Manufacturer: KOGANEI CORPORATION

Features

High-Performance Ionization Technology

• Advanced AC Systems: To begin with, the high-performance 200 Hz AC system enables an outstanding ion balance for stable operations.

• Precision Output: Specifically, the DTY-ELF14H model produces an excellent ion balance of $\pm$5V, while the DTY-ELF13H maintains $\pm$10V.

• Long-Term Stability: Consequently, this newly developed format ensures steady and long-term elimination of static electricity.

• Environmental Safety: Furthermore, the hardware maintains extremely low ozone production at less than 0.004 ppm to ensure user safety.

Application Versatility and Efficiency

• Diverse Nozzle Options: Additionally, a wide array of nozzle types enables charge removal tasks ranging from pinpoint targets to wide area workpieces.

• Remote Ion Transport: Therefore, the blow type models facilitate never-before-possible ion transport using specialized tubing and metal piping.

• Resource Management: In a similar fashion, the air-saving type sucks in outside air for blowing to optimize consumption.

• No-Air Flexibility: Moreover, several models do not require an air supply at all, which allows for flexible installation based on the specific location.

Maintenance and Monitoring

• Simplified Servicing: To facilitate easier upkeep, the design features a one-touch connection and disconnection mechanism for the needle unit.

• Tool-Free Access: Specifically, users can remove and attach the discharge needle unit and louvers with one touch without using any tools.

• Automated Care: Furthermore, certain high-end models include an automatic cleaning function so that manual maintenance of the discharge needle is not needed.

• Visual Verification: Similarly, the hardware includes a balance indicator so users can confirm the ratio of positive and negative ions at a glance.

Safety and Diagnostics

• Active Protection: To ensure ongoing safety, an alarm output function detects problems with static discharge, high-voltage circuits, or internal fans.

• Abnormality Detection: Likewise, the system provides an abnormal ion balance output function to alert operators of performance shifts.

• Global Compliance: Finally, the entire equipment range remains CE marking compliant to meet essential industrial safety standards.

Specifications
