Product Made in Japan
Manufacturer: Kansai
Model:KS/KG100/KS/KG1150

US Shackle – KS/KG100/KS/KG1150 (Straight Type)

Feature

“KS” means “wear-resistant steel” while “KG” means “galvanized steel.”
“1150” refers to “Straight nut-bolt type” while “100” refers to “Straight-bolt type.”

This is a US standard, not an ISO standard, and is only available in the US.

Although the working load is specified, in a static test with a concentrated point load, the product will deform if twice the load is applied. In addition, since the test load is not constant, it is used in the working load. This is the difference between Japan and other countries.
These products have higher quality and durability in both quality and bearing capacity.

Dimension table (unit = m/m)

120ton and 150ton have handles.
The breaking load is more than 6 times the working load.
The proof test uses the same single point concentrated loading method as JIS and is twice the working load.
