Daico Thermotec
Daico DV series Drying and Draining Air Blower, High Pressure Blower
Manufacturer: Daico Thermotec Co.,Ltd
Model: DV series
Features
It can be used in a variety of fields that require a high level of cleanliness, such as draining and dust removal from various glass plates for LCDs and PDPs, nozzles for heating devices that spray hot air, semiconductor manufacturing equipment, and food production lines.
It can be completely disassembled, so acid washing and electrolytic polishing (passivation treatment) can be performed reliably to every corner of the interior.
The results of chemical polishing and cleaning can be visually confirmed, ensuring a high level of cleanliness.
Specifications
| DNV | DMV | DLV | DLXV | |
|---|---|---|---|---|
| A | 58 | 70 | 90 | 105 |
| B | 35 | 46 | 60 | 75 |
| C | 39 | 51 | 66 | 81 |
| D | 10 | 10 | 15 | 20 |
| E | 45 | 45 | 65 | 85 |
| F | twenty five | 28 | 48 | 56 |
| G | 10 | 10 | 15 | 20 |
| I | 20 | 20 | twenty five | 30 |
| J | 35 square | 46 squares | 60 square | 75 square |
| M | M6 | M8 | M12 | M16 |
| W | 78.0 | 95.0 | 122.4 | 143.6 |
| H | 66.6 | 83.6 | 107.9 | 129.1 |
| Sw | 1.0 | 0.8 | 0.8 | 0.8 |
| K | PS(Rp)1″ (internal thread) | PS(Rp)1 1/4″ (internal thread) | PS(Rp)1 1/2″ (internal thread) | PS(Rp)2″ (internal thread) |
| L1 | 100 to 200 | 250-500 | 550-700 | 750 to 1300 |
