

Unit: mm

Part Number	Diameter × Length (d × L1)	Thread Pitch	Thread Length L2	Head Diameter D	Phillips Drive Q	Thread / Tip Shape
NBS30	3.3 × 30	1.95	20	6.0 – 6.5	No.2	Coarse / Special Shape
NBS35	3.3 × 35	1.95	25	6.0 – 6.5	No.2
NBS40	3.3 × 40	1.95	25	6.0 – 6.5	No.2
NBS45	3.3 × 45	1.95	30	6.0 – 6.5	No.2
NBS50	3.3 × 50	1.95	30	6.0 – 6.5	No.2
NBS65	3.7 × 65	2.30	40	7.0 – 7.5	No.2
NBS75	3.7 × 75	2.30	45	7.0 – 7.5	No.2
NBS90	3.9 × 90	2.30	50	8.0 – 8.5	No.2

The post 63-87NS No-Break Screw Slim Type first appeared on Kouei Japan Trading | Get Quotation.

Y5-4ZB0 Be The Weather Tomorrow Slim Type

kvt part2 — Sat, 26 Dec 2020 04:20:46 +0000

Model: Y5-4ZB0

Iron (or standard).
Plain.

The post Y5-4ZB0 Be The Weather Tomorrow Slim Type first appeared on Kouei Japan Trading | Get Quotation.

Q1-0169 Slim Eye Plate (Imported)

kvt part2 — Sat, 26 Dec 2020 04:20:46 +0000

Model: Q1-0169

Iron (or standard), Stainless Steel (303, 304, XM7,…).
Plain, Nickel.

Part Number	D	A	B1	B2	H	h	W	d
IPF1050	5	15	45	35	19.5	12.5	13	4.1
IPF1060	6	20	60	46	24.5	16.5	18	5.1
IPF1080	8	26	80	60	32	22	21	5.1

Part Number	D	A	B1	B2	H	h	W	d
SPF1050	5	15	45	35.5	20	12	14	4.2
SPF1060	6	20	60	46	25	17	16	5.2
SPF1080	8	26	80	60	32	21	20	5.2

The post Q1-0169 Slim Eye Plate (Imported) first appeared on Kouei Japan Trading | Get Quotation.

63-3ASC SITAJI IPPATSU Slim AS

kvt part2 — Sat, 26 Dec 2020 04:20:45 +0000

Model: 63-3ASC

Iron (or standard).
Plain.

Unit: mm

Packing Specification	Product Name	W	H	D	Plate Thickness
C-box	Undercoat, Single Coat As-12mm	13.5	60	12	0.5

The post 63-3ASC SITAJI IPPATSU Slim AS first appeared on Kouei Japan Trading | Get Quotation.

63-3295 Super Slim D4.7 (12 Size)

kvt part2 — Sat, 26 Dec 2020 04:20:44 +0000

Model: 63-3295

Dia range:M2.6～M2.6
Length range:15～50

Iron (or standard).
Zinc yellow cr6+.

Product Name	L	D	S	d
Ultra-thin 15 (Large Head)	15	4.7	10.0	2.6
Ultra-thin 20 (Large Head)	20	4.7	12.0	2.6
Ultra-thin 25 (Large Head)	25	4.7	14.0	2.6
Ultra-thin 27 (Large Head)	27	4.7	14.0	2.6
Ultra-thin 32 (Large Head)	32	4.7	17.0	2.6
Ultra-thin 37 (Large Head)	37	4.7	20.0	2.6
Ultra-thin 45 (Large Head)	45	4.7	23.0	2.6
Ultra-thin 50 (Large Head)	50	4.7	25.0	2.6

The post 63-3295 Super Slim D4.7 (12 Size) first appeared on Kouei Japan Trading | Get Quotation.

63-3306 Super Slim D4.7 (Without Bit)

kvt part2 — Sat, 26 Dec 2020 04:20:42 +0000

Model: 63-3306

Dia range:M2.6～M2.6
Length range:15～50

Iron (or standard).
Zinc yellow cr6+, GB (brown bronze).

Product Name	L	D	S	d
Ultra-thin 15 (Large Head)	15	4.7	10.0	2.6
Ultra-thin 20 (Large Head)	20	4.7	12.0	2.6
Ultra-thin 25 (Large Head)	25	4.7	14.0	2.6
Ultra-thin 27 (Large Head)	27	4.7	14.0	2.6
Ultra-thin 32 (Large Head)	32	4.7	17.0	2.6
Ultra-thin 37 (Large Head)	37	4.7	20.0	2.6
Ultra-thin 45 (Large Head)	45	4.7	23.0	2.6
Ultra-thin 50 (Large Head)	50	4.7	25.0	2.6

The post 63-3306 Super Slim D4.7 (Without Bit) first appeared on Kouei Japan Trading | Get Quotation.

