Common Functions (Airplane / Glider / Helicopter / Multicopter)

• Control up to 10 channels: Drive complex models with room to grow.
• 30 model memories + model copy: Store, duplicate, and organize setups quickly.
• Model Menu profiles: Switch among Airplane / Helicopter / Glider / Multicopter layouts to match your craft.
• RF formats (2.4 GHz): Select T-FHSS Air or S-FHSS on the Model Select screen, then pick a receiver from the compatibility list.
• Throttle (motor) curve—5 points: Shape power delivery for smooth launches and precise mid-stick control.
• Fail-safe (all channels): Predefine safe outputs for signal-loss events.
• Battery fail-safe (T-FHSS Air only): Set the trigger voltage by battery type for smarter protection.
• Program mixing—6 slots: Build four linear mixes and two 5-point curve mixes for custom control logic.
• Dual timers: Save two timers per model so you don’t re-enter values when you swap aircraft.
• Stick alarm: Play a warning tone when the throttle reaches a chosen position.
• Trainer tools: Choose a training mode that fits the pilot—limit channels or add counter-rudder assistance.
• I/O ports: Use the trainer connector, 3.5 mm earphone jack, and S.IF port to program S.BUS servos and telemetry sensors.
• Languages: Navigate in Japanese Katakana / English / +5 partially supported languages.
• Names: Enter model/user names up to 10 characters for easy identification.
• Alarms & haptics: Get timer beeps and vibration alerts for battery, MIX, and telemetry events.

Flight tuning basics:

• D/R (Dual Rate): Aileron, Elevator, Rudder
• EXP (Exponential): Aileron, Elevator, Throttle (not in heli mode), Rudder
• EPA (ATV), digital trim, sub-trim (all channels), reverse
• Throttle ATL for high-side trim behavior
• Stick calibration to re-zero inputs
• Servo display / servo test for quick checks
• S.BUS servo programming for S.BUS/S.BUS2 parameters
• Model Transformer for wireless data transfer

Airplane-Only

• Flaperon with differential and Flap trim for precise approaches.
• Aileron differential and Aileron→Rudder for coordinated turns.
• Elevator→Flap and Flap→Elevator to hold pitch with flap changes.
• Air brakes, V-tail, Elevon, and Elbeta (CH2 + CH8) for diverse airframes.
• Snap Roll for repeatable aerobatics.
• Gyro sensitivity switching and Gyro Sense for quick gain changes.
• Throttle curve / Pitch curve (up to 5 points) plus Throttle delay and Idle Down for smoother power management.
• THR→Needle mixing to track mixture with throttle.
• Throttle cut / Motor cut for safe ground handling.
• (Repeat) Flap trim available on dedicated control.

Helicopter-Only

• Conditions: Set Idle Up and Throttle Hold for maneuvers and autos.
• Swash AFR, Swash MIX, and Swash Ring to keep CCPM geometry clean.
• Offset and Delay for smooth condition and trim transitions.
• Throttle cut and Gyro Sense for safety and stability.
• Throttle curve / Pitch curve to shape headspeed and lift.
• Pitch→Rudder to hold tail authority during collective changes.
• THR Hold and Governor for solid RPM management.
• Hovering TH and Hovering Pi to lock in a steady hover.
• High/Low pitch limits, Throttle MIX, and THR→Needle for fine power/mixture control.

Glider-Only

• Condition presets and Motor switch for electric gliders.
• Gyro Sense for soaring stability.
• Aileron→Rudder and Rudder→Aileron to coordinate turns either way.
• V-tail plus a full Camber toolkit: Camber FLP, Camber MIX, Camber→ELE, ELE→Camber, AIL→Camber, AIL→BRKFL.
• Butterfly (Crow) for steep, controlled descents.
• Trim Mix to snap AIL/ELE/FLP/RUD trims to preset positions with a switch.

Multicopter-Only

• Gyro Sense for camera-gimbal or auxiliary stabilization tuning.
• Center alarm to mark a chosen throttle position audibly.

Included Accessories

• Receiver battery power switch
• Mini driver
• Instruction manual
• Warranty

Optional Parts

• NiMH TX pack: HT5F1800B (6.0 V / 1800 mAh) — recommended charger HBC-3A(4)
• LiFe TX pack: FT2F2100BV2 (6.6 V / 2100 mAh) — recommended charger LBC-4E5
• LiFe packs for receivers/servos: available separately
• Telemetry sensors: available separately
• Trainer cord (micro type): not compatible with 12FG
• Neck strap
• Genuine lever head
