FUJI DIE
Fuji Die PS1 Type Electroplated Grinding Tool
Manufacturer: Fuji Die Co., Ltd.
Model: PS1 Type
Specifications And Dimensions (Unit : mm)
| Model No. | D | Y | L | T |
|---|---|---|---|---|
| PS1-5 | 5 | 4 | 50 | 10 |
| PS1-7 | 7 | 4 | 50 | 10 |
| PS1-8 | 8 | 6 | 60 | 10 |
| PS1-10 | 10 | 6 | 60 | 10 |
| PS1-13 | 13 | 6 | 60 | 10 |
| PS1-16 | 16 | 6 | 60 | 10 |
| PS1-20 | 20 | 6 | 60 | 10 |
| PS1-8L | 8 | 6 | 80 | 10 |
| PS1-10L | 10 | 6 (10) | 80 | 10 |
| PS1-13L | 13 | 6 (10) | 80 | 10 |
| PS1-16L | 16 | 6 (10) | 80 | 10 |
| PS1-20L | 20 | 6 (10) | 80 | 10 |
