Sinfonia Controller for RV Conveyor and Spiral Elevator Vibrating Equipment

Manufacturer: Sinfonia Technology co., LTD, Ltd.
Model: Controller for RV Conveyor and Spiral Elevator

Features

Start up and shut down can be easily controlled with one button.
A reverse phase braking force occurs at the time of vibrating motor shut down, which makes a conveyor quick stop. This prevents free-shaking and material flow.
Furthermore, reversed phase braking time can be adjusted by a timer, which enables to stop vibration in a suitable time.

Specifications

Standard Specifications

Model	Rating (50/60Hz) Current capacity (A)		Gross weight (kg)	Applicable load type
Model	200/220V	400/440V	Gross weight (kg)	Applicable load type
ORV-14×2R	3/2	–	20	RV-14D
ORV-24×2R	5/3	–	20	RV-24D
ORV-44×2R	6/4	–	20	RV-44D
ORV-74×2R	9/5	–	20	RV-74D
ORV-154×2R	15/8	–	30	RV-154D
ORV-224×2R	21/11	–	30	RV-224D
ORV- 78×2R	10/6	–	20	RV-78D
ORV-158×2R	19/10	–	30	RV-158D
ORV-228×2R	17/9	–	30	RV-228D
ORV-378×2R	27	–	60	RV-378D
ORV-378×2R	–	14	30	RV-378D
ORV-558×2R	31	–	60	RV-558D
ORV-558×2R	–	16	30	RV-558D
ORV-758×2R	41/21	–	60	RV-758D

１. All ratings are continuous.
２. All models are indoor wall type, and higher models are dustproof design.
３. The coating color of inner and outer surface is both Munsell 5Y7/1.

Dimensions/Connection Diagram

Dimensions

Unit: mm

Model	A	B	C	D	E	F	G	H	J
ORV-14×2R	400	500	220	300	540	15	11	26	26
ORV-24×2R	400	500	220	300	540	15	11	26	26
ORV-44×2R	400	500	220	300	540	15	11	26	26
ORV-74×2R	400	500	220	300	540	15	11	26	26
ORV-154×2R	450	600	220	350	640	20	14	26	26
ORV-224×2R	450	600	220	350	640	20	14	26	26
ORV- 78×2R	400	500	220	300	540	15	11	26	26
ORV-158×2R	450	600	220	350	640	20	14	26	26
ORV-228×2R	450	600	220	350	640	20	14	26	26
ORV-378×2R (200/220V)	500	800	270	400	840	20	14	42	26
ORV-378×2R (400/440V)	450	600	220	350	640	20	14	26	26
ORV-558×2R (200/220V)	500	800	270	400	840	20	14	42	26
ORV-558×2R (400/440V)	450	600	220	350	640	20	14	26	26
ORV-758×2R	500	800	270	400	840	20	14	42	42
