Manufacturer: Eagle Industry Co., Ltd.
Model: EA100

Features

• Single seal
• In-house manufactured carbon seal faces
• Three different impeller connections available

Specification

Materials

• Seal face: Carbon graphite resin
  impregnated (B)
  Seat: Aluminium oxide (V)
  Elastomer: NBR (P)
  Metal parts: CrNi steel (F)

Operating range

• Shaft diameter: d1 = 8 … 20 mm (0.32″ … 0.78″)
  Pressure: p1 = 5 bar (73 PSI), vacuum up to 0.1 bar (1.45 PSI)
  Temperature: t = -20 °C … +80 °C (-4 °F… +176 °F)
  Sliding velocity: vg = 5 m/s (16 ft/s)
  Solids content：0.05wt.%

Recommended applications

• Water and waste water technology
  Drinking water
  Hot water circulation pumps
  Industrial pumps/equipment
  Domestic pumps
  Low duty water pumps
  Pumps for water & under floor
  Heating systems
  Pumps for solar systems

Product variants

• EA102
  As EA100 but with a collar.
  EA103
  As EA100 but without a collar. Please inquire.
  EA104
  As EA100 but with different coil spring installations. Please inquire.
