Venn Co.
Venn FD-9N type constant flow valve (for overflow limit / water supply)
Manufacturer: Venn Co., Ltd.
Model: FD-9N
Features
- We have a lineup of abundant set flow rates.
- The internal constant flow cartridge can replace and maintain.
- Due to the elasticity of the original rubber, stable constant flow rate control performed.
Specifications
| Product code | FD9N-F |
|---|---|
| Valve type | Constant flow valve |
| Use | Water supply (overflow limit) |
| Nominal diameter | 25-50 (1-2) |
| Applicable fluid | Tap water |
| Fluid temperature | 5-40 |
| Primary side applied pressure | 1.0MPa or less |
| Operating differential pressure range | 0.1-0.7MPa or 0.2-0.5MPa |
| Set flow rate / symbol | Tolerance 20-270 L / min: Within ± 20% of set flow rate |
| End connection | JIS Rc screw |
| Mounting posture | Horizontal / vertical freedom |
| Material body | CAC |
| Material cartridge | POM resin, EPDM |
