CCS OPPD-30G Digital Control Units
Manufacturer: CCS Inc.
Model: OPPD-30G
Features
- GigE Vision compliant LED Lighting Controller.
- Brightness/temperature monitoring and feedback control.
Specifications
| Applicable Light Unit (output ratings) | 30 W max. (total for 2 channels) |
|---|---|
| Number of channels | 2 channels |
| Intensity control | PWM intensity control, Frequency: 50/100/99/98/97 kHz |
| Input voltage | 24 VDC±10% |
| Output voltage | PWM mode: 12 VDC |
| Output current | 2.5 A max. (total for 2 channels) |
| Current consumption | 1.3 A max. |
| Monitoring | Lighting brightness monitor / Lighting internal temperature monitor, Monitor brightness alarm upper/lower limit value setting |
| Feedback | PWM correction method |
| External control protocol | GigE Vision compliant |
| Communication interface | Ethernet 10BASE-T/100BASE-TX, Auto MDI-X |
| Protective functions | Overcurrent, controller internal temperature monitoring (PWM output cut to 1/4 at 105°C) |
| Conformed standards | Conforms to EN 61326-1: 2013, EN 55011: 2009 / A1: 2010 Group 1, Class A Conforms to EMC (2014/30/EU) / RoHS (2011/65/EU, directive 32) |
| Operating temperature and humidity | 0 to 40°C / 35 to 85% RH (no condensation) |
| Storage temperature and humidity | -20 to 70°C / 35 to 95% RH (no condensation) |
| Weight | 150 g |
| Material | Housing: Polycarbonate and aluminum |
| Accessories | Instruction manual, Terminal block |
Dimensions (mm)
