Manufacturer: Sakaguchi Electric Heaters CO., LTD.
Features
- Mica is glued together with silicone, then heated and compressed to completely cure the adhesive at a higher temperature.
- It has excellent water resistance and exhibits high electrical insulation in high-humidity atmospheres.
- It is a product that produces less smoke, odor, gas generation, and mica swelling in high humidity.
- It has excellent mechanical and punching workability.
- In addition to UL94 V-0, the product has a thermal index of 746B (electrical properties 750°C, mechanical properties 450°C). (UL File No.E58537)
Specifications
| Dimensions (mm) | Thickness (mm) | Product Code |
|---|
| 600×1000 | 0.3 | ZMC03 |
| 600×1000 | 0.5 | ZMC05 |
| 600×1000 | 1.0 | ZMC10 |
| 275×250 | 0.3 | ZMC0381 |
| 275×250 | 0.5 | ZMC0581 |
| 275×250 | 1.0 | ZMC181 |
