Nansin Co., Ltd.
Nansin STC-75 NTB Caster
Manufacturer: Nansin Co., Ltd.:
Model: STC-75 NTB
Model: STC-75 NTB
Features
| Feature | Specification |
| Product Name | STC-75 NTB |
| Wheel type | Urethane (contains B) |
| Wheel diameter (D) | 75 mm |
| Permissible load | 60 daN |
| Starting force | 4.8 daN |
| Turning starting force | 28.8 daN |
| Wheel width (W) | 27 mm |
| Mounting height (H) | 93 mm |
| Mounting pitch (A×B(A’×B’)) | 55 × 42 (54 × 44) mm |
| Plate size (X×Y) | 70 × 58 mm |
| Mounting hole diameter (P) | 8.8 mm |
| Eccentricity (E) | 25 mm |
| Turning radius (R) | 65 mm |