63-332A Super Slim D4.2 (ABOX)

kvt part2 — Sat, 26 Dec 2020 04:20:36 +0000

Model: 63-332A

Dia range:M2.6～M2.6
Length range:15～37

Iron (or standard).
Zinc yellow cr6+, GB (brown bronze).

Product Name	L	D	S	d
Ultra-thin 15 (Small Head)	15	4.2	10.0	2.6
Ultra-thin 20 (Small Head)	20	4.2	12.0	2.6
Ultra-thin 25 (Small Head)	25	4.2	14.0	2.6
Ultra-thin 27 (Small Head)	27	4.2	14.0	2.6
Ultra-thin 32 (Small Head)	32	4.2	17.0	2.6
Ultra-thin 37 (Small Head)	37	4.2	20.0	2.6

The post 63-332A Super Slim D4.2 (ABOX) first appeared on Kouei Japan Trading | Get Quotation.

V0-0488 Sakisubo Slim Torsion B 10pc

kvt part2 — Sat, 26 Dec 2020 04:20:35 +0000

Model: V0-0488

Iron (or standard).
Trivalent zinc cr+3 color white.

The post V0-0488 Sakisubo Slim Torsion B 10pc first appeared on Kouei Japan Trading | Get Quotation.

U0-Y020 AAP Inflatable Anchor Set Slim

kvt part2 — Sat, 26 Dec 2020 04:20:28 +0000

Model: U0-Y020

*Representative image only

Iron (or standard).
Trivalent zinc cr+3 color white.

■ Slim Type
● Test Conditions
Concrete Design Strength: Fc = 21 N/mm²
Bolt Material: SS400

Product Code	Thread Size	Material	Outer Diameter (mm)	Overall Length (mm)	Drill Diameter (mm)	Hole Depth (mm)	Tensile Load (kN)
ZSM10-S	M10	Zinc Die Cast (ZAS)	14.6	26.0	15.0	50	20.1
ZSM10-S	M10		14.6	26.0	15.0	100	34.9
ZSM12-S	M12		17.6	29.0	18.0	50	26.0
ZSM12-S	M12		17.6	29.0	18.0	120	51.8
ZSM16-S	M16		23.6	44.0	24.0	80	46.5
ZSM16-S	M16		23.6	44.0	24.0	160	72.2
ZSM20-S	M20		27.6	50.0	28.0	100	67.3
ZSM20-S	M20		27.6	50.0	28.0	200	113.4

The post U0-Y020 AAP Inflatable Anchor Set Slim first appeared on Kouei Japan Trading | Get Quotation.

50-4511 Thin Washer Head (Slim Box)

kvt part2 — Sat, 26 Dec 2020 04:20:27 +0000

Model: 50-4511

Dia range:M4～M4
Length range:13～25

Iron (or standard).
Trivalent zinc cr+3 color white.

Unit: mm

Product Code	Nominal Size × Overall Length (Thread Length)	Head Diameter	Effective Length	Applicable Plate Thickness
684130W	4 × 13 (13)	10.6	4	1.2 – 3.2
684160W	4 × 16 (16)		7
684190W	4 × 19 (19)		10
684250W	4 × 25 (25)		16

The post 50-4511 Thin Washer Head (Slim Box) first appeared on Kouei Japan Trading | Get Quotation.

50-4506 Flexi Head (Reamea (Slim Box))

kvt part2 — Sat, 26 Dec 2020 04:20:26 +0000

Model: 50-4506

Dia range:M4～M5
Length range:28～60

Iron (or standard).
Trivalent zinc cr+3 color white.

Unit: mm

Product Code	Thread Type	Nominal Size × Overall Length (Thread Length)	Head Diameter	Effective Length	Applicable Plate Thickness
684280R	Fully Threaded	4 × 28 (24)	8.0	16	1.2 – 3.1
684320R		4 × 32 (27)		20
684400R		4 × 40 (35)		28
684450R		4 × 45 (39)		33
685600R	Half Threaded	5 × 60 (42)	9.8	47	1.6 – 4.5

The post 50-4506 Flexi Head (Reamea (Slim Box)) first appeared on Kouei Japan Trading | Get Quotation.

11-A002 Slim Hexagon Head P=2

kvt part2 — Sat, 26 Dec 2020 04:20:25 +0000

Model: 11-A002

Dia range:M6～M6
Length range:10～12

Iron (or standard).
Zinc yellow cr6+, Zinc blue cr6+, Trivalent zinc cr+3 color white, Trivalent zinc cr+3 color black,…

Nominal Thread Size (d)	Pitch	k		s		Spring Washer d1 (Max.)	a (Max.)
Nominal Thread Size (d)	Pitch	Nominal Size	Tolerance	Nominal Size	Tolerance	Spring Washer d1 (Max.)	a (Max.)
M6	1.0	2.5	±0.1	10	0 -0.2	11.5	4.5

The post 11-A002 Slim Hexagon Head P=2 first appeared on Kouei Japan Trading | Get Quotation.

