Venn Co.
Venn PS-43C Solenoid Valve (for Steam, Liquid, and Air)
Manufacturer: Venn Co., Ltd.
Model: PS-43C
Features
- It is more than three times as durable as our conventional products.
- It features a built-in strainer.
- The strainer plug is easy to remove, and the strainer can be easily cleaned without the need for special tools.
- For nominal diameters of 25 or less, the coil exterior makes of heat-resistant thermosetting resin.
Specification
| Product Symbol | PS43C-W |
|---|---|
| Types | piston |
| Activate | Energized and closed |
| Nominal diameter | 15～50（1/2～2） |
| Applicable fluids | Steam, water, air, oil (about kerosene, light oil) |
| Fluid temperature | 5~180°C (100°C or less for hot water) |
| Fluid viscosity | Below 20cSt |
| Application pressure | 0～1.0MPa |
| Minimum differential pressure before and after the valve | 0 MPa (0.03 MPa if the coil is horizontal) |
