KOGANEI CORPORATION
Koganei Multi Mount Cylinders Non-Rotating Double Acting Type
Manufacturer: KOGANEI CORPORATION
Specifications
| Item | Bore size mm [in.] | ||
|---|---|---|---|
| 6 [0.236] | 10 [0.394] | 16 [0.630] | |
| Operating type | Non-rotating double acting type | Non-rotating double acting type | Non-rotating double acting type |
| Media | Air | Air | Air |
| Operating pressure range | 0.2～0.7 MPa [29～102 psi] | 0.15～0.7 MPa [22～102 psi] | 0.1～0.7 MPa [15～102 psi] |
| Proof pressure | 1.03 MPa [149 psi] | 1.03 MPa [149 psi] | 1.03 MPa [149 psi] |
| Operating temperature range | 0～60°C [32～140°F] | 0～60°C [32～140°F] | 0～60°C [32～140°F] |
| Operating speed range | 50～300 mm/s [2.0～11.8 in./sec.] | 50～300 mm/s [2.0～11.8 in./sec.] | 50～300 mm/s [2.0～11.8 in./sec.] |
| Cushion | Rubber bumper | Rubber bumper | Rubber bumper |
| Lubrication | Not required | Not required | Not required |
| Non-rotating accuracy | ±2° | ±1.5° | ±1° |
| Port size | M5 X 0.8 | M5 X 0.8 | M5 X 0.8 |
| Stroke tolerance | +1 / -0.039 mm [+0.039 / -0.0015 in.] | +1 / -0.039 mm [+0.039 / -0.0015 in.] | +1 / -0.039 mm [+0.039 / -0.0015 in.] |
