APPIE
APPIE JIS Test Powders1 JIS Z 8901 (Class 5,10 Fly Ash)
Manufacturer: The Association of Powder Process Industry and Engineering (APPIE)
Model: JIS Z 8901 (Class 5,10 Fly ash)
Standard
Reference standard:JIS Z 8901
- Material：Fly ash
- Particle density：1.95∼2.3g/cm3
Chemical component
| Chemical component | % ( weight ) |
|---|---|
| SiO2 | 45 (min.) |
| Moisture content | 1 (max.) |
| Ignition Loss | 5 (max.) |
Particle size distribution
- Class5: Sieving(Top size 106µm), Sedimentation Method
Class10: Sedimentation Method
| Particle size µm | Oversize(weight basis)% | |
|---|---|---|
| Class 5 | Class 10 | |
| 2 | – | 82±5 |
| 4 | – | 60±5 |
| 5 | 84±5 | – |
| 8 | – | 22±3 |
| 10 | 60±5 | – |
| 16 | – | 3±3 |
| 20 | 32±3 | |
| 30 | 15±3 | |
| 40 | 8±3 | |
| 106 | 1 (max.) | |
Electron Microscopic Photograph
Test Powders 1-Class5（Fly ash ）（SEM）
Test Powders 1-Class10（Fly ash ）（SEM）