50-4502 Hex Head (DANBA (Slim Box))

kvt part2 — Sat, 26 Dec 2020 04:20:25 +0000

Model: 50-4502

Dia range:M5～M6
Length range:19～35

Iron (or standard).
Trivalent zinc cr+3 color white.

Unit: mm

Product Code	Nominal Size × Overall Length (Thread Length)	Effective Length	Applicable Plate Thickness
685190H	5 × 19 (19)	7	1.6 – 4.5
685250H	5 × 25 (25)	13	1.6 – 4.5
686250H	6 × 25 (25)	11	2.3 – 6.0
686350H	6 × 35 (35)	21	2.3 – 6.0

The post 50-4502 Hex Head (DANBA (Slim Box)) first appeared on Kouei Japan Trading | Get Quotation.

V0-2901 Electric Slim Ratchet Set

kvt part2 — Sat, 26 Dec 2020 04:20:24 +0000

Model: V0-2901

Iron (or standard).
Plain.

The post V0-2901 Electric Slim Ratchet Set first appeared on Kouei Japan Trading | Get Quotation.

U0-9F01 Phoenix (Slimkun)

kvt part2 — Sat, 26 Dec 2020 04:20:23 +0000

Model: U0-9F01

Iron (or standard).
Plain.

Part No.	Overall Length (Folded)	Head Diameter	Applicable Wall Thickness	Screw Diameter	Screw Length	Pilot Hole Diameter
S-1	27.0	12.5	3 mm or more	3.5 – 4.0	27 mm + mounting material thickness	6.0
S-2	29.0		8 mm or more		29 mm + mounting material thickness
S-3	32.0		11 mm or more		32 mm + mounting material thickness

The post U0-9F01 Phoenix (Slimkun) first appeared on Kouei Japan Trading | Get Quotation.

70-B025 Quax Bit 310 For Slim Head

kvt part2 — Sat, 26 Dec 2020 04:20:20 +0000

Model: 70-B025

Iron (or standard).
Plain.

Size	Product Code	Applicable Size	Overall Length	Packaging	Hex Across Flats
1	QS01B50-6.35	M3	50mm	1	6.35
2	QS02B75-6.35	M4	75mm	1	6.35

The post 70-B025 Quax Bit 310 For Slim Head first appeared on Kouei Japan Trading | Get Quotation.

10-A302 (+) Slim Head P=2

kvt part2 — Sat, 26 Dec 2020 04:12:11 +0000

Model: 10-A302

Dia range:M3～M4
Length range:6～16

Iron (or standard).
Trivalent zinc cr+3 color white, Trivalent zinc cr+3 color black, Nickel.

Thread Nominal	Phillips Recess No.	D		H		d1	a	Minimum Clamping Plate Thickness
Thread Nominal	Phillips Recess No.	Standard Dimension	Tolerance	Standard Dimension	Tolerance	Max.	Max.	Minimum Clamping Plate Thickness
M3	1	6.0	0 -0.5	0.8	±0.1	5.5	1.5	0.8
M4	2	8.0	0 -0.5	0.9	±0.1	7	2.15	1.15

The post 10-A302 (+) Slim Head P=2 first appeared on Kouei Japan Trading | Get Quotation.

A0-L200 Slim Head Screw 6-Lobe

kvt part2 — Fri, 18 Dec 2020 04:55:03 +0000

Model: A0-L200

Dia range:M2～M6
Length range:4～40

Iron (or standard), Stainless Steel (303, 304, XM7,…).
Plain, Nickel, Black Nickel.

	M	M2	M2.6	M3	M4	M5	M6
Head Height	K ± 0.1	0.5	0.6	0.8	0.9	1.0	1.2
Head Diameter (D)	D – 0.5	4.0	6.0	7.0	8.0	9.0	12
Drive Size		T4	T5	T6	T8	T10	T20

The post A0-L200 Slim Head Screw 6-Lobe first appeared on Kouei Japan Trading | Get Quotation.

63-SP10 Power Thread (Slim Type)

kvt part2 — Fri, 18 Dec 2020 04:55:02 +0000

Model: 63-SP10

Dia range:M3.4～M3.4
Length range:38～50

Iron (or standard).
Zinc yellow cr6+.

