Diatex Co.
Diatex 9030BK Air-Tightening and Waterproofing Double-Sided Tape
Manufacturer: Diatex Co., Ltd.
Model: 9030BK
Features
- Easy to tear by hands straight: No cutting tool is required
- Scrap-less: face to face contact of adhesive separates without damaging the adhesive
- High weather resistance: High UV and water resistance
- Easy rewind: No need to take off your gloves
- Easy repositionable: No wrinkles and good finishing
Specifications
| Content | Unit | Value | Test method |
|---|---|---|---|
| Thickness | mil (mm) | 9.3 (0.24) | PSTC 133 |
| Peel adhesion – Face side | oz/in (N/cm) | 102 (11.2) | PSTC 101 |
| Peel adhesion – Back side | oz/in (N/cm) | 102 (11.2) | PSTC 101 |
| Shear Adhesion | mil (mm) | 28 (50) | PSTC 107 |
| Breaking Strength | lbf/in (N/cm) | 34 (60) | PSTC 131 |
| Temperature use range | °F | -40 to 200 | MCC method |
Dimensions (mm)
