Diatex 3040BK Self-Adhering Flashing Tape
Manufacturer: Diatex Co., Ltd.
Model: 3040BK
Features
- Meets AAMA 711-13; Type A (without primer), Level 3 (exposure up to 176°F) and AC 148
- Easy to tear by hands straight: No cutting tool is required
- Scrap-less: face to face contact of adhesive separates without damaging the adhesive
- Light weight: 50 to 70% lighter than conventional window flashing tape
Specifications
| Content | Unit | Value | Test method |
|---|---|---|---|
| Thickness | mil (mm) | 9.4 (0.24) | PSTC 133 |
| Peel adhesion | oz/in (N/cm) | 136 (15) | PSTC 101 |
| Shear adhesion | mil (mm) | 39 (1.0) | PSTC 107 |
| Breaking strength | lbf/in (N/cm) | 44.5 (78) | PSTC 131 |
| Elongation | % | 17 | PSTC 131 |
| Temperature use range | °F | -40 to 200 | MCC method |
Dimensions (mm)