Unit: mm

Product Code	Thread Type	Nominal Diameter (d)	Total Length (L)	Head Diameter (D)	Thread Length (S)
Fine AP-38 Small	Half Thread	3.4	38	6.1	25.0
Fine AP-50 Small	Half Thread	3.4	50	6.1	25.0
Fine AP-65 Small	Half Thread	3.7	65	7.0	33.0
Fine AP-75 Small	Half Thread	3.7	75	7.0	38.0

The post 63-SP10 Power Thread (Slim Type) first appeared on Kouei Japan Trading | Get Quotation.

63-SP1B Power Thread (Slim Type (PCS))

kvt part2 — Fri, 18 Dec 2020 04:54:59 +0000

Model: 63-SP1B

Dia range:M3.7～M3.7
Length range:65～75

Iron (or standard).
Zinc yellow cr6+.

Unit: mm

Product Code	Thread Type	Nominal Diameter (d)	Total Length (L)	Head Diameter (D)	Thread Length (S)
Fine AP-38 Small	Half Thread	3.4	38	6.1	25.0
Fine AP-50 Small	Half Thread	3.4	50	6.1	25.0
Fine AP-65 Small	Half Thread	3.7	65	7.0	33.0
Fine AP-75 Small	Half Thread	3.7	75	7.0	38.0

The post 63-SP1B Power Thread (Slim Type (PCS)) first appeared on Kouei Japan Trading | Get Quotation.

63-3326 Super Slim D4.2 (Without Bit)

kvt part2 — Fri, 18 Dec 2020 04:54:54 +0000

Model: 63-3326

Dia range:M2.6～M2.6
Length range:15～37

Iron (or standard).
Zinc yellow cr6+, GB (brown bronze).

Product Name	Length (L)	Diameter (D)	Thread Length (S)	Thread Diameter (d)
Ultra Fine 15 Head Small	15	4.2	10.0	2.6
Ultra Fine 20 Head Small	20	4.2	12.0	2.6
Ultra Fine 25 Head Small	25	4.2	14.0	2.6
Ultra Fine 27 Head Small	27	4.2	14.0	2.6
Ultra Fine 32 Head Small	32	4.2	17.0	2.6
Ultra Fine 37 Head Small	37	4.2	20.0	2.6

The post 63-3326 Super Slim D4.2 (Without Bit) first appeared on Kouei Japan Trading | Get Quotation.

00-AH00 Intrtorque Screw (Slim Head)

kvt part2 — Fri, 18 Dec 2020 04:54:44 +0000

Model: 00-AH00

Dia range:M3～M4
Length range:3～12

Iron (or standard).
Trivalent zinc cr+3 color white, Trivalent zinc cr+3 color black, Nickel.

Thread Nominal (d)	Pitch	Drive Size	A	φdk		k		φda	l		u
Thread Nominal (d)	Pitch	Drive Size	Reference	Standard Dimensions	Tolerance	Standard Dimensions	Tolerance	Max	Max	Min	Max
M3	0.5	IT6	1.75	7.0	+0 -0.5	0.8	±0.1	3.6	0.5	0.4	1.0
M4	0.7	IT8	2.39	8.0	+0 -0.5	0.9	±0.1	4.7	0.7	0.6	1.4

The post 00-AH00 Intrtorque Screw (Slim Head) first appeared on Kouei Japan Trading | Get Quotation.

10-A002 (+) Slim Pan Head P=2

kvt part2 — Fri, 18 Dec 2020 04:54:37 +0000

Model: 10-A002

Dia range:M4～M4
Length range:8～8

Iron (or standard).
Zinc yellow cr6+, Zinc blue cr6+, Trivalent zinc cr+3 color white, Trivalent zinc cr+3 color black,…

Thread Nominal	Small Thread Body					Washer		a (Maximum)
	dk		k	Cross Hole		Washer
	dk		k	Cross Hole Number	m (Reference)	D1 (Max)	T (Min)
M4	7	0 -0.5	2.2 ±0.5	2	4.2	7	1.0	2.15

The post 10-A002 (+) Slim Pan Head P=2 first appeared on Kouei Japan Trading | Get Quotation.

63-S47T Slim Screw (Import (Value))

kvt part2 — Fri, 18 Dec 2020 04:54:11 +0000

Model: 63-S47T

Dia range:M3.3～M3.9
Length range:25～90

Iron (or standard).
Zinc yellow cr6+, Trivalent zinc cr+3 color white.

Size	Head Diameter (D)	Thread Diameter (d)	Thread Length (S)
3.3×25	6	3.3	19
3.3×30	6	3.3	23
3.3×35	6	3.3	25
3.3×40	6	3.3	30
3.3×45	6	3.3	30
3.3×50	6	3.3	35
3.7×55	7	3.7	40
3.7×60	7	3.7	40
3.7×65	7	3.7	45
3.7×70	7	3.7	50
3.7×75	7	3.7	50
3.9×90	7	3.9	60

The post 63-S47T Slim Screw (Import (Value)) first appeared on Kouei Japan Trading | Get Quotation.

