Manufacturer: MALHATY PUMP MFG.CO., LTD.
Model:
Features
- By adopting a special dry seal, the pump does not cause leakage from the seal in operation.
- Dry-running is allowable.
- Semi-open type impeller adopted for this model prevents clogging.
- The vertical design enables an easy installation in a small space.
- The back pull-out structure enables easy assembly/disassembly without disconnecting piping.
- The allowable pushing pressure is 3meters.
Materials
| 2PDM-27M | 2PDM-32M |
|---|
| Casing | SCS13 | SCS14 |
| Impeller | SCS13 | SCS14 |
| Shaft | SUS304 | SUS316 |
| Cover Packkng | FKM | FKM |
Specification
| Bore | 32×25mm 〜 65×65mm |
| Discharging Volume | 25L/min 〜 540L/min |
| Total Head | 6m 〜 23m |
| Shaft Seal | Special Dry Seal（MGW type） |
| Motor Pole | 2P（2900min⁻¹/50Hz 3500min⁻¹/60Hz) |
