Japan, Kitagawa
KITAGAWA Y-R series Rotary Cylinder

Made in Japan
Manufacturer: Kitagawa
Model: Y-R series
Feature:
Built-in check valve and relief valve.
Specification:
Model | Y0715R | Y1020R | Y1225R | Y1530R | Y2035R | |
---|---|---|---|---|---|---|
Piston Stroke (mm) | 15 | 20 | 25 | 30 | 35 | |
Piston Area (cm2) | Push Side | 44 | 86 | 122 | 176 | 314 |
Pull Side | 37 | 79 | 113 | 160 | 290 | |
Draw Bar Thrust (kN) | Push Side | 16.6 | 32 | 46 | 66 | 117 |
Pull Side | 13.9 | 29 | 42 | 60 | 108 | |
Max. Operation Pressure (MPa) | 4 | 4 | 4 | 4 | 4 | |
Max. Speed (min-1) | 6000 | 6000 | 6000 | 5500 | 5500 | |
Moment of Inertia (kg・m2) | 0.003 | 0.013 | 0.023 | 0.048 | 0.098 | |
Total Leakage (L/min) | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | |
Net Weight (kg) | 4 | 7.1 | 10 | 13.5 | 22 |
