Manufacturer: Hirosugi Instruments Co., Ltd.
Model: BSF-600E

Specification

Material

Free-cutting steel (SUM)

process

Trivalent chromium chromate treatment

Exterior drawings

L tolerance:
±0.1 up to L=60
, ±0.2 from L=65 to 100,
±0.3 from L=110

Thread diameter (pitch)	L	Part Number	ℓ1
M6 (1.0)	10	BSF-610E	7
	15	BSF-615E	12
	20	BSF-620E	14
	twenty five	BSF-625E	14
	30	BSF-630E	14
	35	BSF-635E	14
	40	BSF-640E	14
	45	BSF-645E	14
	50	BSF-650E	14
	55	BSF-655E	14
	60	BSF-660E	14
	65	BSF-665E	14
	70	BSF-670E	14
	75	BSF-675E	14
	80	BSF-680E	14
	85	BSF-685E	14
	90	BSF-690E	14
	95	BSF-695E	14
	100	BSF-6100E	14
	110	BSF-6110E	14
	120	BSF-6120E	14
	125	BSF-6125E	14
	130	BSF-6130E	14
	140	BSF-6140E	14
	150	BSF-6150E	14
