YAMAGUCHI GIKEN YPC-225 Auto Spray Guns (Boll Joint Type)
Manufacturer: YAMAGUCHI GIKEN co., ltd.
Model: YPC-225 (Boll Joint Type)
Feature
- Dedicated to a water-soluble panel cassette.
- There are wide variety, such as the fixed nozzle type, the sphere type which can change the spraying direction, wide and spot type nozzles.
Spray quantity
| Type | Liquid Pressure | |||||
|---|---|---|---|---|---|---|
| 0.1 MPa | 0.15 MPa | 0.2 MPa | 0.3 MPa | 0.4 MPa | ||
| Ball Joint | Circle #1 | 235 cc/min | 500 cc/min | 730 cc/min | 1400 cc/min | 1850 cc/min |
| Circle #2 | × | 270 cc/min | 490 cc/min | 1180 cc/min | 1690 cc/min | |
| Circle #3 | × | × | 260 cc/min | 730 cc/min | 1400 cc/min | |
| Circle #4 | 730 cc/min | 1200 cc/min | 1500 cc/min | 2040 cc/min | 2500 cc/min | |
| Circle #5 | 670 cc/min | 1100 cc/min | 1380 cc/min | 1960 cc/min | 2390 cc/min | |
| Flat | 175 cc/min | 420 cc/min | 730 cc/min | 1360 cc/min | 1825 cc/min | |
Spray pattern
| Type | Distance | ||||
|---|---|---|---|---|---|
| 50 mm | 100 mm | 150 mm | 200 mm | ||
| Ball Joint | Circle #1 | φ 40 | φ 70 | φ 100 | φ 110 |
| Circle #2 | φ 20 | φ 35 | φ 55 | φ 65 | |
| Circle #3 | φ 10 | φ 15 | φ 20 | φ 25 | |
| Circle #4 | φ 15 | φ 20 | φ 35 | – | |
| Circle #5 | φ 15 | φ 25 | φ 35 | φ 40 | |
| Flat | – | – | – | – | |
