APPIE
APPIE SAP Test Powders 3 Class 2 STP3-2 Talc
Manufacturer: The Association of Powder Process Industry and Engineering (APPIE)
Material: Talc
particle density : 2.7∼2.9 g/cm3
Chemical component
| Chemical component | % ( weight ) |
|---|---|
| SiO2 | 60∼63 |
| Fe2O3 | 0∼3 |
| AI2O3 | 0∼3 |
| CaO | 0∼2 |
| MgO | 30∼34 |
| Ignition Loss | 3∼7 |
Particle size distribution – measured by Laser Diffraction-Scattering Method
| Undersize (volume%) | Particle size range ( µm ) |
|---|---|
| 10 | 1.7~2.9 |
| 20 | 2.3~3.9 |
| 30 | 2.7~4.6 |
| 40 | 3.1~5.3 |
| 50 | 3.6~6.1 |
| 60 | 4.0~6.9 |
| 70 | 4.4~7.6 |
| 80 | 5.1~8.7 |
| 90 | 6.3~11 |
