Diatex Co.
Diatex 1009GR Multi-Purpose Masking Protection, and Repair Tape (Translucent Green)
Manufacturer: Diatex Co., Ltd.
Model: 1009GR
Features
- Easy to tear by hands straight: No cutting tool is required
- Scrap-less: face to face contact of adhesive separates without damaging the adhesive
- High weather resistance: Residue free removal even after 1 month
- Easy repositionable: No wrinkles and good finishing
- ASTM E 84(UL 723): Class 1, Flame Spread Index 5, Smoke Developed Index 0
Specifications
| Content | Unit | Value | Test method |
|---|---|---|---|
| Thickness | mil (mm) | 4.4 (0.16) | PSTC 133 |
| Peel adhesion | oz/in (N/cm) | 36 (4.0) | PSTC 101 |
| Shear adhesion | mil (mm) | 3.9 (0.1) | PSTC 107 |
| Breaking strength | lbf/in (N/cm) | 34 (60) | PSTC 131 |
| Elongation | % | 15 | PSTC 131 |
| Temperature use range | °F | -40 to 200 | MCC method |
Dimensions (mm)
