Manufacturer: Hirosugi Instruments Co., Ltd.
Model: LSU-600-15

Specification

Material

Free-cutting stainless steel (SUS303)

process

Degreasing

Exterior drawings

L tolerance:
up to L=60 ±0.1,
L=65 to 100 ±0.2,
L=110 and above ±0.3

Thread diameter (pitch)	L	Part Number	ℓ1
M6 (1.0)	10	LSU-610-15	7
	15	LSU-615-15	12
	20	LSU-620-15	14
	twenty five	LSU-625-15	14
	30	LSU-630-15	14
	35	LSU-635-15	14
	40	LSU-640-15	14
	45	LSU-645-15	14
	50	LSU-650-15	14
	55	LSU-655-15	14
	60	LSU-660-15	14
	65	LSU-665-15	14
	70	LSU-670-15	14
	75	LSU-675-15	14
	80	LSU-680-15	14
	85	LSU-685-15	14
	90	LSU-690-15	14
	95	LSU-695-15	14
	100	LSU-6100-15	14
	110	LSU-6110-15	14
	120	LSU-6120-15	14
	125	LSU-6125-15	14
	130	LSU-6130-15	14
	140	LSU-6140-15	14
	150	LSU-6150-15	14
