Diatex Co.
Diatex 3020SB Seaming Tape for House Wrap, Waterproofing and Repair
Manufacturer: Diatex Co., Ltd.
Model: 3020SB
Features
- Easy to tear by hands straight: No cutting tool is required
- Scrap-less: face to face contact of adhesive separates without damaging the adhesive
- Repositionable – no wrinkles
- Good adhesion on rough surfaces
Specifications
| Content | Unit | Value | Test method |
|---|---|---|---|
| Thickness | mil (mm) | 5.9 (0.15) | PSTC 133 |
| Peel adhesion | oz/in (N/cm) | 90 (10) | PSTC 101 |
| Shear adhesion | mil (mm) | 3.9 (0.1) | PSTC 107 |
| Breaking strength | lbf/in (N/cm) | 34 (60) | PSTC 131 |
| Elongation | % | 15 | PSTC 131 |
| Temperature use range | °F | -40 to 200 | MCC method |
