Koganei Multi Mount Cylinders Double Acting Type
Manufacturer: KOGANEI CORPORATION
Specifications
| Item | Bore size mm [in.] | ||
|---|---|---|---|
| 6 [0.236] | 10 [0.394] | 16 [0.630] | |
| Operating type | Double acting type | Double acting type | Double acting type |
| Media | Air | Air | Air |
| Operating pressure range MPa [psi] | 0.15 ~ 0.7 [22 ~ 102] | 0.1 ~ 0.7 [15 ~ 102] | 0.15 ~ 0.7 [22 ~ 102] |
| Proof pressure MPa [psi] | 1.03 [149] | 1.03 [149] | 1.03 [149] |
| Operating temperature range °C [°F] | 0 ~ 60 [32 ~ 140] | 0 ~ 60 [32 ~ 140] | 0 ~ 60 [32 ~ 140] |
| Operating speed range mm/s [in./sec.] | 50 ~ 300 [2.0 ~ 11.8] | 50 ~ 300 [2.0 ~ 11.8] | 50 ~ 300 [2.0 ~ 11.8] |
| Cushion | Rubber bumper | Rubber bumper | Rubber bumper |
| Lubrication | Not required | Not required | Not required |
| Port size | M5 X 0.8Note | M5 X 0.8Note | M5 X 0.8Note |
| Stroke tolerance mm [in.] | +1 [0.039] | +1 [0.039] | +1 [0.039] |
