Fuso Rubber
Fuso Rubber Flame-Retardant Fluorine Rubber Sheet 80
Manufacturer: Fuso Rubber Co., Ltd.
Model: Fluorine Rubber Sheet 80
Features
- This sheet retains the functionality of regular fluoroelastomer and is also flame-retardant.
- Fluoroelastomer is a high-performance rubber that utilizes the unique properties of fluorine atoms, and is superior to other rubbers in heat resistance, oil resistance, weather resistance, and chemical resistance.
- This product has been confirmed by an external organization to be equivalent to UL94 V-0 (2mm or more) and V-1 (1mm).
Product specifications
- Material: Fluorine rubber
- Hardness: 81 (Type A)
- Color: Black
- General physical properties
Tensile strength: 11.5MPa
Elongation at break: 250% - Heat aging resistance (275℃ x 72h)
Hardness change (Type A): +10
Tensile strength change rate: +2%
Elongation change rate at break: -42% - Oil resistance (150℃ x 72h) IRM903 Volume change rate: +2%
- Compression set (150°C x 72h): 17%
- Flame retardancy (UL94 equivalent test results)
1mm: V-1
2mm: V-0
3mm: V-0
Size
- Minimum size
Thickness: 1mm
Width x Length: 10mm x 10mm - Maximum size
Thickness: 3mm
Width x Length: 1,000mm x 2,000mm
