Direct, connected control with T-FHSS SR and SR-mode servos: The system uses SR-mode servos to deliver response beyond conventional digital servos. You set the link mode (SR/digital, etc.) and telemetry on the receiver settings screen, so you can configure everything in one place.

• Telemetry availability: You can use telemetry only in T-FHSS mode; meanwhile, T-FHSS SR, S-FHSS, FASST-C2, and MINI-Z T-FHSS do not support telemetry.

• Telemetry-off indicator: When you turn telemetry off, the “telemetry off sign” lights an LED on the back of the LCD to alert people around you.

• Up to 7 channels (S-FHSS): With S-FHSS, you can run as many as seven channels, so you add sensors and accessories more freely.
• Slim body: The thinnest body in its class fits every driving posture; as a result, long sessions feel more comfortable.
• Home button: With a single press, you jump to the settings screen; additionally, you can assign this button to your favorite function and skip the touch panel altogether.
• Variable throttle stroke: You adjust the throttle-stick angle to taste (the factory setting uses the widest angle), which helps you modulate throttle more precisely.
• Throttle neutral adjuster: You tune the neutral split from 5:5 to 7:3, so the feel matches different vehicle styles.
• Stick tension adjuster: You dial in spring tension for both steering and throttle sticks to get the exact resistance you prefer.
• Stick-angle adjuster: You also tweak the stick-stroke axis angle for a more natural wrist position.
• microSD card slot: You save model files, log telemetry, and update software with a microSD card (sold separately; supports SD/SDHC, not SDXC).
• Convenient switches: Beyond the main controls, the transmitter adds body switches on the bottom and paddle switches on the back, which speeds up in-run adjustments.
• Wide-view full-color LCD with touch: Because the screen sits on top, you can glance at settings while driving without breaking flow.
• Design & IP: The product won the 2018 Good Design Award and holds 2 patents plus 2 design registrations (including partial designs).

Functions & Specifications

Setup Menu

Receiver settings (compatible with T-FHSS SR, T-FHSS, S-FHSS, FASST-C2, and MINI-Z).

• MINI-Z note: The transmitter supports T-FHSS (MINI-Z EVO mode) only; it does not support MINI-Z EVO2 or MINI-Z FHSS.

• Acceleration

• Condition

• Idle Up

• Channel limiter: Limit maximum servo travel to protect your hardware.

• Channel assignment: Map steering or throttle to any channel as you reorganize the layout.

• Throttle mode

• Sub-trim

• Trim/Dial settings

• Switch settings

• Endpoint, Reverse, D/R, ATL, Failsafe, Servo View

Model Menu

Model select/copy
Model name
Delete model
Data reset

Mixing Menu

Steering mix
Brake mix
Gyro mix
4WS mix
Dual ESC
CPS mix (1/2/3): When you use CPS-1 (optional), you set LED patterns and more.
Tank mix: Ideal for tracked vehicles such as tanks.

Program mix (1–5): Apply mixing between any channels. For example, you can: make the car rotate harder under braking → reduce gyro gain only while braking, stabilize acceleration → increase gyro gain when throttle is ON, cut straight-line hunting → lower gyro gain near steering neutral.

Tilt mix: Especially effective for boats.
Winch mix: By linking throttle and winch both ways, you drive and operate the winch simultaneously with one control.

Racing Menu

Curve (EXP) & Speed: Set steering and throttle independently; additionally, throttle offers a Curve mode that suits drag cars.
Traction Control
ABS
Start
Engine Cut
Telemetry menu & sensor list: Review and manage live data sources.

Accessories Menu

Timer & lap list for practice sessions
Home button settings for personalization
Home screen display: Switch between Servo View and Telemetry View
Index table for DD cars
Gear-ratio table
S.BUS Servo: Configure S.BUS servos directly
MC (ESC) Link: Works with MC970CR and MC971CR
Gyro Link: Adjust gyro parameters from the transmitter

System Menu

Display: Set backlight and calibrate the touch panel
Audio: Adjust switch sounds, alarms, and telemetry voice guides
Battery: Select the battery type to get the correct low-voltage alarm
Adjuster: Calibrate steering and throttle sticks
Receiver Update: Update receiver firmware directly from the transmitter
Date/Time & LED: Customize clock and LED behavior

Included Accessories

FT2F1700BV2 transmitter battery ×1 (installed at shipment; connector removed by the manufacturer)

LBC-34D P charger ×1
Receiver-connector dust caps ×3
Throttle ratchet plate ×1
Instruction manual ×1
Mini screwdriver ×1
