Deicy N Series Liquid-Filled Capacitive Inclination Sensor
Manufacturer: DEICY Co., Ltd.
Model: N Series
Features
- This inclination angle sensor is available in three models with measurement angle ranges of ±10°/30°/70°
Specifications
| Item | N2 | N3 | N4 |
|---|---|---|---|
| Measuring Range | ±10° | ±30° | ±70° |
| Resolution | <0.002° | <0.005° | <0.01° |
| Non-linearity | 0.04° | 0.12° | 0.28° |
| Horizontal Sensitivity | <1% (±30°) | <1% (±30°) | <1% (±30°) |
| Response Time | Approx. 0.3 sec | Approx. 0.3 sec | Approx. 0.3 sec |
| Power Supply | Ubn=5V DC | Ubn=5V DC | Ubn=5V DC |
| Input Voltage Range | Ubz=3~6V DC | Ubz=3~6V DC | Ubz=3~6V DC |
| Current Consumption | Approx. 1mA | Approx. 1mA | Approx. 1mA |
| Protection Class | IP65 | IP65 | IP65 |
| Operating Temperature Range | -40°C ~ +85°C | -40°C ~ +85°C | -40°C ~ +85°C |
| Environmental Temperature Range | -45°C ~ +90°C | -45°C ~ +90°C | -45°C ~ +90°C |
| Durability | 5G, 5 ~ 500Hz | 5G, 5 ~ 500Hz | 5G, 5 ~ 500Hz |
| Shock Resistance | 10,000G | 10,000G | 10,000G |
| Weight (without cable) | 18.5g | 18.5g | 18.5g |
| Housing Material | Glass fiber reinforced plastic housing | Glass fiber reinforced plastic housing | Glass fiber reinforced plastic housing |
| Connection Cable | Standard: 0.5m (φ2.1mm) shielded cable | Standard: 0.5m (φ2.1mm) shielded cable | Standard: 0.5m (φ2.1mm) shielded cable |
