Yamato Protec Corporation
Yamato Protec Tree Mist Microfog C

Manufacturer: Yamato Protec Corporation
Model: Tree Mist
High-pressure spray nozzle
| Model | YMH-5C-1.5SU | ||
|---|---|---|---|
| Operating pressure range | 2.0–6.0 MPa | ||
| Spray volume (per nozzle) | Approx. 40mL/min (at 6.0MPa water discharge) | ||
| Spray particle diameter (Sauter average diameter) | Approximately 17μm (at 6.0MPa water discharge) | ||
| Number of nozzles installed | 6 pieces | ||
The Tokyo Metropolitan Government, Osaka Prefecture, and other municipalities offer subsidy programs for the installation of misting systems, so please check those programs if you are considering installation.
Please note that the subsidy application window will close immediately once the allocated budget is fully exhausted.
System Features
This is the “Tree Mist” object-type micro fog light C, a high-pressure type that sprays a fine mist.
Complemented by illuminated branch tips, this unit seamlessly transitions into a striking decorative art piece during the off-season.
Recommended installation location
Since freestanding tree mist requires no structural installation work, it can be placed anywhere. It is also recommended for installation in tenant buildings and event venues.
Control unit
| type | 1L type | 2L type | 4L type |
|---|---|---|---|
| Model | YMS-CH-WM1002/B | YMS-CH-SW1M-0.5mini | YMS-CH-SW1M-22mini |
| Input power | AC100V | ||
| Driving control | Intermittent operation controlled by a timer | ||
| Pump maximum discharge pressure | 6 MPa | ||
| Pump discharge volume | 0.9L/min (50Hz) 1.0L/min (60Hz) | 1.7L/min (50Hz) 2.0L/min (60Hz) | 3.3L/min (50Hz) 4.0L/min (60Hz) |
| Pump motor output | 0.2kW | 0.4kW | 0.75kW |
