Features

1. Safe and easy installation using existing azbil DCS (Advanced-PS/TDCS3000, Harmonas-DEO)
Replacement only of base unit IO module with HART-compatible module
No need to upgrade DCS or change software
2. Solution for HART’s weak point, slow communication
Online trend diagnostics with high-speed communications
At HART’s full speed of 1200 bps, high-speed communication almost equal to that of FOUNDATION fieldbus is achieved
3. Emergency notification of field device error
If the field device diagnostic function detects an emergency, the device error alert is issued to notify that an emergency response is required. It is also possible to notify remote places connected by LAN by turning on a police lamp.

Function

Dramatically streamline loop checking by aligning it to your workflow
Loop checking is supported by the following work units to improve the efficiency of pre-start inspection work.
1. Checking field equipment for survival and continuity
2. Commissioning of field equipment
3. Checking outputs to see if field devices are measuring values correctly
4. 3-point and 5-point check (HART communication only)

Safer Interlock & Sequence Testing: Allows batch-simulated inputs for multiple HART devices simultaneously. This eliminates manual on-site adjustments and wire disconnections, significantly reducing errors and enhancing safety.
Advanced Valve Diagnostics (Valstaff): Integrates with the Valstaff system to continuously monitor Azbil smart valve positioners (AVP_02/03), enabling early malfunction detection and data visualization for smarter maintenance decisions.
High Capacity: Supports connections for up to 3,000 field devices across both HART and FOUNDATION Fieldbus protocols.
Multi-Vendor Configuration: Seamlessly calibrates and configures devices from various vendors using standard DTM, DD, or EDD files.