63-S47H Slim Screw (Import (Pack))

kvt part2 — Fri, 18 Dec 2020 03:07:22 +0000

Model: 63-S47H

Dia range:M3.3～M3.9
Length range:35～90

SUS410.
Plain.

Size	Head Diameter (D)	Thread Diameter (d)	Thread Length (S)
3.3×25	6	3.3	19
3.3×30	6	3.3	23
3.3×35	6	3.3	25
3.3×40	6	3.3	30
3.3×45	6	3.3	30
3.3×50	6	3.3	35
3.7×55	7	3.7	40
3.7×60	7	3.7	40
3.7×65	7	3.7	45
3.7×70	7	3.7	50
3.7×75	7	3.7	50
3.9×90	7	3.9	60

The post 63-S47H Slim Screw (Import (Pack)) first appeared on Kouei Japan Trading | Get Quotation.

00-A200 TRX Slim Head (Pack)

kvt part2 — Fri, 18 Dec 2020 03:07:21 +0000

Model: 00-A200

Dia range:M2～M6
Length range:4～30

Iron (or standard).
Trivalent zinc cr+3 color white, Trivalent zinc cr+3 color black, Nickel.

Nominal Diameter (d)	D		H		Drive Size
Nominal Diameter (d)	Standard Size	Tolerance	Standard Size	Tolerance	Drive Size
M2	4.0	0 -0.5	0.5	±0.1	T4
M2.6	6.0	0 -0.5	0.6	±0.1	T5
M3	7.0	0 -0.5	0.8	±0.1	T6
M4	8.0	0 -0.5	0.9	±0.1	T8
M5	9.0	0 -0.5	1.0	±0.1	T10
M6	12.0	0 -0.5	1.2	±0.1	T20

The post 00-A200 TRX Slim Head (Pack) first appeared on Kouei Japan Trading | Get Quotation.

50-4501 Flat Head (DANBA (Slim Box))

kvt part2 — Fri, 18 Dec 2020 03:07:20 +0000

Model: 50-4501

Dia range:M4～M4
Length range:16～50

Iron (or standard), SUS410.
Plain, Trivalent zinc cr+3 color white.

Iron-made (Unit: mm)

Product Code	Nominal Diameter × Total Length (Thread Length)	Head Diameter	Working Length	Applicable Plate Thickness
684160F	4 × 16 (13)	8.0	6	1.2~3.2
684190F	4 × 19 (16)	8.0	9	1.2~3.2
684250F	4 × 25 (22)	8.0	15	1.2~3.2
684430F	4 × 30 (26)	8.0	20	1.2~3.2
684350F	4 × 35 (31)	8.0	25	1.2~3.2
684400F	4 × 40 (36)	8.0	30	1.2~3.2
684450F	4 × 45 (41)	8.0	35	1.2~3.2
684500F	4 × 50 (46)	8.0	40	1.2~3.2

Stainless Steel-made (Unit: mm)

Product Code	Nominal Diameter × Total Length (Thread Length)	Head Diameter	Working Length	Applicable Plate Thickness
68416FP	4 × 16 (13)	8.0	6	1.2~3.2
68419FP	4 × 19 (16)	8.0	9	1.2~3.2
68425FP	4 × 25 (22)	8.0	15	1.2~3.2
68430FP	4 × 30 (26)	8.0	20	1.2~3.2
68440FP	4 × 40 (36)	8.0	30	1.2~3.2

The post 50-4501 Flat Head (DANBA (Slim Box)) first appeared on Kouei Japan Trading | Get Quotation.

50-4500 Pan Head (DANBA (Slim Box))

kvt part2 — Fri, 18 Dec 2020 03:07:19 +0000

Model: 50-4500

Dia range:M4～M4
Length range:13～30

Iron (or standard), SUS410.
Plain, Trivalent zinc cr+3 color white.

Iron-made (Unit: mm)

Product Code	Nominal Diameter × Total Length (Thread Length)	Head Diameter	Working Length	Applicable Plate Thickness
684130N	4 × 13 (13)	4	4	1.2~3.2
684160N	4 × 16 (16)	7	7	1.2~3.2
684190N	4 × 19 (19)	8.2	10	1.2~3.2
684250N	4 × 25 (25)	16	16	1.2~3.2
684300N	4 × 30 (30)	21	21	1.2~3.2

Stainless Steel-made (Unit: mm)

Product Code	Nominal Diameter × Total Length (Thread Length)	Head Diameter	Working Length	Applicable Plate Thickness
68413NP	4 × 13 (13)	4	4	1.2~3.2
68416NP	4 × 16 (16)	7	7	1.2~3.2
68419NP	4 × 19 (19)	8.2	10	1.2~3.2
68425NP	4 × 25 (25)	16	16	1.2~3.2
68430NP	4 × 30 (30)	21	21	1.2~3.2

The post 50-4500 Pan Head (DANBA (Slim Box)) first appeared on Kouei Japan Trading | Get Quotation.

