Manufacturer: Hirosugi Instruments Co., Ltd.
Model: BSU-500

Specification

Material

Free-cutting stainless steel (SUS303)

process

Degreasing

Exterior drawings

L tolerance:
±0.1 up to L=60
, ±0.2 from L=62 to 100,
±0.3 from L=105

Thread diameter (pitch)	L	Part Number	ℓ1
M5 (0.8)	8	BSU-508	5
	9	BSU-509	6
	10	BSU-510	7
	11	BSU-511	8
	12	BSU-512	9
	13	BSU-513	10
	14	BSU-514	10
	15	BSU-515	10
	16	BSU-516	10
	18	BSU-518	10
	19	BSU-519	10
	20	BSU-520	10
	twenty three	BSU-523	10
	twenty five	BSU-525	10
	27	BSU-527	10
	30	BSU-530	10
	33	BSU-533	10
	35	BSU-535	10
	37	BSU-537	10
	40	BSU-540	10
	43	BSU-543	10
	45	BSU-545	10
	48	BSU-548	10
	50	BSU-550	10
	52	BSU-552	10
	55	BSU-555	10
	57	BSU-557	10
	60	BSU-560	10
	62	BSU-562	10
	65	BSU-565	10
	68	BSU-568	10
	70	BSU-570	10
	72	BSU-572	10
	75	BSU-575	10
	78	BSU-578	10
	80	BSU-580	10
	83	BSU-583	10
	85	BSU-585	10
	88	BSU-588	10
	90	BSU-590	10
	92	BSU-592	10
	95	BSU-595	10
	97	BSU-597	10
	100	BSU-5100	10
	105	BSU-5105	10
	110	BSU-5110	10
	115	BSU-5115	10
	120	BSU-5120	10
	125	BSU-5125	10
	130	BSU-5130	10
	135	BSU-5135	10
	140	BSU-5140	10
	145	BSU-5145	10
	150	BSU-5150	10
