Hakaru
Hakaru RAC-102PF Rectangular (102 x 102)
Manufacturer: HAKARU PLUS CORPORATION
Model: RAC-102PF
Product Description
This is a rectangular, direct-acting indicating electrical meter that receives an electrical signal and displays the measured power factor. It conforms to the Japanese Industrial Standard JIS C-1102 for direct-acting indicating electrical meters.
Features
- This type is for balanced circuits.
- This is a three-phase, three-wire type.
- The depth is 100mm or less. This allows for smaller (thinner) panels and more efficient use of the space inside the panel.
- With an insulating barrier and terminal cover, it enhances safety and prevents accidents by strengthening insulation between terminals and protecting live parts.
- The bright, easy-to-read scale is designed to fulfill the fundamental function of an indicating instrument.
- We use a strong, flame-retardant molded case material.
- The dimensions are 102 x 102.
