Kitz UN Stainless & High Alloy 10K Lift Check Valve
Manufacturer: Kitz
Model: UN
Structure
Materials
| Parts | UN |
|---|---|
| Body | SCS13A |
| Cap | 304SS |
| Disc | 304SS |
| Face to face dimensions: | JIS B2011 |
|---|---|
| End thread dimensions: | JIS B0203 |
| Wall thickness: | KITZ Std. |
Dimensions
| Nominal Size | 3/8 | 1/2 | 3/4 | 1 | 1¼ | 1½ | 2 | |
|---|---|---|---|---|---|---|---|---|
| 10 | 15 | 20 | 25 | 32 | 40 | 50 | ||
| L | 55 | 65 | 80 | 90 | 105 | 120 | 140 | |
| H | 50 | 53 | 54 | 62 | 66 | 76 | 85 | |
