Manufacturer: Hirosugi Instruments Co., Ltd.
Model: ASU-400-6

Specification

Material

Free-cutting stainless steel (SUS303)

process

Degreasing

Exterior drawings

Tolerance of L
: ±0.1 up to L=60
, ±0.2 from L=62

Thread diameter (pitch)	L	Part Number	ℓ1
M4 (0.7)	5	ASU-405-6	Fully threaded
	5.5	ASU-405.5-6
	6	ASU-406-6
	6.5	ASU-406.5-6
	7	ASU-407-6
	7.5	ASU-407.5-6
	8	ASU-408-6
	8.5	ASU-408.5-6
	9	ASU-409-6
	9.5	ASU-409.5-6
	10	ASU-410-6
	11	ASU-411-6
	12	ASU-412-6
	12.5	ASU-412.5-6
	13	ASU-413-6
	14	ASU-414-6
	15	ASU-415-6
	16	ASU-416-6
	16.5	ASU-416.5-6
	17	ASU-417-6	8
	17.5	ASU-417.5-6	8
	18	ASU-418-6	8
	19	ASU-419-6	8
	20	ASU-420-6	8
	twenty one	ASU-421-6	8
	twenty two	ASU-422-6	8
	twenty three	ASU-423-6	8
	twenty four	ASU-424-6	8
	twenty five	ASU-425-6	8
	26	ASU-426-6	8
	27	ASU-427-6	8
	28	ASU-428-6	8
	29	ASU-429-6	8
	30	ASU-430-6	8
	31	ASU-431-6	8
	32	ASU-432-6	8
	33	ASU-433-6	8
	34	ASU-434-6	8
	35	ASU-435-6	8
	36	ASU-436-6	8
	37	ASU-437-6	8
	38	ASU-438-6	8
	39	ASU-439-6	8
	40	ASU-440-6	8
	41	ASU-441-6	8
	42	ASU-442-6	8
	43	ASU-443-6	8
	44	ASU-444-6	8
	45	ASU-445-6	8
	46	ASU-446-6	8
	47	ASU-447-6	8
	48	ASU-448-6	8
	49	ASU-449-6	8
	50	ASU-450-6	8
	51	ASU-451-6	8
	52	ASU-452-6	8
	53	ASU-453-6	8
	54	ASU-454-6	8
	55	ASU-455-6	8
	56	ASU-456-6	8
	57	ASU-457-6	8
	58	ASU-458-6	8
	59	ASU-459-6	8
	60	ASU-460-6	8
62	ASU-462-6	8
64	ASU-464-6	8
65	ASU-465-6	8
66	ASU-466-6	8
68	ASU-468-6	8
70	ASU-470-6	8
72	ASU-472-6	8
74	ASU-474-6	8
75	ASU-475-6	8
76	ASU-476-6	8
78	ASU-478-6	8
80	ASU-480-6	8
85	ASU-485-6	8
90	ASU-490-6	8
95	ASU-495-6	8
100	ASU-4100-6	8
