DEICY
Deicy KS91 One Axis Small And Lightweight Subminiature Type
Manufacturer: DEICY Co., Ltd.
Model: KS91
Features
- A compact and lightweight single-axis acceleration sensor with a mass of 1.0g and a height of 7.5mm.
- For attaching to lightweight measurement targets.
Specifications
| Model | KS91 |
|---|---|
| Purpose | Measurement · Small Size Base |
| Number of Axes | 1 |
| Sensitivity (mV/G) | 10 |
| Maximum Usable Acceleration (G) | 700 |
| Frequency Characteristics (Hz ± 3 dB) | 4 ~ 26,000 |
| Common Mode Frequency (Hz) | >50 (+25 dB) |
| Operating Temperature Range (°C) | -20 ~ 120 |
| Weight (g) | 1 (Excluding cable) |
| Constant Current (mA) | 2 ~ 20 |
| Shape | Share Type |
| Cable Direction | Straight Wire |
| Connector | Straight 1.5m Lead UNF10-32 3/4 |
| Attachment Method | Adhesive |
| Case Material | Aluminum/SUS |
| Dimensions (mm) | 7.8 Ø x 7.3H |
| Suitable Cable | 016 Cable: Extended Length Clutch (UNF10-32) |
| Cable Recommendation | 051/10 (10m, 80°C) · Extension Cable (10m) UNF10-32 (BNC optional) |
