Manufacturer: Hirosugi Instruments Co., Ltd.
Model: CF-400ZE

Specification

Material

Steel plate (SPCC)

process

Trivalent chromium chromate treatment

Exterior drawings

L tolerance:
±0.05 up to L=10
, ±0.1 from L=10.5 to 20,
±0.2 from L=22

Screw diameter	L	Part Number
For M4	2	CF-402ZE
	2.5	CF-402.5ZE
	3	CF-403ZE
	3.5	CF-403.5ZE
	4	CF-404ZE
	4.5	CF-404.5ZE
	5	CF-405ZE
	5.5	CF-405.5ZE
	6	CF-406ZE
	6.5	CF-406.5ZE
	7	CF-407ZE
	7.5	CF-407.5ZE
	8	CF-408ZE
	8.5	CF-408.5ZE
	9	CF-409ZE
	9.5	CF-409.5ZE
	10	CF-410ZE
	10.5	CF-410.5ZE
	11	CF-411ZE
	11.5	CF-411.5ZE
	12	CF-412ZE
	12.5	CF-412.5ZE
	13	CF-413ZE
	14	CF-414ZE
	15	CF-415ZE
	16	CF-416ZE
	17	CF-417ZE
	18	CF-418ZE
	19	CF-419ZE
	20	CF-420ZE
	twenty two	CF-422ZE
	twenty five	CF-425ZE
	28	CF-428ZE
	30	CF-430ZE
	32	CF-432ZE
	35	CF-435ZE
