KOGANEI CORPORATION
Koganei C Series Jig Cylinders Standard Cylinders Double Acting (Long Life)
Manufacturer: KOGANEI CORPORATION
Model: C Series
Features
Our advanced pressure regulation units deliver superior performance by combining a compact design with high stability. Because we prioritize precision, every unit includes a stable pressure regulator equipped with preset markers as a standard feature. Furthermore, you can customize your setup to match specific operational requirements. You can choose from a standard pressure specification, an integrated check mechanism, or a specialized low-pressure specification. Since we offer these diverse options, our components integrate seamlessly into a wide range of industrial applications.
Specifications
| Cylinder bore | 12 [0.472] | 16 [0.630] | 20 [0.787] | 25 [0.984] | 32 [1.260] | 40 [1.575] | |
|---|---|---|---|---|---|---|---|
| Item | Double acting type | ||||||
| Medium | Air | ||||||
| Operating pressure range | MPa [psi] | 0.1 ~ 1.0 [15 ~ 145] | |||||
| Proof pressure | MPa [psi] | 1.05 [152] | |||||
| Operating temperature range | °C [°F] | 0 to 60 [32 to 140] | |||||
| Operating speed range | mm/s [in/sec] | 30 ~ 500 [1.2 ~ 19.7] | |||||
| Cushion | Rubber bumper | ||||||
| Lubrication | Not required | ||||||
| Port size | M5×0.8 | Rc1/8 | |||||
