Kyoei Electric Co., Ltd. SRC30 Slip Ring

Manufacturer: Kyoei Electric Co., Ltd.
Model: SRC30
Features
Specifications
| Number of Poles | 4 to 20 poles |
| Voltage | AC/DC 100V or less |
| Allowable Current | 1A |
| Allowable Rotation Speed | 400 rpm |
| Inner Diameter / Outer Diameter | 10 mm / 30 mm |
| Environmental Compliance | RoHS2 compliant |
◆Dimensional drawings


| Number of poles | Length |
| 4 | 30 |
| 8 | 42 |
| 12 | 54 |
| 16 | 66 |
| 20 | 78 |