10-A304 (+) Slim Head P=4

kvt part2 — Fri, 18 Dec 2020 03:07:18 +0000

Model: 10-A304

Dia range:M3～M4
Length range:6～40

Iron (or standard).
Trivalent zinc cr+3 color white, Trivalent zinc cr+3 color black, Nickel.

Thread Size	Cross Hole Number	D		H		D1 × T	d		Min. Plate Thickness
Thread Size	Cross Hole Number	Standard Size	Tolerance	Standard Size	Tolerance	D1 × T	Max	Max	Min. Plate Thickness
M3	1	6.0	0	0.8	±0.1	6 × 0.5	5.5	2.1	0.9
M4	2	8.0	-0.5	0.9	±0.1	8 × 0.5	7.0	2.8	1.30

The post 10-A304 (+) Slim Head P=4 first appeared on Kouei Japan Trading | Get Quotation.

60-A000 Slim Head (Heat (2 Thread))

kvt part2 — Fri, 18 Dec 2020 03:07:17 +0000

Model: 60-A000

Dia range:M2.7～M5.1
Length range:13～45

Iron (or standard).
Zinc yellow cr6+, Zinc blue cr6+, Trivalent zinc cr+3 color white, Trivalent zinc cr+3 color black,…

Nominal Diameter	Cross Hole Number	Head Diameter	Head Height
Nominal Diameter	Cross Hole Number	dk	K
2.7	2	5.7	1.0
3.1	2	6.0	1.0
3.5	2	6.7	1.0
3.8	2	7.3	1.0
4.1	2	8.0	1.0
5.1	2	9.8	1.0

The post 60-A000 Slim Head (Heat (2 Thread)) first appeared on Kouei Japan Trading | Get Quotation.

60-A300 + Slim Head Wood Screw

kvt part2 — Fri, 18 Dec 2020 03:07:16 +0000

Model: 60-A300

Dia range:M3.1～M3.8
Length range:16～38

Stainless Steel (303, 304, XM7,…).
Plain, GB (brown bronze), BK (SUS black oxide), Painted White, Painted Black.

Nominal Diameter	Cross Hole Number	d		D		H
Nominal Diameter	Cross Hole Number	Standard Size	Tolerance	Standard Size	Tolerance	Standard Size	Tolerance
3.1	2	3.1	±0.1	6.9	±0.15	1.2	0
3.5	2	3.5	±0.1	7.2	±0.2	1.2	-0.2
3.8	2	3.8	±0.1	7.8	±0.2	1.2	-0.2

The post 60-A300 + Slim Head Wood Screw first appeared on Kouei Japan Trading | Get Quotation.

70-A400 6-Lobe Slim Head 310

kvt part2 — Fri, 18 Dec 2020 03:07:14 +0000

Model: 70-A400

Dia range:M2～M6
Length range:3～40

Iron (or standard), Stainless Steel (303, 304, XM7,…), Aluminum (AL).
Plain, Nickel, Trivalent zinc cr+3 color white, GB (Brown Bronze),…

	M2	M2.6	M3	M4	M5	M6
dk	4	6	7	8	9	12
k	0.5	0.6	0.8	0.9	1.0	1.2
t	0.4	0.5	0.75	0.9	1.0	1.2
Drive	T4	T5	T6	T8	T10	T20
A	30°	30°	30°	30°	30°	30°
Minimum breaking torque	0.4 N·m	0.5 N·m	0.95 N·m	2.3 N·m	4 N·m	10 N·m

The post 70-A400 6-Lobe Slim Head 310 first appeared on Kouei Japan Trading | Get Quotation.

70-AQ00 (+) Quax Slim Head 310

kvt part2 — Fri, 18 Dec 2020 03:07:13 +0000

Model: 70-AQ00

Dia range:M3～M4
Length range:6～16

Iron (or standard), Stainless Steel (303, 304, XM7,…).
Plain, Trivalent zinc cr+3 color white, Trivalent zinc cr+3 color black.

	M3	M4
dk	7	8
k	0.8	0.9
QS No.	1	2
A	Approx. 30°	Approx. 30°
Minimum breaking torque	0.95 N·m	2.3 N

The post 70-AQ00 (+) Quax Slim Head 310 first appeared on Kouei Japan Trading | Get Quotation.

