KOGANEI CORPORATION
Koganei Air Indicators M5 × 0.8, R1/8 (M5 × 0.8)
Manufacturer: KOGANEI CORPORATION
Features
Air indicators change colors to show whether air pressure is present or absent in pneumatic circuits. This provides clear, immediate feedback for easy monitoring. Additionally, they allow quick checks of pressurized lines, as well as tracking the operating status and completion of operations.
Moreover, the design of the air indicators ensures they completely change colors. This feature, along with sharply contrasting indications, makes it easier to detect pressure changes at a glance, improving system safety.
Specifications
| Item | KIS-R | KIS-G | KIL-R | KIL-G |
|---|---|---|---|---|
| Port size | M5 × 0.8 | R1/8 and M5 × 0.8 (female thread) | R1/8 and M5 × 0.8 (female thread) | R1/8 and M5 × 0.8 (female thread) |
| Media | Air | |||
| Operating pressure range | MPa [psi]: 0.15 ~ 0.9 [22 ~ 131] | MPa [psi]: 0.1 ~ 0.7 [15 ~ 102] | MPa [psi]: 0.1 ~ 0.7 [15 ~ 102] | MPa [psi]: 0.1 ~ 0.7 [15 ~ 102] |
| Proof pressure | MPa [psi]: 1.3 [189] | MPa [psi]: 1.3 [189] | MPa [psi]: 1.3 [189] | MPa [psi]: 1.3 [189] |
| Operating temperature range | °C [°F]: 0 ~ 60 [32 ~ 140] | °C [°F]: 0 ~ 60 [32 ~ 140] | °C [°F]: 0 ~ 60 [32 ~ 140] | °C [°F]: 0 ~ 60 [32 ~ 140] |
| Maximum operating frequency | Hz: 5 | Hz: 3 | Hz: 3 | Hz: 3 |
| Lubrication | Required | Required | Required | Required |
| Color indication | No air pressure: Red Under air pressure: None | No air pressure: Green Under air pressure: Red | No air pressure: Red Under air pressure: Green | No air pressure: Red Under air pressure: Green |
| Body material | Brass | Brass | Aluminum alloy | Aluminum alloy |
| Mass | g [oz.]: 5 [0.18] | g [oz.]: 5 [0.18] | g [oz.]: 86 [3.03] | g [oz.]: 86 [3.03] |
