Features

• First, you detect angular velocity with a vibration gyro sensor.

• Next, you power it from DC 3.5–8.4 V and draw 30 mA with no servo attached.

• Meanwhile, you operate confidently from –10°C to +45°C.

• For tight installs, you use a 20.7 × 21.7 × 10.6 mm body (no protrusions) that weighs just 5.4 g.

• Additionally, you monitor status via LED and connect through S.BUS/S.BUS2.

Functions

• For sharper control, you pair it with F-4G UR-mode servos and get high-speed response.

• Then, you set remote gain from the transmitter (needs a 3+ channel radio with an adjustable third channel).

• For RC drift, you load drift-specific settings that curb road-surface effects and, together with UR response, deliver more dramatic slides.

• Moreover, you benefit from an ultra-compact, lightweight build thanks to high-density mounting.

• With the aluminum case, you increase rigidity and transmit chassis motion to the sensors more precisely.

• For wiring, you connect over S.BUS, and, if needed, you also run it with non-S.BUS systems.

• Importantly, you use digital servos only (Futaba HPS/BLS and other digital types); you don’t use analog servos.

Modes & Adjustments

• Choose Normal / AVCS.

• Enable High-Speed Response and High-Gain.

• Tune tail slide speed, gyro curve, left/right endpoints, and damper.

• Prioritize steering with Stick Priority.

• Finally, you adjust settings wirelessly when you use F-4G gear: T10PX, T6PV, R404SBS, R404SBS-E.

  • For GYD560/GYC480, you also use T10PX/T6PV/R404SBS/R404SBS-E after a software update.