63-041T (+) Tapix Slim D6

kvt part2 — Sat, 05 Dec 2020 06:50:45 +0000

Model: 63-041T

Dia range:M3.3～M3.8
Length range:25～90

Iron (or standard), SUS410.
Plain, Zinc yellow cr6+, Trivalent zinc cr+3 color white, Trivalent zinc cr+3 color black,…

Steel

Size	Length (L)	Screw Diameter (d)	Head Diameter (D)	d1	d2	Pitch (P)	K Size	Color
3.3×25	25	20	6.0	2.30	3.3	12	3.6	Chromate
3.3×32	32	25	6.0	2.30	3.3	12	3.6	Gold
3.3×38	38	25	6.0	2.30	3.3	12	3.6	Chromate
3.3×45	45	32	6.0	2.30	3.3	12	3.6	Gold
3.3×50	50	32	6.0	2.30	3.3	12	3.6	Chromate
3.8×57	57	32	7.2	2.72	3.8	11	3.6	Gold
3.8×65	65	50	7.5	2.72	3.8	11	3.6	Chromate
3.8×75	75	50	7.5	2.72	3.8	11	3.6	Gold
3.8×90	90	50	7.5	2.72	3.8	11	3.6	Chromate

SUS410

Size	Length (L)	Screw Diameter (d)	Head Diameter (D)	d1	d2	Pitch (P)	K Size
3.3×25	25±1.5	20±1.5	6.0±0.1	2.3±0.05	3.3±0.2	12	3.1±0.2
3.3×30	30±1.5	25±1.5	6.1±0.1	2.3±0.05	3.3±0.2	12	3.1±0.2
3.3×35	35±1.5	28±1.5	6.1±0.1	2.3±0.05	3.3±0.2	12	3.1±0.2
3.3×40	40±1.5	32±1.5	6.1±0.1	2.3±0.05	3.3±0.2	12	3.1±0.2
3.3×45	45±1.5	32±1.5	6.1±0.1	2.3±0.05	3.3±0.2	12	3.1±0.2
3.3×50	50±1.5	32±1.5	6.1±0.1	2.3±0.05	3.3±0.2	12	3.1±0.2

The post 63-041T (+) Tapix Slim D6 first appeared on Kouei Japan Trading | Get Quotation.

63-S470 Slim Screw (Import)

kvt part2 — Sat, 05 Dec 2020 06:42:59 +0000

Model: 63-S470

Dia range:M3.3～M3.9
Length range:25～90

Iron (or standard), SUS410.
Plain, Zinc yellow cr6+, Trivalent zinc cr+3 color white.

Size	Head Diameter (D)	Screw Diameter (d)	Thread Length (S)
3.3×25	6	3.3	16
3.3×30	6	3.3	20
3.3×35	6	3.3	22
3.3×40	6	3.3	26
3.3×45	6	3.3	32
3.3×50	6	3.3	35
3.7×55	7	3.7	40
3.7×60	7	3.7	40
3.7×65	7	3.7	45
3.7×70	7	3.7	50
3.7×75	7	3.7	50
3.9×90	7	3.9	60

The post 63-S470 Slim Screw (Import) first appeared on Kouei Japan Trading | Get Quotation.

00-A40 TRX Slim Head

kvt part2 — Sat, 05 Dec 2020 04:46:40 +0000

Model: 00-A40

Dia range:M2～M8
Length range:2～50

Iron (or standard), Brass, Stainless Steel (303, 304, XM7,…).
Plain, Trivalent zinc cr3+ color white, Trivalent zinc cr3+ color black, Nickel,…

Screw Designation (d)	Head Diameter (D)		Standard Dimension (k)		Drive Size
Screw Designation (d)	Standard Dimension	Tolerance	Standard Dimension	Tolerance	Drive Size
M2	4.0	0 -0.5	0.5	±0.1	T4
M2.6	6.0	0 -0.5	0.6	±0.1	T5
M3	7.0	0 -0.5	0.8	±0.1	T6
M4	8.0	0 -0.5	0.9	±0.1	T8
M5	9.0	0 -0.5	1.0	±0.1	T10
M6	12.0	0 -0.5	1.2	±0.1	T20
M8	14.0	0 -0.5	1.5	±0.15	T25

M8 is made of steel only

The post 00-A40 TRX Slim Head first appeared on Kouei Japan Trading | Get Quotation.

63-030S Slim Course Thread Rap

kvt part2 — Sat, 05 Dec 2020 04:46:39 +0000

Model: 63-030S

Dia range:M3.3～M4.2
Length range:30～90

Iron (or standard).
Zinc yellow cr6+, Trivalent zinc cr+3 color white, Trivalent zinc cr+3 color black.

