Manufacturer: Hirosugi Instruments Co., Ltd.
Model: ASB-400MBE

Specification

Material
Free-cutting brass (C3604BD)
Cadmium content less than 75 ppm
Process
Black baking treatment (nickel base)

The female thread is nickel plated only
(however, some of the inside of the female thread is black baked).

Exterior drawings

L tolerance:
±0.1 up to L=60,
±0.2 from L=65 to 100,
±0.3 from L=110

Thread diameter (pitch)	L	Part Number	ℓ1
M4 (0.7)	5	ASB-405MBE	Fully threaded
	6	ASB-406MBE
	7	ASB-407MBE
	8	ASB-408MBE
	9	ASB-409MBE
	10	ASB-410MBE
	11	ASB-411MBE
	12	ASB-412MBE
	13	ASB-413MBE
	14	ASB-414MBE
	15	ASB-415MBE
	16	ASB-416MBE
	17	ASB-417MBE
	18	ASB-418MBE
	19	ASB-419MBE
	20	ASB-420MBE
	twenty one	ASB-421MBE	8
	twenty two	ASB-422MBE	8
	twenty three	ASB-423MBE	8
	twenty four	ASB-424MBE	8
	twenty five	ASB-425MBE	8
	26	ASB-426MBE	8
	27	ASB-427MBE	8
	28	ASB-428MBE	8
	29	ASB-429MBE	8
	30	ASB-430MBE	8
	35	ASB-435MBE	8
	40	ASB-440MBE	8
	45	ASB-445MBE	8
	50	ASB-450MBE	8
	55	ASB-455MBE	8
	60	ASB-460MBE	8
	65	ASB-465MBE	8
	70	ASB-470MBE	8
	75	ASB-475MBE	8
	80	ASB-480MBE	8
	85	ASB-485MBE	8
	90	ASB-490MBE	8
	95	ASB-495MBE	8
	100	ASB-4100MBE	8
	110	ASB-4110MBE	8
	120	ASB-4120MBE	8
	130	ASB-4130MBE	8
	140	ASB-4140MBE	8
	150	ASB-4150MBE	8
