Tohkemy Corporation
Tohkemy Verozon CDL Series Unit Systems
Manufacturer: Tohkemy Corporation
Model: Verozon CDL Series
Features
Economical batch chlorine dioxide generator for low volume applications
“Two-component method” using 7.5% sodium chlorite and 9% hydrochloric acid
Simple functionality realizes low cost and highly reliable generation controllability
The generator maximizes operational safety by producing chlorine dioxide at dilute concentrations (2,000 mg/L; 1,000 mg/L for CDLb6 models).
An integrated buffer tank holds the generated solution prior to continuous dosing.
This stabilized aqueous solution retains its efficacy during storage, enabling seamless support for batch, on-demand, or intermittent treatment cycles.
Measurement and liquid transfer using a measurement vessel eliminates the need to calibrate the metering pump.
Specification
| model | ClO2Amount generated (maximum)(g/h) | ClO2Water concentration (mg/L) | Maximum chemical consumption | ClO2Maximum chemical consumption (L/h) *1 | Reference amount of treated water (m3/h) *2 | size (mm) | mass (kg) | power consumption (w) | |
|---|---|---|---|---|---|---|---|---|---|
| NaClO2 (L/h) | HCl (L/h) | ||||||||
| CDLb 6 | 6 | 1,000 | 0.15 | 0.15 | 8 | 12 | 1236 x 878 x 306 | 41 | 40 |
| CDLb 12 | 12 | 2,000 | 0.3 | 0.3 | 8 | 24 | 1236 x 878 x 306 | 42 | 40 |
| CDLb 22 | 22 | 2,000 | 0.55 | 0.55 | 11 | 44 | 1236 x 878 x 306 | 46 | 40 |
| CDLb 55 | 55 | 2,000 | 1.375 | 1.375 | 30 | 110 | 1550 x 800 x 345 | 73 | 90 |
| CDLb 120 | 120 | 2,000 | 3 | 3 | 60 | 240 | 1300 x 880 x425 | 85 | 120 |
1: Amount of 2,000 (1,000) mg / L chlorine dioxide water that can be supplied mixed with diluted water
2: Reference value when the injection concentration is 0.5 mg / L
Power supply voltage 100-230VAC ± 10% 50/60 Hz