Unit: mm

Size	Head Diameter (D)	Screw Diameter (d)	Thread Length (S)
3.3×30	7.1 ± 0.2	3.3	Full Thread
3.3×35	7.1 ± 0.2	3.3	Full Thread
3.3×40	7.1 ± 0.2	3.3	Full Thread
3.3×45	7.1 ± 0.2	3.3	Full Thread
3.3×50	7.1 ± 0.2	3.3	Full Thread
3.3×55	7.1 ± 0.2	3.3	Full Thread
3.8×60	8.0 ± 0.2	3.8	50
3.8×65	8.0 ± 0.2	3.8	50
4.2×75	8.2 ± 0.2	4.2	50
4.2×90	8.2 ± 0.2	4.2	70

The post 63-030S Slim Course Thread Rap first appeared on Kouei Japan Trading | Get Quotation.

00-A600 Hexagon Socket Slim Head

kvt part2 — Sat, 05 Dec 2020 04:46:38 +0000

Model: 00-A600

Dia range:M2～M8
Length range:3～50

Iron (or standard), Stainless Steel (303, 304, XM7,…), SUS316L.
Plain, Trivalent zinc cr+3 color white, Trivalent zinc cr+3 color black, Nickel,…

Screw Designation (d)	Standard Dimension (D)		Standard Dimension (k)		S	t (MAX)
Screw Designation (d)	Standard Dimension	Tolerance	Standard Dimension	Tolerance	S	t (MAX)
M2	4.0	+0 -0.5	0.5	±0.1	1.3	0.6
M2.5 ※1	5.0	+0 -0.5	0.6	±0.1	1.3	0.7
M2.6	5.0	+0 -0.5	0.6	±0.1	1.3	0.8
M3	6.0	+0 -0.5	0.8	±0.1	1.5	1.1
M4	8.0	+0 -0.5	0.9	±0.1	2.0	1.5
M5	9.0	+0 -0.5	1.0	±0.1	2.5	1.8
M6	10.0	+0 -0.5	1.2	±0.1	3.0	2.2
M8 ※2	13.0	+0 -0.5	1.5	±0.1	4.0	4.2

※1 M2.5 is made of SUS material only.
※2 M8 is made of SUS316L material only.

The post 00-A600 Hexagon Socket Slim Head first appeared on Kouei Japan Trading | Get Quotation.

00-A300 (+) Slim Head

kvt part2 — Sat, 05 Dec 2020 04:46:37 +0000

Model: 00-A300

Dia range:M2～M8
Length range:2～70

Iron (or standard), Brass, Stainless Steel (303, 304, XM7,…), Aluminum (AL), SUS403.
Plain, Zinc yellow cr6+, Zinc blue cr6+, Trivalent zinc cr+3 color white, Trivalent zinc cr+3 color black,…

Unit: mm

Screw Designation	Cross Hole Number (M)	Standard Dimension (D)		Standard Dimension (k)
Screw Designation	Cross Hole Number (M)	Standard Dimension	Tolerance	Standard Dimension	Tolerance
M2	0	4.0	0 -0.5	0.5	±0.1
M2.5	1	5.0	0 -0.5	0.6	±0.1
M2.6	1	5.0	0 -0.5	0.6	±0.1
M3	1	6.0	0 -0.5	0.8	±0.1
M4	2	8.0	0 -0.5	0.9	±0.1
M5	2	9.0	0 -0.5	1.0	±0.1
M6	2	10.0	0 -0.5	1.2	±0.1
M8	3	14.0	0 -0.7	Steel 1.5 SUS 2.0	±0.15

The post 00-A300 (+) Slim Head first appeared on Kouei Japan Trading | Get Quotation.

00-A100 (+) Slim Head (Pack)

kvt part2 — Sat, 05 Dec 2020 04:46:36 +0000

Model: 00-A100

Dia range:M2～M6
Length range:3～30

Iron (or standard).
Trivalent zinc cr3+ color white, Trivalent zinc cr3+ color black, Nickel, Non-Chrome White.

Screw Designation (d)	Standard Dimension (D)		Standard Dimension (H)		Cross Hole Number
Screw Designation (d)	Standard Dimension	Tolerance	Standard Dimension	Tolerance	Cross Hole Number
M2	4.0	0 -0.5	0.5	±0.1	0
M2.6	5.0	0 -0.5	0.6	±0.1	1
M3	6.0	0 -0.5	0.8	±0.1	1
M4	8.0	0 -0.5	0.9	±0.1	2
M5	9.0	0 -0.5	1.0	±0.1	2
M6	10.0	0 -0.5	1.2	±0.1	2

The post 00-A100 (+) Slim Head (Pack) first appeared on Kouei Japan Trading | Get Quotation.
