Manufacturer: Hirosugi Instruments Co., Ltd.
Model: BSL-500BE

Specification

Material

Lead-free free-cutting aluminum (CB156)
Lead content 10 ppm or less

process

Black anodized aluminum (BAL)

Exterior drawings

L tolerance:
±0.1 up to L=60
, ±0.2 from L=65 to 100,
±0.3 from L=110

Thread diameter (pitch)	L	Part Number	ℓ1
M5 (0.8)	8	BSL-508BE	5
	10	BSL-510BE	7
	12	BSL-512BE	9
	15	BSL-515BE	10
	18	BSL-518BE	10
	20	BSL-520BE	10
	twenty five	BSL-525BE	10
	30	BSL-530BE	10
	35	BSL-535BE	10
	40	BSL-540BE	10
	45	BSL-545BE	10
	50	BSL-550BE	10
	55	BSL-555BE	10
	60	BSL-560BE	10
	65	BSL-565BE	10
	70	BSL-570BE	10
	75	BSL-575BE	10
	80	BSL-580BE	10
	85	BSL-585BE	10
	90	BSL-590BE	10
	95	BSL-595BE	10
	100	BSL-5100BE	10
	110	BSL-5110BE	10
	120	BSL-5120BE	10
	125	BSL-5125BE	10
	130	BSL-5130BE	10
	140	BSL-5140BE	10
	150	BSL-5150BE	10
	50	BSL-450BE	8
	55	BSL-455BE	8
	60	BSL-460BE	8
	65	BSL-465BE	8
	70	BSL-470BE	8
	75	BSL-475BE	8
	80	BSL-480BE	8
	85	BSL-485BE	8
	90	BSL-490BE	8
	95	BSL-495BE	8
	100	BSL-4100BE	8
	110	BSL-4110BE	8
	120	BSL-4120BE	8
	130	BSL-4130BE	8
	140	BSL-4140BE	8
	150	BSL-4150BE	8
