Datalink ATS005T-W075U (standard) Series AC Adapter
Manufacturer: DataLink
Model: ATS005T-W075U (standard)
Features
- The AC adapters, whether sold separately or included, may be replaced with equivalent products.
- When ordering the standard model ATS005T-W075U, please specify the model number “ATS005T-W075U.”
- ATS005T-W075U is the successor model to “STD-07510U.”
Specifications
| Item | Details |
|---|---|
| Operating Conditions | Temperature: +0°C to +40°C Humidity: +20% to 80% RH (non-condensing) |
| Storage Conditions | Temperature: -20°C to +80°C Humidity: +10% to 90% RH (non-condensing) |
| Dimensions | Width: 56.0 mm Height: 59.0 mm (including AC plug) Depth: 28.0 mm Cord Length: 1500 mm ±30 (excluding DC plug) |
| Weight | Approx. 80g |
| Specifications | Input: AC100V to 240V, 50/60Hz Output: DC7.5V / 0 to 1.0A |
| Input Voltage Range | AC100V to 240V, 50/60Hz |
| Output Voltage | DC7.5V ± 5% |
| Output Plug | Outer Diameter: 4.75φ ±0.1 Inner Diameter: 1.7φ ±0.1 Length: 9.5 ±0.3 (EIAJ RC5320, Voltage Class 3, Standard) Center: Positive / Outside: Negative |
| Safety Standard | PSE |
| Environmental Compliance | RoHS2 Compliant |
