Venn Co.
Venn WS-40N type solenoid valve with manual mechanism
Manufacturer: Venn Co., Ltd.
Model: WS-40N
Features
- This product complies with the performance standards of the Water Supply Act.
- In addition, it features a manual opening and closing mechanism.
- As a result, the main valve can operate using fluid pressure.
- Moreover, it equips with a water hammer mitigation mechanism.
- Furthermore, a tube end core can attach.
Specifications
| Product code | WS40N-F |
|---|---|
| type | With manual mechanism |
| Nominal diameter | 15~25 (1/2~1) |
| Fluid temperature | Water / tap water |
| Applicable pressure | 0.03~1.0MPa |
| Minimum differential pressure before and after the valve | 0.03MPa |
| Rated voltage | AC100 / 200V 50 / 60Hz AC110 / 220V 60Hz shared |
| Protective structure | Dustproof, splashproof, indoor use |
| End connection | JIS Rc screws |
| Rated current | AC100V: 0.21A AC200V: 0.10A |
| Starting current | AC100V: 0.70A AC200V: 0.35A |
| Material body | CAC |
| Material diaphragm | NBR |
